3917-2. Steps to take in an emergency
7
When trouble arises
ing parts as shown in the illustration
4 Start the engine of the second vehi-
cle. Increase the engine speed
slightly and maintain at that level for
approximately 5 minutes to
recharge the battery of your vehi-
cle.
5 Open and close any of the doors of
your vehicle with the engine switch
off.
6 Maintain the engine speed of the
second vehicle and start the engine
of your vehicle by turning the
engine switch to IGNITION ON
mode.
7 Once the vehicle’s engine has
started, remove the jumper cables
in the exact reverse order from
which they were connected.
Once the engine starts, have the vehicle
inspected at your Lexus dealer as soon as
possible.
■Starting the engine when the battery is
discharged
The engine cannot be started by push-start-
ing.
■To prevent battery discharge
●Turn off the headlights and the audio sys-
tem while the engine is stopped.
●Turn off any unnecessary electrical com-
ponents when the vehicle is running at a
low speed for an extended period, such
as in heavy traffic.
■When the battery is removed or dis-
charged
●Information stored in the ECU is cleared.
When the battery is depleted, have the
vehicle inspected at your Lexus dealer.
●Some systems may require initialization.
(  P.430)
■When removing the battery terminals
When the battery terminals are removed,
the information stored in the ECU is
cleared. Before removi ng the battery termi-
nals, contact your Lexus dealer.
■Charging the battery
The electricity stored in the battery will dis-
charge gradually even when the vehicle is
not in use, due to natural discharge and the
draining effects of certain electrical appli-
ances. If the vehicle is left for a long time,
the battery may discharge, and the engine
may be unable to start. (The battery
recharges automatically during driving.)
■When recharging or replacing the bat-
tery
●In some cases, it may not be possible to
unlock the doors using the smart access
system with push-button start when the
battery is discharged. Use the wireless
remote control or the mechanical key to
lock or unlock the doors.
●The engine may not start on the first
attempt after the battery has recharged
but will start normally after the second
attempt. This is not a malfunction.
●The engine switch mode is memorized by
the vehicle. When the battery is recon-
nected, the system will return to the
mode it was in before the battery was dis-
charged. Before disconnecting the bat-
tery, turn the engine switch off.
If you are unsure wh at mode the engine
switch was in before the battery dis-
charged, be especially careful when
reconnecting the battery.
■When replacing the battery
●Use a battery that conforms to European
regulations.
●Use a battery that the case size is same as
the previous one (LN3), 20 hour rate
capacity (20HR) is equivalent (70Ah) or
greater, and performance rating (CCA)
is equivalent (592A) or greater.
• If the sizes differ, the battery cannot be properly secured.
• Battery performance may decrease and
the engine may not be able to start.

4228-2. Customization
■Smart access system with push-button start and wireless remote control
( P.95, 106)
■Smart access system with push-button start ( P.95, 106)
■Wireless remote control ( P.92, 95, 106)
FunctionDefault settingCustomized setting
Operating signal (Buzzers)5OffOO1 to 7
Operation signal (Emergency
flashers)OnOffOO
Time elapsed before automatic
door lock function is activated if
door is not open ed after being
unlocked
60 seconds
Off
OO30 seconds
120 seconds
Open door warning buzzerOnOffO
FunctionDefault settingCustomized setting
Smart access system with push-
button startOnOffO
Smart door unlockingDriver’s doorAll the doorsOO
Time elapsed before unlocking all
the door when gripping and hold-
ing the driver’s door handle
2 seconds
Off
O1.5 seconds
2.5 seconds
Number of consecutive door lock
operations2 timesAs many as desiredO
FunctionDefault settingCustomized setting
Wireless remote controlOnOffO
Unlocking operation
Driver’s door
unlocked in one step, all doors
unlocked in two step
All doors unlocked in one stepOO
ABC
ABC
ABC

