Page 5 of 648
1
2
3
4
5
6
7
5
GS_G_U (OM30C80U)
June 29, 2011 10:30 am
4-1. Maintenance and care
Cleaning and protecting
the vehicle exterior.................. 430
Cleaning and protecting
the vehicle interior .................... 433
4-2. Maintenance
Maintenance
requirements............................... 436
General maintenance ............... 438
Emission inspection and
maintenance (I/M)
programs ....................................... 4414-3. Do-it-yourself maintenance
Do-it-yourself service
precautions .................................. 442
Hood ................................................. 445
Positioning a floor jack............... 446
Engine compartment.................. 448
Tires ................................................... 463
Tire inflation pressure................. 473
Wheels ............................................. 477
Air conditioning filter.................. 479
Electronic key battery ................ 482
Checking and replacing
fuses ................................................ 484
Headlight aim ............................... 509
Light bulbs ........................................ 512
5-1. Essential information
Emergency flashers ................... 520
If your vehicle needs
to be towed ................................... 521
If you think something is
wrong ............................................ 530
Fuel pump shut off system ......... 531
Event data recorder.................... 532
4Maintenance and care
5When trouble arises
Page 9 of 648
9
GS_G_U (OM30C80U)
June 29, 2011 10:30 am
Tire
●Rotation
●Replacement
●Inflation pressure
●Information
P. 463
P. 556
P. 598
P. 604
Tail lights P. 157
Side marker light P. 157
Trunk P. 48
Rear window defogger P. 255
Door P. 43
Fuel filler door P. 82
Turn signal light P. 144
: If equipped
Page 431 of 648
431
4-1. Maintenance and care
4
Maintenance and care
GS_G_U (OM30C80U)
June 29, 2011 10:30 am
■Automatic car washes
●Fold the mirrors back before washing the vehicle.
●Brushes used in automatic car washes may scratch the vehicle surface and
harm your vehicle’s paint.
●Before entering an automatic car wash, check that the fuel filler door is closed.
■High pressure washers
Do not allow the nozzles of the washers to come within close proximity of the win-
dows and fuel filler door.
■Aluminum wheels
●Remove any dirt immediately by using a neutral detergent. Do not use hard
brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners.
Use the same mild detergent and wax as used on the paint.
●Do not use detergent on the wheels when they are hot, for example after driving
for long distance in the hot weather.
●Wash detergent from the wheels immediately after use.
■Bumpers and side moldings
Do not scrub with abrasive cleaners.
CAUTION
■Caution about the exhaust pipe
Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe until it has cooled suffi-
ciently, as touching a hot exhaust pipe can cause burns.
Page 475 of 648
475
4-3. Do-it-yourself maintenance
4
Maintenance and care
GS_G_U (OM30C80U)
June 29, 2011 10:30 am
.
■Tire inflation pressure check interval
You should check tire inflation pressure every 2 weeks, or at least once a month.
If equipped, do not forget to check the spare.
■Effects of incorrect tire inflation pressure
Driving with incorrect tire inflation pressure may result in the following:
●Reduced fuel efficiency
●Reduced driving comfort and tire life
●Reduced safety
●Damage to the drive train
If a tire needs frequent refilling, have it checked by your Lexus dealer.
■Instructions for checking tire inflation pressure
When checking tire inflation pressure, observe the following:
●Check only when the tires are cold.
If your vehicle has been parked for at least 3 hours and has not been driven for
more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure
reading.
●Always use a tire pressure gauge.
The appearance of the tire can be misleading. In addition, tire inflation pressures
that are even just a few pounds off can degrade ride and handling.
●Do not bleed or reduce tire inflation pressure after driving. It is normal for the
tire inflation pressure to be higher after driving.
●Never exceed the vehicle capacity weight.
Passengers and luggage weight should be placed so that the vehicle is bal-
anced.
Page 538 of 648
538
5-2. Steps to take in an emergency
GS_G_U (OM30C80U)
June 29, 2011 10:30 am
■If the malfunction indicator lamp comes on while driving
First check the following:
●Is your vehicle low on gas?
If it is, refuel the vehicle immediately.
●Is the fuel tank cap loose?
If it is, tighten it securely.
The light will go off after taking several driving trips.
