Page 2 of 914
TABLE OF CONTENTS2
GS350/250_EE (OM30C36E)
For your information...................... 8
Reading this manual .................... 12
How to search .............................. 13
Pictorial index .............................. 14
1-1. For safe use
Before driving ..................... 34
For safety drive ................... 36
Seat belts ............................. 38
SRS airbags ......................... 44
Airbag manual on-off sys-
tem.....................................56
Safety information for chil-
dren...................................58
Child restraint systems ........ 59
Installing child restraints ..... 68
Exhaust gas precautions ...... 79
1-2. Theft deterrent system
Engine immobilizer system. 80
Double locking system ........ 85
Alarm .................................. 86
2. Instrument cluster
Warning lights and indica-
tors.......................................94
Gauges and meters .............. 98
Multi-information display . 101
Head-up display ................ 1093-1. Key information
Keys .................................. 118
3-2. Opening, closing and locking
the doors and trunk
Smart entry & start system 123
Wireless remote control .... 141
Doors ................................. 146
Trunk ................................. 150
3-3. Adjusting the seats
Front seats ......................... 157
Driving position memory .. 161
Head restraints................... 167
3-4. Adjusting the steering wheel and
mirrors
Steering wheel.................170
Inside rear view mirror ...... 171
Outside rear view mirrors . 174
3-5. Opening, closing the windows
and moon roof
Power windows ................. 178
Moon roof ......................... 181
1For safety and security
2Instrument cluster
3Operation of each compo-
nent
Page 58 of 914
581-1. For safe use
GS350/250_EE (OM30C36E)
Safety information for children
It is recommended that children sit in the rear seats to avoid acci-
dental contact with the shift lever, wiper switch etc.
Use the rear door child-protector lock or the window lock switch
to avoid children opening the door while driving or operating the
power window accidentally.
Do not let small children operate equipment which may catch or
pinch body parts, such as the power window, hood, trunk, seats
etc.
Observe the following precautions when children are in the vehi-
cle.
Use a child restraint system appropriate for the child, until the
child becomes large enough to properly wear the vehicle’s seat
belt.
CAUTION
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the windows, the moon roof or other features of the vehicle. In addition,
heat build-up or extremely cold temperatures inside the vehicle can be fatal
to children.
Page 88 of 914
871-2. Theft deterrent system
1
GS350/250_EE (OM30C36E)
For safety and security
Do one of the following to deactivate or stop the alarm:
Unlock the doors or open the trunk using the entry function or
wireless remote control.
Turn the engine switch to ACCESSORY or IGNITION ON
mode, or start the engine. (The alarm will be deactivated or
stopped after a few seconds.)
System maintenance
The vehicle has a maintenance-free type alarm system.
Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of
the following:
Nobody is in the vehicle.
The windows and moon roof (if equipped) are closed before the alarm is
set.
No valuables or other personal items are left in the vehicle.
Deactivating or stopping the alarm
Page 120 of 914
117
3
Operation of
each component
GS350/250_EE (OM30C36E)
3-1. Key information
Keys ...................................118
3-2. Opening, closing and locking
the doors and trunk
Smart entry & start system 123
Wireless remote control .... 141
Doors ................................ 146
Trunk................................. 150
3-3. Adjusting the seats
Front seats ......................... 157
Driving position memory.. 161
Head restraints .................. 167
3-4. Adjusting the steering
wheel and mirrors
Steering wheel .................. 170
Inside rear view mirror ..... 171
Outside rear view mirrors . 174
3-5. Opening, closing the windows
and moon roof
Power windows................. 178
Moon roof ......................... 181
Page 144 of 914
141
3 3-2. Opening, closing and locking the doors and trunk
Operation of each component
GS350/250_EE (OM30C36E)
Wireless remote control
The wireless remote control can be used to lock and unlock the
vehicle.
Locks all the doors
Closes the windows and moon
roof (press and hold)
*
Unlocks all the doors
Opens the windows and moon
roof (press and hold)
*
Opens the trunk
(press and hold)
If the vehicle is equipped with a
power trunk lid, the trunk lid auto-
matically opens fully.
*: These settings must be customized
at any authorized Lexus dealer or
repairer, or another duly qualified
and equipped professional.
