Pcs Lexus GS350 2012 Owner's Manual

3
1
8 7
6
5
4
3
2
GS350/250_EE (OM30C36E)
4-1. Before driving
Driving the vehicle ............ 186
Cargo and luggage............. 197
Trailer towing .................... 198
4-2. Driving procedures
Engine (ignition) switch .... 207
Automatic transmission..... 214
Turn signal lever ............... 222
Parking brake .................... 224
Horn .................................. 227
4-3. Operating the lights and wipers
Headlight switch ............... 228
Automatic High Beam ...... 233
Fog light switch................. 239
Windshield wipers and
washer................................241
Headlight cleaner switch ... 248
4-4. Refueling
Opening the fuel tank cap . 2494-5. Using the driving support
Cruise control .................... 254
Dynamic radar cruise con-
trol.....................................258
LKA (Lane-Keeping
Assist)...............................274
Lexus (parking assist-sen-
sor)....................................284
Lexus (parking assist moni-
tor)....................................297
Driving mode select switch 326
Driving assist systems ....... 331
Hill-start assist control ...... 339
PCS (Pre-Crash Safety sys-
tem)....................................341
BSM (Blind Spot Monitor) 352
4-6. Driving tips
Winter driving tips ............ 359
4Driving

19Pictorial index
GS350/250_EE (OM30C36E)
Driving position memory switches . . . . . . . . . . . . . . . . . . . . . . P. 161
Outside rear view mirror switches . . . . . . . . . . . . . . . . . . . . . . P. 174
Door lock switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 146
Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 178
Window lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 178
PCS OFF switch
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 342
Tire pressure warning reset switch
*. . . . . . . . . . . . . . . . . . . . . P. 675
AFS OFF switch
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 230
*: If equipped
1
2
3
4
5
6
7
8

27Pictorial index
GS350/250_EE (OM30C36E)
AFS OFF switch*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 230
Tire pressure warning reset switch
*. . . . . . . . . . . . . . . . . . . . . P. 675
PCS OFF switch
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 342
Outside rear view mirror switches . . . . . . . . . . . . . . . . . . . . . . P. 174
Driving position memory switches . . . . . . . . . . . . . . . . . . . . . . P. 161
Window lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 178
Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 178
Door lock switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 146
*: If equipped
1
2
3
4
5
6
7
8

952. Instrument cluster
2
Instrument cluster
GS350/250_EE (OM30C36E)Warning lights inform the driver of malfunctions in the indicated
vehicle’s systems.
*1: These lights turn on when the engine switch is turned to IGNITION ON
mode to indicate that a system check is being performed. They will turn
off after the engine is on, or after a few seconds. There may be a malfunc-
tion in a system if the lights do not come on, or turn off. Have the vehicle
Warning lights
*1Brake system warning
light
(P. 749)*1, 2
(if
equipped)
“AFS OFF” indicator
(P. 751)
*1Charging system warn-
ing
light (P. 7 5 0 )*2Parking brake indicator
(P. 751)
*1Malfunction indicator
lamp (P. 750)*1Brake system warning
light (P. 7 5 1 )
*1SRS warning light
(P. 750)Open door warning light
(P. 752)
*1ABS warning light
(P. 750)Low fuel level warning
light (P. 7 5 2 )
*1Electric power steering
system warning light
(P. 751)Seat belt reminder light
(P. 752)
*1, 2
(if
equipped)
“PCS” warning light
(P. 751)
*1
Master warning light
(P. 752)
*1Slip indicator
(P. 751)*1Tire pressure warning
light
(P. 753)

962. Instrument cluster
GS350/250_EE (OM30C36E)
inspected by any authorized Lexus dealer or repairer, or another duly qual-
ified and equipped professional.
*2: The light flashes to indicate a malfunction.
The indicators inform the driver of the operating state of the vehi-
cle’s various systems.
Indicators
Turn signal indicator
(P. 222)Cruise control “SET”
indicator (P. 254)
Tail light indicator
(P. 228)
(if
equipped)
LKA (Lane-Keeping
Assist) indicator
(P. 276)
Headlight high beam
indicator (P. 228)

(if
equipped)
Lexus parking assist-
sensor indicator (P.
285)
(if
equipped)
Automatic High Beam
indicator (P. 233)
*1
(if
equipped)
“AFS OFF” indicator
(P. 230)
(if
equipped)
Front fog light indicator
(P. 239)*1, 2 Slip indicator
(P. 333, 339)
Rear fog light indicator
(P. 239)
*1VSC OFF indicator
(P. 334)
Cruise control indicator
(P. 254)
*1, 3
(if
equipped)
“PCS” warning light
(P. 342)
(if
equipped)
Radar cruise control
indicator (P. 258)Parking brake indicator
(P. 224)

