window Lexus GS350 2013 Opening, closing and locking the doors and trunk / LEXUS 2013 GS350 QUICK GUIDE OWNERS MANUAL (OM30C68U)
[x] Cancel search | Manufacturer: LEXUS, Model Year: 2013, Model line: GS350, Model: Lexus GS350 2013Pages: 94, PDF Size: 2.07 MB
Page 2 of 94
2
GS350_QG_U (OM30C68U)
Headlights ............................................................................................................................................... 27
Head-up Display................................................................................................................ ...................25
Intuitive Parking Assist ....................................................................................................... ............... 38
Keys............................................................................................................................................................... 9
Lexus Enform with Safety Connect ............................................................................................. 80
Lexus Night View ............................................................................................................... .................. 44
LKA (Lane-Keeping Assist)...................................................................................................... .......40
Moon Roof ...................................................................................................................... ....................... 86
Multi-information Display ...................................................................................................... ...........23
Navigation System
Register home .................................................................................................................. ................ 51
Destination input - Search by address .................................................................................. 52
Destination input - Search points of interest by name....................................................54
Destination input - Search points of interest by category.............................................55
Destination input - Search points of intere st by telephone number .........................56
Parking Brake.................................................................................................................. ....................... 22
Portable Audio Device Ports.................................................................................................... ........76
Power Windows .................................................................................................................. ................. 85
Rear Air Conditioning System
Front controller ................................................................................................................................ 71
Remote Touch ................................................................................................................... ..................... 47
Safety Connect ................................................................................................................. .................... 78
Seat Heaters/Seat Ventilators ........................... ............................................................................. 72
Smart Access System with Push-button Start........ ................................................................... 10
Theft Deterrent System ......................................................................................................... ............. 12
Tire Pressure Warning System ................................................................................................... ..... 46
Trunk .......................................................................................................................... ............................... 88
Turn Signal Lever .............................................................................................................. ..................... 21
Voice Command System
Basic operation ............................................................................................................................... 73
Command list ................................................................................................................... ................74
Windshield Wipers and Washer ................................................................................................... .29
XM Services.................................................................................................................... .......................82
Page 3 of 94
3
GS350_QG_U (OM30C68U)
OverviewInstrument Panel
Windshield wiper and washer switch P.29
Multi-information display P.23
Headlight switch Turn signal lever
Fog light switch
*1
P.27
P.21
Inside lock buttons P.83
Trunk opener P.88
Hood lock release lever*1
Driving position memory switches
P.14
See P.6
See P.5
Window lock switch P.85
Outside rear view mirror switches
*1
Power window switches
P.85
Door lock switches P.83
Pre-collision braking off switch*1
Tire pressure warning reset switch P.46
AFS OFF switch P.28
Page 10 of 94
10
GS350_QG_U (OM30C68U)
■Wireless remote control
Locks all the doors
Unlocks all the doors
Pressing the button unlocks the driver’s
door. Pressing the button again within
5 seconds unlocks the other doors.
Opens the windows and moon roof
(press and hold)
*
Opens the trunk (press and hold)
If the vehicle is equipped with a power
trunk opener and closer, the trunk lid
automatically opens fully.
Sounds the alarm (press and hold)
*: This setting must be customized at your
Lexus dealer.
Smart Access System with Push-button Start
■ Entering the vehicle
Grip the driver’s door handle to unlock the
door. Grip the passenger’s door handle to
unlock all the doors.
Make sure to touch the sensor on the
back of the handle.
The doors cannot be unlocked for 3 sec-
onds after the doors are locked.
1
2
3
4
5
The following operations can be performed simp ly by carrying the electronic key on your
person, for example in your pocket. (The driver should always carry the electronic key.)
For details on starting the engine, see page 15.
Page 68 of 94
68
GS350_QG_U (OM30C68U)
Front Air Conditioning System
Without rear air conditioning system
With rear air conditioning system
Outside temperature
Passenger’s side temperature control
Passenger’s side temperature display
Front seat air outlet selector
Windshield wiper de-icer
Micro dust and pollen filter
Outside air or recirculated mode
Rear window and outside rear view
mirror defoggers
S-FLOW mode
Off
Automatic mode
Driver’s side temperature displayDriver’s side temperature control
Windshield defogger
DUAL mode
Cooling and dehumidification func-
tion on/off
Fan speed control
Air flows to the feet and the wind-
shield defogger operates
Rear air conditioning operation
screen
Passenger’s side air outlet selector
3-ZONE mode
Driver’s side air outlet selector1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
Page 85 of 94
85
GS350_QG_U (OM30C68U)
Powe r Wi n d ows
■Po w e r w i n d o w s w i t c h e s
Closing
One-touch closing
*
Opening
One-touch opening
*
*
: Pushing the switch in the opposite direc-
tion will stop window travel partway.
■ Window lock switch
Press the switch down to lock the passen-
ger window.
The indicator will come on.
Use this switch to prevent children from
accidentally opening or closing a pas-
senger window.
1
2
3
4
Indicator
Page 87 of 94
87
GS350_QG_U (OM30C68U)
Fuel Tank Cap
■Before refueling the vehicle
● Close all the doors and windows, and turn the engine switch off.
● Confirm the type of fuel.
■Opening the fuel tank cap
With the doors unlocked, press the
center of the rear ed ge of the fuel filler
door.
Push until you hear a click and take
your hand away to slightly open the fuel
filler door. Then open the door fully by
hand.
Turn the fuel tank cap slowly to open.
Hang the fuel tank cap on the back of
the fuel filler door.1
2
3
Page 91 of 94
What to do if...
91
GS350_QG_U (OM30C68U)
If the electronic key does not operate properly
■Unlocking and locking the doors
Use the mechanical key in order to perform
the following operations:
Locks all the doors
Closes the windows and moon roof
*
(turn and hold)
Unlocks all the doors
Turning the key rearward unlocks the
driver’s door. Turning the key once
again within 5 seconds unlocks the
other doors.
Opens the windows and moon roof
*
(turn and hold)
*: This setting must be customized at your Lexus dealer.
■ Unlocking the trunk
Turn the mechanical key clockwise to open.
1
2
3
4