Operation signals
Doors:
The emergency flashers flash to indicate that the doors have been locked/
unlocked. (Locked: once; Unlocked: twice)
Windows and moon roof:
A buzzer sounds to indicate that the windows and moon roof are operating.
Welcome light illumination control
P. 1 2 3
Function summary
1
2
3
4
5
Page 148 of 914
1453-2. Opening, closing and locking the doors and trunk
3
Operation of each component
GS350/250_EE (OM30C36E)
For vehicles sold in Montenegro
CAUTION
When closing the windows or moon roof using wireless remote control
Observe the following precautions.
Failing to do so may result in death or serious injury.
Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window or moon roof is
being operated.
To prevent inadvertent power windows and moon roof operation, never let
a small child have and use the wireless remote control.
Jam protection function
Never try jamming any part of your body to activate the jam protection
function intentionally.
The jam protection function may not work if something gets caught just
before the window or moon roof fully closes.
Page 182 of 914
1783-5. Opening, closing the windows and moon roof
GS350/250_EE (OM30C36E)
Power windows
The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:
Closing
One-touch closing
*
Opening
One-touch opening
*
*
: Pushing the switch in the opposite
direction will stop window travel
partway.
Press the switch to lock the pas-
senger window switches.
The indicator will come on.
Use this switch to prevent children
from accidentally opening or clos-
ing a passenger window.
Opening and closing procedures
1
2
3
4
Window lock switch
Indicator
Page 184 of 914
1803-5. Opening, closing the windows and moon roof
GS350/250_EE (OM30C36E)
Door lock linked window operation
The power windows can be opened and closed using the mechanical key.*
(P. 821)
The power windows can be opened and closed using the wireless remote
control.
* (P. 141)
*: These settings must be customized at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional.
When the battery is disconnected
The window lock switch is disabled. If necessary, press the window lock
switch after reconnecting the battery.
Power windows open warning buzzer
The buzzer sounds and a message is shown on the multi-information display
in the instrument cluster when the engine switch is turned off and the driver’s
door is opened with the power windows open.
Customization
Settings (e.g. linked door lock operation) can be changed.
(Customizable features: P. 855)
CAUTION
Observe the following precautions.
Failure to do so may result in death or serious injury.
Closing the windows
Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.
Do not allow children to operate the power windows.
Closing a power window on someone can cause serious injury, and in
some instances, even death.
Jam protection function
Never use any part of your body to intentionally activate the jam protec-
tion function.
The jam protection function may not work if something gets caught just
before the window fully closes.
Page 186 of 914
1823-5. Opening, closing the windows and moon roof
GS350/250_EE (OM30C36E)
The moon roof can be operated when
The engine switch is in IGNITION ON mode.
Operating the moon roof after turning the engine off
The moon roof can be operated for approximately 45 seconds after the
engine switch is turned to ACCESSORY mode or turned off. It cannot, how-
ever, be operated once either front door is opened.
Jam protection function
If an object is detected between the moon roof and the frame while the moon
roof is closing or tilting down, travel is stopped and the moon roof opens
slightly.
Sunshade
The sunshade can be opened and closed manually. However, the sunshade
will open automatically when the moon roof is opened.
Door lock linked moon roof operation
The moon roof can be opened and closed using the mechanical key.* (P.
821)
The moon roof can be opened and closed using the wireless remote con-
trol.
*
(P. 141)
*: These settings must be customized at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional.
Page 188 of 914
1843-5. Opening, closing the windows and moon roof
GS350/250_EE (OM30C36E)
Moon roof open warning buzzer
The buzzer sounds and a message is shown on the multi-information display
in the instrument cluster when the engine switch is turned off and the driver’s
door is opened with the moon roof open.
Customization
Settings (e.g. linked door lock operation) can be changed.
(Customizable features: P. 855)
CAUTION
Observe the following precautions.
Failure to do so may cause death or serious injury.
Opening the moon roof
Do not allow any passengers to put their hands or heads outside the vehi-
cle while it is moving.
Do not sit on top of the moon roof.
Closing the moon roof
Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when the moon roof is being oper-
ated.
Do not allow children to operate the moon roof.
Closing the moon roof on someone can cause death or serious injury.
Jam protection function
Never use any part of your body to intentionally activate the jam protec-
tion function.
The jam protection function may not work if something gets caught just
before the moon roof fully closes.