185
4Driving
GS350/250_EE (OM30C36E)
4-1. Before driving
Driving the vehicle............ 186
Cargo and luggage ............ 197
Trailer towing.................... 198
4-2. Driving procedures
Engine (ignition) switch.... 207
Automatic transmission .... 214
Turn signal lever ............... 222
Parking brake .................... 224
Horn .................................. 227
4-3. Operating the lights
and wipers
Headlight switch............... 228
Automatic High Beam ...... 233
Fog light switch ................ 239
Windshield wipers
and washer ...................... 241
Headlight cleaner switch ... 2484-4. Refueling
Opening the fuel tank cap . 249
4-5. Using the driving support
systems
Cruise control ................... 254
Dynamic radar cruise
control ............................. 258
LKA
(Lane-Keeping Assist) .... 274
Lexus
parking assist-sensor....... 284
Lexus
parking assist monitor..... 297
Driving mode select switch326
Driving assist systems ...... 331
Hill-start assist control ...... 339
PCS (Pre-Crash Safety
system)............................ 341
BSM (Blind Spot Monitor) 352
4-6. Driving tips
Winter driving tips ............ 359

3344-5. Using the driving support
GS350/250_EE (OM30C36E)
EPS (Electric Power Steering)
Employs an electric motor to reduce the amount of effort needed
to turn the steering wheel
AVS (Adaptive Variable Suspension system) (if equipped)
By independently controlling the damping force of the shock
absorbers for each of the 4 wheels according to the road and driv-
ing conditions, this system combines riding comfort with supe-
rior steering stability, and ensures good vehicle posture. (P.
328)
VDIM (Vehicle Dynamics Integrated Management)
Provides integrated control of the ABS, brake assist, TRC, VSC,
hill-start assist control and EPS systems
Helps to maintain vehicle stability when swerving on slippery
road surfaces by controlling the brakes, engine output, steering
assist, and steering ratio
PCS (Pre-Crash Safety system) (if equipped)
P. 343
Emergency brake signal
When the brakes are applied suddenly, the stop lights automati-
cally flash to alert the vehicle behind.

3434-5. Using the driving support
4
Driving
GS350/250_EE (OM30C36E)
PCS (Pre-Crash Safety system)
Pre-crash seat belts (front seat only)
If the pre-crash sensor detects that a collision is unavoidable, the
pre-crash safety system will retract the seat belt before the colli-
sion occurs.
The same will happen if the driver makes an emergency braking
or loses control of the vehicle. (P. 40)
Pre-crash brake assist
When there is a high possibility of a frontal collision, the system
applies greater braking force in relation to how strongly the
brake pedal is depressed.
Pre-crash braking
When there is a high possibility of a frontal collision, the system
warns the driver using a warning light, warning display and
buzzer. If the system determines that a collision is unavoidable,
the brakes are automatically applied to reduce the collision
speed.

: If equipped
When the radar sensor detects that a frontal collision is highly
likely or even unavoidable, safety systems such as the brakes and
seat belts are automatically engaged to lessen impact as well as
vehicle damage.
The pre-crash safety system can be turned on and off as necessary
by operating the switch. (P. 344)

3444-5. Using the driving support
GS350/250_EE (OM30C36E)
Suspension control (if equipped)
When the system determines that a collision is unavoidable, the
operation of AVS (P. 334) optimally controls the damping
force of the shock absorber.
Driver monitor system (if equipped)
When the system determines that there is a possibility of a colli-
sion, and either the driver is not facing forward or the driver’s
eyes are closed, PCS warnings are given in advance to warn the
driver. If the system determines that the conditions to operate
pre-crash alert braking have been met even when the possibility
of a collision increases further, pre-crash alert braking will oper-
ate.
Enabled
Disabled
The “PCS” warning light comes on
when pre-crash safety system is
disabled.
Disabling pre-crash safety system
1
2

3484-5. Using the driving support
GS350/250_EE (OM30C36E)
Situations in which the pre-crash safety system does not function properly
The system may not function effectively in situations such as the following:
On roads with sharp bends or uneven surfaces
If a vehicle suddenly moves in front of your vehicle, such as at an intersec-
tion
If a vehicle suddenly cuts in front of your vehicle, such as when overtaking
In inclement weather such as heavy rain, fog, snow or sand storms
When your vehicle is skidding such as the VSC system off
When your vehicle is steeply inclined
Automatic cancelation of the pre-crash safety system
When a malfunction occurs due to sensor contamination, etc. that results in
the sensors being unable to detect obstacles, the pre-crash safety system will
be automatically disabled. In this case, the system will not activate even if
there is a collision possibility.
When there is a malfunction in the system
“PCS” warning light will flash and warning messages will be displayed.
(P. 751, 759)