Alphabetical index451
change ....................................................... 71, 76
Do-it-yourself maintenance ..................... 310
Door courtesy lights ....................................274
Door lock Doors.................................................................. 95
Smart access system with push-button start ................................................................. 106
Wireless remote control........................... 93
Doors ................................................................... 95 Automatic door lock ing and unlocking
system ............................................................. 98
Door glasses .................................................. 124
Door lock.......................................................... 95
Open door warning buzzer .......... 96, 98
Outside rear view mirrors ........................121
Rear door child-protectors ..................... 98
Drive distance ...................................................79
Drive info 1/Drive info 2 ...............................79
Driver’s seat position memory .................. 114 Driving position memory...........................114
Memory recall function ............................. 116
Drive-start control ........................................135
Driving................................................................134 Break-in tips ...................................................135
Correct driving posture .............................23
Driving Mode Select switch...................210
Procedures ..................................................... 134
Winter drive tips...........................................251
Driving information display .........................79
Driving Mode Select switch......................210
Driving range ....................................................79
Driving support system information display ............................................................................. 82
Dynamic radar cruise control with full- speed range..................................................195Warning message..................................... 203
Dynamic Torque Control AWD system .......................................................................... 246
E
Eco drive mode ..............................................210
Eco Driving Indicator.................... 80, 81, 87 Eco Driving Indicator Light ........................ 80
EDR (Event data recorder) ............................7
Elapsed time ......................................................79
Electric Power Steering (EPS)
Function .......................................................... 246
Warning light ...............................................363
Electronic key .................................................. 92 Battery-saving function............................ 107
If the electronic key does not operate properly .......................................................387
Replacing the battery .................................341
Electronic roof sunshade Jam protection function ........................... 130
Operation ........................................................129
Emergency, in case of If a warning buzzer sounds.................... 361
If a warning light turns on........................ 361
If a warning message is displayed .......371
If the battery is discharged ................... 389
If the electronic key does not operate properly .......................................................387
If the engine will not start....................... 384
If the fuel filler do or cannot be opened
......................................................................... 386
If the vehicle is trapped in rising water ..........................................................................353
If you have a flat tire ..................................375
If you lose your keys ................................ 386
If you think something is wrong......... 359
If your vehicle becomes stuck ............ 395
If your vehicle has to be stopped in an emergency .................................................352
If your vehicle needs to be towed .... 355
If your vehicle overheats ........................393
Emergency flashers .................................... 352
Engine ................................................................144 ACCESSORY mode................................147
Compartment............................................... 318
Engine switch .................................................144
Fuel pump shut off system.................... 360
Hood ................................................................. 316
How to start the engine ............................144

454Alphabetical index
K
Keyless entrySmart access system with push-button start ................................................................. 106
Wireless remote control........................... 93
Keys...................................................................... 92 Battery-saving function ............................107
Electronic key ................................................. 92
Engine switch................................................. 144
If the electronic key does not operate properly....................................................... 387
If you lose your keys.................................386
Key number plate ......................................... 92
Keyless entry .......................................... 95, 101
Mechanical key.............................................. 92
Replacing the battery.................................341
Warning buzzer .......................................... 106
Wireless remote control........................... 93
Knee airbags .................................................... 28
L
Lane Tracing Assist (LTA) ........................ 184 Operation....................................................... 184
Warning messages .................................... 192
Language (multi-information display) ... 82
LATCH anchors ............................................. 50
Lever Auxiliary catch lever ...................................316
Hood lock release lever...........................316
Internal trunk release lever .................... 103
Shift lever..........................................................149
Turn signal lever ...........................................153
Wiper lever.....................................................164
Lexus climate concierge ............................ 261
Lexus Enform Safety Connect.................. 55
Lexus Safety System + 2.0 ......................... 171 Automatic High Beam ............................... 161
Dynamic radar cruise control with full-speed range ............................................... 195
LTA (Lane Tracing Assist)..................... 184
PCS (Pre-Collision System).................. 177 RSA (Road Sign Assist)........................... 193
License plate lights....................................... 158 Light switch .................................................... 158
Replacing light bulbs ................................346
Light bulbs Replacing .......................................................346
Wattage ..........................................................407
Lights Automatic High Beam system ............... 161
Front interior lights .................................... 275
Front personal lights................................. 275
Headlight switch.......................................... 158
Interior lights list .......................................... 274
Interior lights ................................................. 274
Rear interior lights ..................................... 275
Rear personal lights .................................. 275
Trunk light ....................................................... 103
Turn signal lever .......................................... 153
Vanity lights ................................................... 281
Wattage ..........................................................407
Welcome light illumination control ... 159
Lock steering column ..................................145
Low profile tire.............................................. 326
LTA (Lane Tracing Assist) ........................ 184 Operation ....................................................... 184
Warning messages.....................................192
Luggage mat .................................................280
M
Maintenance Do-it-yourself maintenance ...................314
General maintenance .............................. 310
Maintenance data ..................................... 398
Maintenance requirements ................. 309
Malfunction indicator la mp ..................... 362
Master warning light .................................. 368
Menu icons........................................................ 78
Meter Changing the main meter location.......77
Clock.......................................................... 70, 73
Indicators...........................................................68
Instrument panel light control......... 72, 76