If the light does not go off even after several trips, contact your Lexus dealer as soon
as possible.
■Front passenger detection sensor and passenger seat belt reminder
●If luggage is placed on the front passenger seat, the front passenger detection
sensor may cause the warning light to flash, even if a passenger is not sitting in
the seat.
●If a cushion is placed on the seat, the sensor may not detect a passenger, and the
warning light may not operate properly.
■SRS warning light
This warning light system monitors the following:
●The airbag sensor assembly
●Front airbag sensors
●The curtain shield and rear side airbag sensors
●The side and curtain shield airbag sensors
●The front passenger occupant classification ECU
●“AIR BAG ON” and “AIR BAG OFF” indicator lights
●The pressure sensor
●The belt tension sensor
●The seat belt buckle switches
●The driver’s seat position sensor
●The inflators
●The warning light
●The interconnecting wiring and power sources
Page 541 of 648
5
When trouble arises
541
5-2. Steps to take in an emergency
GS_G_U (OM30C80U)
June 29, 2011 10:30 am
CAUTION
■Maintenance of the tires
Each tire, including the spare (if provided), should be checked monthly when cold
and inflated to the inflation pressure recommended by the vehicle manufacturer on
the vehicle placard or tire inflation pressure label (tire and load information label).
(If your vehicle has tires of a different size than the size indicated on the vehicle
placard or tire inflation pressure label [tire and load information label], you should
determine the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire pressure
monitoring system (TPMS-tire pressure warning system) that illuminates a low tire
pressure telltale (tire pressure warning light) when one or more of your tires is sig-
nificantly under-inflated. Accordingly, when the low tire pressure telltale (tire pres-
sure warning light) illuminates, you should stop and check your tires as soon as
possible, and inflate them to the proper pressure. Driving on a significantly under-
inflated tire causes the tire to overheat and can lead to tire failure. Under-inflation
also reduces fuel efficiency and tire tread life, and may affect the vehicle’s handling
and stopping ability.
Please note that the TPMS (tire pressure warning system) is not a substitute for
proper tire maintenance, and it is the driver’s responsibility to maintain correct tire
pressure, even if under-inflation has not reached the level to trigger illumination of
the TPMS low tire pressure telltale (tire pressure warning light).
Your vehicle has also been equipped with a TPMS (tire pressure warning system)
malfunction indicator to indicate when the system is not operating properly. The
TPMS (tire pressure warning system) malfunction indicator is combined with the
low tire pressure telltale (tire pressure warning light). When the system detects a
malfunction, the telltale will flash for approximately one minute and then remain
continuously illuminated. This sequence will continue upon subsequent vehicle
start-ups as long as the malfunction exists. When the malfunction indicator is illumi-
nated, the system may not be able to detect or signal low tire pressure as intended.
TPMS (tire pressure warning system) malfunctions may occur for a variety of rea-
sons, including the installation of replacement or alternate tires or wheels on the
vehicle that prevent the TPMS (tire pressure warning system) from functioning
properly. Always check the TPMS (tire pressure warning system) malfunction tell-
tale after replacing one or more tires or wheels on your vehicle to ensure that the
replacement or alternate tires and wheels allow the TPMS (tire pressure warning
system) to continue to function properly.
Page 557 of 648
5
When trouble arises
557
5-2. Steps to take in an emergency
GS_G_U (OM30C80U)
June 29, 2011 10:30 am
■The compact spare tire
●The compact spare tire is identified by the label “TEMPORARY USE ONLY”
on the tire sidewall.
Use the compact spare tire temporarily only in an emergency.
●Make sure to check the tire inflation pressure of the compact spare tire.
(P. 5 9 8 )
■Tr e a d l i f e
The compact spare tire can be used many times, if necessary. It has tread life of up
to 3000 miles (4800 km) depending on road conditions and your driving habits.
When treadwear indicators appear on the tire, replace the tire. (P. 4 6 3 )
■When using the compact spare tire
As the compact spare tire is not equipped with the tire pressure warning valve and
transmitter, low inflation pressure of the spare tire will not be warned. Also, if you
replace the compact spare tire after the tire pressure warning light comes on, the
light remains on.
■Compact spare tire
The compact tire saves space in your luggage compartment, and its
lighter weight helps to enhance fuel economy and permits easier
installation in case of a flat tire.
