light Lexus GS350 2007 Using the front audio system / LEXUS 2007 GS430/350 QUICK REFERENCE MANUAL

Topic 4
Rain and Night Driving
28
Entering and Exiting
Before DrivingBefore Driving
When Driving
Rain and
Night DrivingRain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Fog Lights
The fog lights can be used only when the head-
lights (low beam) are on.
Windshield Wipers and Washers
nIntermittent wiper with interval adjuster (if equipped)
MIST: operates once
INT: intermittent operation*
LO: low speed
HI: high speed
*: Wiper interval can be adjusted by turning the
band.
To spray washer fluid, pull the lever.
The wipers will operate automatically.
nRain-sensing windshield wipers (if equipped)
MIST: operates once
AUTO: automatic operation*
LO: low speed
HI: high speed
*: Sensitivity can be adjusted by turning the band.
To spray washer fluid, pull the lever.
The wipers will operate automatically

Topic 4
Rain and Night Driving
29
Headlight Cleaner
The headlight cleaner can be used only when the
engine switch is in IG-ON mode and the headlights
are on.
Rear Window and Outside Rear View
Mirror Defoggers
To defog the rear window and outside mirrors,
press the button.
Press again to cancel.

Instrument Panel Light Control
Brighter
Darker
Maximum brightness
Changes the cluster glass tint
The system turns off automatically after 15 minutes.
1
2
3
4

Driving ComfortTopic 5
Touch Screen .......................................................... 31
Air Conditioning System .................................... 32
Audio System ......................................................... 34
Hands-free System .............................................. 36
Ashtrays................................................................... 37
Seat Heaters / Seat Heaters and
Ventilators .............................................................. 38
Console Box ........................................................... 39
Glove Box ............................................................... 40
Cup Holders........................................................... 40
Interior Lights.......................................................... 41
Rear Sunshade ....................................................... 41
Compass................................................................... 41
Luggage Mat.......................................................... 42
Lexus Link System .................................................42

Topic 5
Driving Comfort
41
Interior Lights
ON
OFF
The light comes on if a door is opened.
Rear Sunshade
To raise the rear sunshade, press the switch.
Press the switch again to lower it.
The sunshade automatically lowers to ensure visi-
bility when reversing.
Compass (If Equipped)
To display the compass, press and hold the AUTO
button for 3 or more seconds.
To cancel the display, press and hold the AUTO
button again for 3 or more seconds.
1
2
3

Topic 5
Driving Comfort
43
Emergency button
Makes a priority call to the Lexus Link Call
Center
nServices
The Lexus Link System offers the following services. For details about the services and sub-
scription, refer to the Owner’s Manual or call the Lexus Link Call Center at 1-800-25-
LEXUS (1-800-255-3987) (toll-free).
lAirbag deployment notification
If an airbag deploys, an emergency call is automatically placed to the Lexus Link Call
Center with your vehicle’s location. You do not need to press any buttons.
lEmergency assistance
When you press the Emergency button, a priority call is placed to the Lexus Link Call
Center with your vehicle’s location. At the Call Center, the Lexus Link Advisor can deter-
mine your vehicle’s location, communicate with you, and, if appropriate, contact the near-
est emergency service provider.
lStolen vehicle location assistance
If you vehicle is stolen, call the Lexus Link Call Center and then select the option for
Lexus Link.
lRemote horn/light and remote
door lock/unlock
The remote operations are performed by contacting the Lexus Link Call Center from the
outside of the vehicle. When necessary, call the Lexus Link Call Center and the select
the option for Lexus Link.
lAdvisor record
You can record a conversation with the Lexus Link Advisor.
lPersonal calling
A hands-free personal calling feature can be added to the Lexus Link System as an
option.
lOther services
Press the SERVICES button in the vehicle or call the Lexus Link Call Center and then
select the option for Lexus Link. The services provided will depend on the service plan
level.
5
The system is only operational in GPS (Global Positioning System) and cellular coverage
areas.

