wiper fluid Lexus GS350 2012 Owner's Manual

17Pictorial index
GS350/250_EE (OM30C36E)
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 101
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 101
When the warning messages are displayed. . . . . . . . . . . . . . . . P. 757
Parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 224
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 224
Precautions against winter season. . . . . . . . . . . . . . . . . . . . . . . P. 360
Warning buzzer/message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 757
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 222
Headlight switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 228
Headlights/front position lights/tail lights/daytime running lightsP. 228
Front fog lights
*/rear fog light . . . . . . . . . . . . . . . . . . . . . . . . . P. 239
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . . . . P. 241
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 241
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 671
Warning messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 771
Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 738
Trunk opener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 150
Hood lock release lever. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 657
Tilt and telescopic steering control switch . . . . . . . . . . . . . . . . P. 170
Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 170
Driving position memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 161
Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 409
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 409
Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 430
Audio system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 432
Audio system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 432
Hands-free system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 542
Trunk opener main switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 151
*: If equipped
4
5
6
7
8
9
10
11
12
13
14

25Pictorial index
GS350/250_EE (OM30C36E)
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 101
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 101
When the warning messages are displayed. . . . . . . . . . . . . . . . P. 757
Parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 224
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 224
Precautions against winter season. . . . . . . . . . . . . . . . . . . . . . . P. 360
Warning buzzer/message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 757
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 222
Headlight switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 228
Headlights/front position lights/tail lights/daytime running lightsP. 228
Front fog lights
*/rear fog light . . . . . . . . . . . . . . . . . . . . . . . . . P. 239
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . . . . P. 241
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 241
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 671
Warning messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 771
Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 738
Trunk opener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 150
Hood lock release lever. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 657
Tilt and telescopic steering control switch . . . . . . . . . . . . . . . . P. 170
Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 170
Driving position memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 161
Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 409
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 409
Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 430
Audio system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 432
Audio system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 432
Hands-free system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 542
Trunk opener main switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 151
*: If equipped
4
5
6
7
8
9
10
11
12
13
14

2464-3. Operating the lights and wipers
GS350/250_EE (OM30C36E)
Raindrop sensor (vehicles with rain-sensing windshield wipers)
If the wiper is turned to AUTO mode while the engine switch is in IGNI-
TION ON mode, the wipers will operate once to show that AUTO mode is
activated.
If the temperature of the raindrop sensor is 85°C (185°F) or higher, or -
30°C (-22°F) or lower, automatic operation may not occur. In this case,
operate the wipers in any mode other than AUTO mode.
When the windshield wipers are in temporary operation
AUTO mode cannot be activated even if is pressed.
If no windshield washer fluid sprays
Check that the washer nozzles are not blocked if there is washer fluid in the
windshield washer fluid reservoir.
The raindrop sensor judges the amount
of raindrops.
An optical sensor is adopted. It may not
operate properly when sunlight from
the rising or setting of the sun intermit-
tently strikes the windshield, or if bugs
etc. are present on the windshield.
CAUTION
Caution regarding the use of windshield wipers in AUTO mode
The windshield wipers may operate unexpectedly if the sensor is touched
or the windshield is subject to vibration in AUTO mode. Take care that
your fingers or anything else do not become caught in the windshield wip-
ers.
Caution regarding the use of washer fluid
When it is cold, do not use the washer fluid until the windshield becomes
warm. The fluid may freeze on the windshield and cause low visibility.
This may lead to an accident, resulting in death or serious injury.

2474-3. Operating the lights and wipers
4
Driving
GS350/250_EE (OM30C36E)
NOTICE
When the windshield is dry
Do not use the wipers, as they may damage the windshield.
When there is no washer fluid spray from the nozzle
Damage to the washer fluid pump may be caused if the lever is pulled
toward you and held continually.
When a nozzle becomes blocked
In this case, contact any authorized Lexus dealer or repairer, or another
duly qualified and equipped professional.
Do not try to clear it with a pin or other object. The nozzle will be damaged.
When standing the windshield wipers up
Raise the wipers in line with the windshield. (P. 362)
Failure to do so may result in damage to the wipers and/or the hood.

2484-3. Operating the lights and wipers
GS350/250_EE (OM30C36E)
Headlight cleaner switch
Press the switch to clean the
headlights.
The headlight cleaners can be operated when
The engine switch is in IGNITION ON mode and the headlight switch is
turned on.
Windshield washer linked operation
When the windshield washer is operated with the engine switch in IGNI-
TION ON mode and the headlights on, the headlight cleaners will operate
once. (P. 241)
Washer fluid can be sprayed on the headlights.
NOTICE
When the washer fluid tank is empty
Do not press the switch continually as the washer fluid pump may overheat.

891Alphabetical index
GS350/250_EE (OM30C36E)
Warning buzzers
Approach warning ................264
Brake system ........................749
Downshifting ........................221
Key reminder ........................777
Lexus parking assist-sensor ..284
No-handed driving warning..279
Open door .............................763
Open hood ............................763
Open moon roof....................764
Open trunk ............................764
Open window .......................764
Pre-crash braking ..................343
Seat belt reminder .................752
Warning lights .............................95
ABS ......................................750
AFS OFF indicator ...............751
Brake system ................749, 751
Charging system ...................750
Electric power steering
system.................................751
Low fuel level .......................752
Malfunction indicator lamp ..750
Master warning light ............752
Open door .............................752
Parking brake indicator.........751
Pre-Crash Safety system .......751
Seat belt reminder light ........752
Slip indicator ........................751
SRS .......................................750
Tire pressure warning light...753Warning messages .................... 757
Warning reflector storage belt .. 623
Washer ...................................... 241
Checking .............................. 671
Low washer fluid warning
message ............................. 771
Preparing and checking
before winter ..................... 359
Switch .................................. 241
Washing and waxing ................ 644
Weight ...................................... 836
Welcome light illumination
control .................................... 123
Wheels ...................................... 693
Replacing ............................. 693
Size ...................................... 850
Window glasses ........................ 178
Window lock switch ................. 178
Windows................................... 178
Power windows.................... 178
Rear window defogger......... 430
Windshield wiper de-icer ......... 431
Windshield wipers .................... 241
Intermittent wiper with interval
adjuster .............................. 241
Position ................................ 362
Rain-sensing windshield
wipers ................................ 243
Winter driving tips.................... 359
Wireless remote control key ..... 141
Battery-Saving Function ...... 129
Locking/Unlocking .............. 141
Replacing the battery ........... 697
WMA disc ................................ 469