The compact spare tire is
designed for temporary emer-
gency use only.
Page 611 of 648
611
6-1. Specifications
6
Vehicle specifications
GS_G_U (OM30C80U)
June 29, 2011 10:30 am
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sureTire pressure when the vehicle has been parked for
three hours or more, or has not been driven more
than 1 mile or 1.5 km under that condition
Maximum inflation pres-
sureThe maximum cold inflated pressure to which a tire
may be inflated, shown on the sidewall of the tire
Recommended inflation
pressureCold tire inflation pressure recommended by a man-
ufacturer
Accessory weight
The combined weight (in excess of those standard
items which may be replaced) of automatic transmis-
sion, power steering, power brakes, power windows,
power seats, radio and heater, to the extent that these
items are available as factory-installed equipment
(whether installed or not)
Curb weight
The weight of a motor vehicle with standard equip-
ment, including the maximum capacity of fuel, oil and
coolant, and if so equipped, air conditioning and
additional weight optional engine
Maximum loaded vehicle
weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant weight150 lb. (68 kg) times the number of occupants speci-
fied in the second column of Table 1
* that follows
Occupant distributionDistribution of occupants in a vehicle as specified in
the third column of Table 1
* below
Page 639 of 648
639
Alphabetical index
GS_G_U (OM30C80U)
June 29, 2011 10:30 am
Tire information
Glossary ....................................................611
Size ........................................................... 607
Tire identification number .............606
Uniform Tire Quality Grading ...609
Tires
Chains ..................................................... 220
Checking ............................................... 463
Compact spare tire .......................... 557
If you have a flat tire............. 556, 566
Inflation pressure ...............................598
Information............................................ 604
Replacing............................................... 556
Rotating tires ........................................ 463
Size ...........................................................598
Snow tires............................................... 222
Tire pressure warning system..... 463
Tools .......................................................... 556
Total load capacity................................. 218
Touch screen ......................................... 228
Towing
Dinghy towing..................................... 225
Emergency towing ........................... 522
Trailer towing........................................224
Traction control .................................... 200
Trip meter.................................................. 147
Trunk
Opener...................................................... 48
Trunk light .................................................49
Wattage ................................................ 600
Turn signal lights
Replacing light bulbs ......................... 512
Switch ........................................................ 144
Wattage ................................................ 600Vanity lights
Vanity lights ..........................................394
Wattage ................................................. 600
Vanity mirrors ........................................ 394
Variable gear ratio steering .............. 201
Vehicle dynamics
integrated management .................. 201
Vehicle identification number .........587
Vehicle load limits ................................. 218
Ventilators .............................................. 400
Warning buzzers
Brake system........................................534
Downshifting ..........................................142
Open door .......................................... 536
Seat belt reminder ............................ 536
Warning lights
Anti-lock brake system .................. 535
Brake system........................................534
Charging system................................534
Electric power steering
warning light .................................... 535
Electronically
controlled brake system ............ 535
Low fuel level ...................................... 536
Malfunction indicator lamp .......... 535
Master warning light.........................537
Open door ........................................... 536
Pre-collision system......................... 535
Seat belt reminder light.................. 536
SRS airbags.......................................... 535
Tire pressure warning light ...........537V
W
Page 643 of 648
643
What to do if...
GS_G_U (OM30C80U)
June 29, 2011 10:30 am
The warning light or indicator
light comes onP. 5 3 4If a warning light turns on or a warning
buzzer sounds...
■Warning lights
or or
P. 5 3 4P. 5 3 5
P. 5 3 6
or
P. 5 3 5P. 5 3 7
P. 5 3 5P. 5 3 7
P. 5 3 6P. 5 3 5
P. 5 3 5P. 5 3 5
P. 5 3 6P. 5 3 6
P. 5 3 4P. 5 3 7
*: Electronically Controlled Brake
System
Brake system warning lightMalfunction indicator lamp
ABS warning lightDriver’s seat belt reminder
light
Front passenger’s seat belt
reminder light
ECB* warning lightTire pressure warning light
Low fuel level warning lightElectric power steering
warning light
SRS warning lightPre-collision system warn-
ing light
Open door warning lightSlip indicator
Charging system warning
lightMaster warning light