Topic 6
Opening and Closing
46
Entering and Exiting
Before DrivingBefore Driving
When Driving
Rain and
Night Driving
Driving Comfort
Opening and ClosingOpening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Powe r Wi n d ows
Powe r w i n d ow s w i t c h e s
To o p e n : press the switch.
To c l o s e : pull the switch up.
Fully pulling up and releasing the switches
causes the windows to close fully. Fully
pressing down and releasing the switches
causes the windows to open fully.
Window lock switch
The window lock switch disables the opera-
tion of all windows other than the driver’s
door window.
Moon Roof (If Equipped)
nOpening and closing
Open
Stops just before it is opened fully. Press the
switch again to fully open.
Close
To stop partway, press the switch lightly.
nTilt up and down
Tilt up
Tilt down
To stop partway, press the switch lightly.
1
2
1
2
1
2

What to do if ...
49
List of Warning/Indicator Lights
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
(U.S.A.)
(Canada)Brake system warning light
Stop the vehicle immediately.
Charging system warning light
Have the vehicle inspected immediately.
(U.S.A.)
(Canada)Malfunction
indicator lampECB*1/VSC warning light
Electric power steering
warning light
SRS warning lightPre-collision system
warning light*2
(U.S.A.)
(Canada)ABS warning light
*1: Electronically Controlled Brake System
For further information, refer to the Owner's Manual.
ILYQ6A00

50
Entering and Exiting
Before Driving
When Driving
Rain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Have the malfunction repaired immediately.
Open door warning light
(On the cen-
ter panel)
Front passenger’s seat belt
reminder light
Low fuel level warning light
Tire pressure warning lighta
(On the
instrument
cluster)
Driver’s seat belt
reminder light
Master warning light
See the Owner's Manual
Tu r n s i g n a l i n d i c a t o rECT PWR indicator
Headlight high beam indicatorCruise control indicator
Headlight indicator (U.S.A.)Damping mode indicator*2
Tail light indicator (Canada)AFS OFF indicator
Fog light indicatorIntuitive parking assist indica-
tor
*2
ECT SNOW indicatorSlip indicator
Shift position and shift range
indicatorsVSC off indicator
*2: If equipped
For further information, refer to the Owner's Manual.

56
Entering and Exiting
Before Driving
When Driving
Rain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
*: Vehicles sold outside Canada
ItemFunctionDefault
settingCustomized
setting
Door lock
Unlocking using a key
Driver's door
unlocked in
one step, all
doors
unlocked in
two steps
All doors
unlocked in
one step.
Speed-detecting automatic
door lock functionOFFON
Opening driver's door unlocks
all doors OFFON
Shift the shift lever to P unlocks
all doors.ONOFF
Shift the shift lever to position
other than P locks all doors.ONOFF
Pow e r w i n d o w s
Linked door lock operationONOFF
Linked door key operationOpen and
closeOpen only
Close only
Wireless remote control linked
operationONOFF
Moon roof
Linked door lock operationONOFF
Linked door key operationOpen and
closeOpen only
Close only
Linked operation of components
when door key is usedSlide onlyTi l t o n l y
Wireless remote control linked
operationONOFF
Linked operation of components
when wireless remote control
used
Slide onlyTi l t o n l y
Automatic light
control system
Light sensor sensitivityLevel 3Levels 1 to 5
Time elapsed before headlights
automatically turn off after
doors are closed
30 seconds
0 seconds
60 seconds
90 seconds
Day time running lightONOFF*

57
Customizing Your Lexus
ItemFunctionDefault
settingCustomized
setting
Windshield
wipers and
washer
Switching operation when the
vehicle is stationaryONOFF
Drip prevention functionONOFF
Time elapsed before the drip
prevention function operates
Va r i a b l e
depending on
the vehicle
speed
3 seconds
Illumination
Time elapsed before lights turn
off15 seconds7. 5 s e c o n d s
30 seconds
Operation when the doors are
unlockedONOFF
Operation after the engine
switch turned OFFONOFF
Foot lightsONOFF
Shift lever lightONOFF
Outer foot lightONOFF
Rear sunshade
Time elapsed before the
reverse operation feature acti-
vates
0.7 seconds
0 seconds
0.9 seconds
1.2 seconds