Alphabetical index459
Tire information ............................................. 410Glossary........................................................... 414
Size...................................................................... 412
Tire identification number ....................... 412
Uniform Tire Quality Grading..............413
Tire pressure warning system ................ 328 Function .......................................................... 328
Initializing ....................................................... 332
Installing tire pressure warning valves and transmitters ........................................331
Registering ID codes ............................... 334
Warning light ...............................................365
Tires................................................................... 326 Chains ............................................................. 252
Checking ....................................................... 326
If you have a flat tire .................................. 375
Inflation pressure........................................ 336
Information ..................................................... 410
Replacing ....................................................... 375
Rotating tires ................................................ 328
Size....................................................................405
Snow tires ........................................................251
Spare tire........................................................ 375
Tire inflation pressu re display function
......................................................................... 328
Tire pressure warning system ............. 328
Warning light ...............................................365
Tools.................................................................. 376
Top tether strap............................................... 53
Total load capacity ...................................... 398
Towing Dinghy towing ............................................... 142
Emergency towing ...................................355
Towing eyelet ............................................. 358
Trailer towing ................................................. 142
TRAC (Traction Control) ........................ 246
Traction Control (TRAC) ........................ 246
Trailer towing .................................................. 142
Transmission Automatic transmission ............................149
Driving Mode Select switch...................210
Paddle shift switches ......................... 151, 152 S mode ............................................................. 152
Trip meters .................................................. 71, 76
Trunk .................................................................... 99 Hands Free Power Trunk Lid............... 102
Internal trunk release lever..................... 103
Power trunk lid ...............................................99
Smart access system with push-button start ................................................................... 101
Trunk closer switch .................................... 102
Trunk easy closer........................................ 103
Trunk features ............................................. 280
Trunk grip ....................................................... 103
Trunk light ....................................................... 103
Trunk opener main switch...................... 105
Trunk opener switch ................................... 101
Trunk storage extension...........................291
Wireless remote control ........................... 101
Trunk light ........................................................ 103
Turn signal lights ............................................153 Replacing light bulbs ................................346
Turn signal lever .......................................... 153
U
USB charging ports.................................... 282
V
Vanity lights......................................................281
Vanity mirrors .................................................281
Vehicle data recordings ..................................6
Vehicle identification number ................ 398
Vehicle Stability Control (VSC) ........... 246
Ventilators (seat ventilators)................... 270
VSC (Vehicle Stability Control) ........... 246
W
Warning buzzersABS ...................................................................363
Airbags............................................................362
Approach warning..................................... 201
Brake hold .................................................... 368

460Alphabetical index
Brake Override System ......................... 363
Brake system .................................................361
Charging system ....................................... 362
Downshifting ....................................... 152, 152
Drive-Start Control .................................. 363
Electric power steering .......................... 363
Engine ............................................................. 362
High coolant temperature ......................361
Intuitive parking assist................... 219, 365
Low engine oil pressure......................... 362
LTA (Lane Tracing Assist)......... 184, 365
Open door..............................................96, 98
Open hood...................................................... 98
Open trunk ...................................................... 98
Open window ...............................................125
PKSA (Parking Support Alert) ............. 213
PKSB (Parking Support Brake) .........366
Pre-collision braking.................................. 177
RCD (Rear Camera Detection) ........366
RCTA (Rear Cross Traffic Alert) ......366
Seat belt .......................................................... 364
Warning lights.................................................361 ABS .................................................................. 363
Brake hold operated indicator ...........368
Brake Override System ......................... 363
Brake system .................................................361
Charging system ....................................... 362
Drive-Start Control .................................. 363
Electric power steering .......................... 363
High coolant temperature ......................361
Intuitive parking assist OFF indicator.........................................................................365
Low engine oil pressure......................... 362
Low fuel level ............................................... 364
LTA indicator ...............................................365
Malfunction indicator lamp................... 362
Master warning light ................................368
Parking brake indicator .......................... 367
PKSB OFF indicator ................................366
Pre-collision system ................................. 367
RCD OFF indicator .................................366
RCTA OFF indicator...............................366 Seat belt reminder light...........................364
Slip indicator ................................................. 367
SRS ....................................................................362
Tire pressure ............................................... 365
Warning messages ....................................... 371
Washer ..............................................................164 Checking .......................................................325
Preparing and checking before winter........................................................................... 251
Switch................................................................ 164
Washing and waxing.................................. 304
Weight Cargo capacity .............................................. 141
Load limits ........................................................ 141
Weight............................................................ 398
Wheel lock key............................................. 376
Wheels ............................................................. 338 Size ................................................................... 405
Window lock switch .....................................125
Windows ........................................................... 124 Power windows ............................................124
Rear window defogger........................... 264
Washer ............................................................ 164
Windshield wiper de-icer ........................ 268
Windshield wipers ........................................164 Position..............................................................167
Rain-sensing windshield wipers .......... 164
Winter driving tips.........................................251
Wireless charger ......................................... 283
Wireless remote control ............................. 93 Battery-Saving Function.......................... 107
Locking/Unlocking ..................................... 93
Replacing the battery .................................341
For information regarding the equipment listed below, refer to
the “NAVIGATION AND MUL-
TIMEDIA SYSTEM OWNER’S
MANUAL”.
