rear oil Lexus GS350 2012 Owner's Manual

15Pictorial index
GS350/250_EE (OM30C36E)
Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 241
Precautions against winter season. . . . . . . . . . . . . . . . . . . . . . . P. 359
To prevent freezing (windshield wiper de-icer)
*1 . . . . . . . . . . P. 431
Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . . P. 646
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 249
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 249
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 838
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 672
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 850
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 359
Checking/rotation/tire pressure warning system
*1 . . . . . . . . . P. 672
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 782, 797
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 657
Opening. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 657
Engine compartment cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 661
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 839
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 829
Warning messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 763
Headlights/front position lights/daytime running lights . . . . . . P. 228
Front fog lights
*1/rear fog light*2. . . . . . . . . . . . . . . . . . . . . . P. 239
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 222
Tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 228
Stop lights
Hill-start assist control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 339
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 228
Back-up light
*2
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 214
4
5
6
7
Light bulbs of the exterior lights for driving
(Replacing method: P. 720, Watts: P. 852)
*1: If equipped
*2: They may be located on the opposite side depending on the target region.
8
9
10
11
12
13
14

1303-2. Opening, closing and locking the doors and trunk
GS350/250_EE (OM30C36E)
Conditions affecting operation
The smart entry & start system uses weak radio waves. In the following situ-
ations, the communication between the electronic key and the vehicle may be
affected, preventing the smart entry & start system, wireless remote control
and engine immobilizer system from operating properly. (Ways of coping:
P. 821)
When the electronic key battery is depleted
Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electrical
noise
When carrying a portable radio, cellular phone, cordless phone or other
wireless communication device
When the electronic key is in contact with, or is covered by the following
metallic objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
When other wireless keys (that emit radio waves) are being used nearby
When carrying the electronic key together with the following devices that
emit radio waves
• Another vehicle’s electronic key or a wireless key that emits radio waves
• Personal computers or personal digital assistants (PDAs)
• Digital audio players
• Portable game systems
If window tint with a metallic content or metallic objects are attached to the
rear window

359
4 4-6. Driving tips
Driving
GS350/250_EE (OM30C36E)
Winter driving tips
Use fluids that are appropriate to the prevailing outside tempera-
tures.
• Engine oil
• Engine coolant
• Washer fluid
Have a service technician inspect the condition of the battery.
Have the vehicle fitted with four snow tires or purchase a set of
tire chains for the rear tires.
*
Ensure that all tires are the specified size and brand, and that chains
match the size of the tires.
*: Tire chains cannot be mounted on the 19 inch tires.
Carry out the necessary preparations and inspections before driv-
ing the vehicle in winter. Always drive the vehicle in a manner
appropriate to the prevailing weather conditions.
Preparation for winter

6446-1. Maintenance and care
GS350/250_EE (OM30C36E)
Cleaning and protecting the vehicle exterior
Working from top to bottom, liberally apply water to the vehicle
body, wheel wells and underside of the vehicle to remove any
dirt and dust.
Wash the vehicle body using a sponge or soft cloth, such as a
chamois.
For hard-to-remove marks, use car wash soap and rinse thor-
oughly with water.
Wipe away any water.
Wax the vehicle when the waterproof coating deteriorates.
If water does not bead on a clean surface, apply wax when the vehicle
body is cool.
Automatic car washes
Fold the mirrors before washing the vehicle. Start washing from the front of
the vehicle. Make sure to extend the mirrors before driving.
Brushes used in automatic car washes may scratch the vehicle surface and
harm your vehicle’s paint.
Rear spoiler (if equipped) may not be washable in some automatic car
washes. There may also be an increased risk of damage to vehicle.
High pressure car washes
Do not allow the nozzles of the car wash to come within close proximity of
the windows.
Before using the car wash, check that the fuel filler door on your vehicle is
closed properly.
Perform the following to protect the vehicle and maintain it in
prime condition:

8368-1. Specifications
GS350/250_EE (OM30C36E)
Maintenance data (fuel, oil level, etc.)
*1: Unladen vehicle
*2: Vehicles with 265/35R19 tires
*3:AWD models
Dimensions and weights
Overall length 4850mm (190.9 in.)
Overall width 1840 mm (72.4 in.)
Overall height*12WD 1455 mm (57.3 in.)
AWD 1470 mm (57.9 in.)
Wheelbase 2850 mm (112.2 in.)
Tread*1
Front 1575 mm (62.0 in.)
Rear1590 mm (62.6 in.)
1560 mm (61.4 in.)*2
Gross vehicle
mass2WD 2170 kg (4784 lb.)
AWD 2250 kg (4960 lb.)
Maximum per-
missible axle
capacityFront 1120 kg (2469 lb.)
Rear 1205 kg (2657 lb.)
Drawbar load 80 kg (176 lb.)
Towing capacityWith brake1600 kg (3527 lb.)
1000 kg (2205 lb.)*3
Without brake 750 kg (1653 lb.)

849
8 8-1. Specifications
Vehicle specifications
GS350/250_EE (OM30C36E)
Your Lexus vehicle is filled with “Toyota Genuine Differential Oil” at the
factory.
Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equiva-
lent of matching quality to satisfy the above specification. Please contact any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional for further details.
*: Minimum pedal clearance when depressed with a force of 500 N (51.0
kgf, 112.4 lbf) while the engine is operating.
Front differential (AWD models)
Oil capacity 0.70 L (0.74 qt., 0.62 Imp.qt.)
Oil type and viscosity
Hypoid gear oil API GL-5
Above -18C (0F): SAE90
Below -18C (0F): SAE80W or SAE80W-90
Rear differential
Oil capacityGS2501.15 L (1.22 qt., 1.01 Imp.qt.)
GS3501.35 L (1.43 qt., 1.19 Imp.qt.)
Oil type and viscosity
Toyota Genuine Differential gear oil
LT
75W-85 GL-5 or equivalent
Brakes
Pedal
clearance
*
2WD115 mm (4.5 in.) Min.
AW D126 mm (5.0 in.) Min.
Pedal free play1.0 — 2.0 mm (0.04 — 0.08 in.)
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3
Steering
Free playLess than 30 mm (1.2 in.)

885Alphabetical index
GS350/250_EE (OM30C36E)
“nanoe” system..........................423
Navigation system
*
Odometer .....................................99
Oil
Engine oil .............................839
Front differential oil .............849
Rear differential oil...............849
Opener
Hood .....................................657
Trunk ....................................150
Outer foot lights
Location ................................611
Replacing light bulbs ............731
Wattage .................................853
Outside rear view mirrors..........174
Adjusting and folding ...........174
BSM (Blind Sport Monitor) .354
Linked mirror function
when reversing ...................176
Mirror position memory .......162
Outside rear view mirror
defoggers ...........................430
Outside temperature display ......104
Overheating, Engine ..................830Paddle shift switches ................ 218
Parking assist sensors ............... 284
Parking brake............................ 225
If the parking brake cannot
be released ......................... 819
Operation ............................. 225
Parking brake engaged
warning buzzer .................. 765
Parking brake engaged
warning message ............... 765
PCS
(Pre-Crash Safety system)...... 343
Function ............................... 343
PCS OFF switch .................. 344
Warning light ....................... 751
Warning message. 759, 767, 774
Personal lights .......................... 612
Pollen removal mode ................ 419
Power easy access system ........ 166
Power outlets ............................ 627
Power steering .......................... 334
Warning light ....................... 751
Warning message................. 762
Power trunk lid ......................... 150
Power windows ........................ 178
Door lock linked window
operation............................ 180
Jam protection function ....... 179
Operation ............................. 178
Window lock switch ............ 178
N
O
P
*: For vehicles with a navigation system, refer to the
“Navigation System Owner’s Manual”.
