fuse Lexus GS350 2008 Using the audio system / LEXUS 2008 GS460/350 (OM30A87U) Owner's Guide

464
4-3. Do-it-yourself maintenance
GS_G_U
May 13, 2008 5:14 pm
■Luggage compartment
FuseAmpereCircuit
1RR S/SHADE7. 5Rear sunshade
2PSB30Pre-collision seat belt
3RR-IG210
4RR-IG110Pre-collision seat belt, seat belt pre-
tensioners, A/P UNIT, rear sunshade
5RR-B10Trunk light, noise filter
6RR FOG7. 5
7STOP LP L10Stoplights, back-up light
8STOP LP R10High mounted stoplights
9RR TAIL10Tail lights, license plate lights, rear
side marker lights

465
4-3. Do-it-yourself maintenance
4
Maintenance and care
GS_G_U
May 13, 2008 5:14 pm
■Luggage compartment 
(vehicles with active stabilizer suspension system)
FuseAmpereCircuit
1STB FR50Front stabilizer
2STB RR30Rear stabilizer
3STB DC/DC30DC/DC converter
■After a fuse is replaced
●If the lights do not turn on even afte r the fuse has been replaced, a bulb may
need replacement. ( P. 4 7 0 )
●If the replaced fuse blows again, have the vehicle inspected by your Lexus
dealer.
■If there is an overload in the circuits
The fuses are designed to blow before the entire wiring harness is damaged.

466
4-3. Do-it-yourself maintenance
GS_G_U
May 13, 2008 5:14 pm
CAUTION
■To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failing to do so may cause damage , and possibly a fire or injury.
●Never use a fuse of a higher amperage rating than indicated, or use any other
object in place of a fuse.
●Always use a genuine Lexus fuse or equivalent. 
Never replace a fuse with a wire, even as a temporary fix. 
This can cause extensive damage or even fire.
●Do not modify fuses or the fuse box.
NOTICE
■Before replacing fuses
Have the cause of electrical overload determined and repaired by your Lexus
dealer.

575
6
Vehicle specifications
GS_G_U
May 13, 2008 5:14 pm
6-3. Initialization
Items to initialize
ItemWhen to initializeReference
Intuitive parking assist
• After reconnecting or changing the battery
• After changing a fuse
P. 5 0 7
Engine oil maintenance
data• After changing engine oilP. 4 1 2
Tire pressure warning
system
• When rotating the tires on vehicles differing with front and rear tire infla-
tion pressures.
• When changing the tire inflation pressure by changing traveling speed
or load weight, etc.
• When changing the tire size.
P. 4 2 3
After reconnecting or performing main tenance on the 12 volt battery, the
following items must be initialized for normal system operation.

587
Alphabetical index
GS_G_U
May 13, 2008 5:14 pm
Front passenger occupant 
classification system ............................92
Front passenger’s seat belt 
reminder light ..................................... 490
Front seats Adjustment .............................................. 45
Driver’s seat position memory ....... 47
Front turn signal lights Wattage ................................................. 552
Fuel Capacity................................................. 543
Fuel gauge .............................................. 132
Gas station information ................. 596
Information............................................ 553
Refueling ................................................... 70
Fuel door......................................................70
Fuel filler door............................................70
Fuses...........................................................442
Garage door opener.......................... 363
Gas station information ..................... 596
Gauges....................................................... 132
Glove box ................................................. 341
Hands-free system 
(for cellular phone)............................ 291
Head restraints........................................... 51
Headlight aim ......................................... 467
Headlight cleaner .................................. 149 Headlights
Adaptive front lighting system...... 143
Discharge headlights 
precautions........................................ 475
Replacing light bulbs ........................470
Switch.........................................................142
Wattage ..................................................552
Heaters Seat heaters ..........................................354
Side mirror............................................. 225
Hill-start assist control ......................... 184
Hood ..........................................................403
Hooks Cargo ..................................................... 360
Shopping bag ..................................... 360
Identification Engine......................................................542
Vehicle ..................................................... 541
Ignition switch Engine switch .......................................... 121
Illuminated entry system .................... 337
I/M test......................................................399
Immobilizer system ................................. 73
Indicator lights......................................... 136
Initialization Items to initialize .................................575
Inside rear view mirror ............................61
Instrument panel light control .......... 133
Interior lights Interior lights ........................................ 338
Wattage ..................................................552
Intuitive parking assist .......................... 164
G
H
I

589
Alphabetical index
GS_G_U
May 13, 2008 5:14 pm
Parking brake ........................................... 131
Parking lightsReplacing light bulbs ....................... 470
Switch ........................................................ 142
Wattage ................................................. 552
Personal lights ....................................... 339
Power outlet ........................................... 353
Power windows.........................................64
Pre-collision system ..............................190
Radar cruise control ............................. 153
Radiator...................................................... 415
Radio ..........................................................229
Radio data system.................................. 231
Rear sunshade........................................357
Rear turn signal lights Replacing light bulbs ....................... 470
Wattage ................................................. 552
Rear view monitor system .................. 179
Rear window defogger .......................225
Replacing Electronic key battery ..................... 440
Fuses .........................................................442
Light bulbs ............................................ 470
Reporting safety defects for 
U.S. owners ......................................... 578
Seat belts Adjusting the seat belt ....................... 53
Automatic locking retractor............ 55
Child restraint system 
installation ............................................ 102
Cleaning and maintaining 
the seat belts..................................... 392
Emergency locking retractor ......... 55
How to wear your seat belt............. 53 How your child should wear

the seat belt ..........................................56
Pre-collision seat belts .......................55
Pregnant women, 
proper seat belt use .........................55
Reminder light .................................... 490
Seat belt extenders ..............................56
Seat belt pretensioners ...................... 54
Seat heaters/ventilators.....................355
Seating capacity ..................................... 198
Seats Adjustment ............................................... 45
Adjustment precautions .................... 46
Child seats/child restraint 
system installation............................ 102
Cleaning .................................................. 391
Driver’s seat position memory ....... 47
Head restraint ...........................................51
Properly sitting in the seat ................ 78
Seat heaters ..........................................354
Service reminder indicators ............. 136
Shift lever Automatic transmission ................... 125
If the shift lever cannot be 
shifted from “P” ................................524
Shift lock system .................................... 524
Shopping bag hooks............................360
Side airbags............................................... 80
Side marker lights Switch.........................................................142
Side mirror Adjusting and folding.......................... 62
Mirror position memory .................... 47P
R
S
