4-1. Before driving
NOTICE
■When encountering flooded roads
Do not drive on a road that has flooded after heavy rain etc. Doing so may cause
the following serious damage to the vehicle:
●Engine stalling
●Short in electrical components
●Engine damage caused by water immersion
In the event that you drive on a flooded road and the vehicle is flooded, be sure to
have your Lexus dealer check the following:
●Brake function
●Changes in quantity and quality of oil and fluid used for the engine, transmission,
transfer (AWD models), differential, etc.
●Lubricant condition for the propeller shaft, bearings and suspension joints (where
possible), and the function of all joints, bearings, etc.

GS350_U (OM30C34U)
7578-1. Specifications
8
Vehicle specifications
*: The fluid capacity is the quantity of reference.If replacement is necessary, contact your Lexus dealer.
Electrical system
Battery
Open voltage at 68 F
(20 C):
Specific gravity reading
at 68 F (20 C):12.6  12.8 V Fully charged
12.2
 12.4 V Half charged
11.8  12.0 V Discharged
(Voltage is checked 20 mi nutes after the engine and
all lights are turned off.)
1.250
 1.290 Fully charged
1.160
 1.200 Half charged
1.060
 1.100 Discharged
Charging rates
Quick charge
Slow charge15 A max.
5 A max.
Automatic transmission
Fluid capacity*2WD8.3 qt. (7.9 L, 7.0 Imp.qt.)
AW D10.6 qt. (10.0 L, 8.8 Imp.qt.)
Fluid typeTo y o t a G e n u i n e AT F W S
NOTICE
■Automatic transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterio-
ration in shift quality, locking up of yo ur transmission accompanied by vibration,
and ultimately damage the tr ansmission of your vehicle.

811Alphabetical index
GS350_U (OM30C34U)
Armrest door ......................................... 575
Ashtrays.................................................... 563
Assist grip .................................................577
Audio input.............................................. 476
Audio system.......................................... 367Audio input............................................ 476
AUX port/USB port.................... 476, 456, 466
Bluetooth
® audio...............................444
CD/DVD player ..................................412
CD/DVD player information ...... 432
DVD video ............................................420
iPod ...........................................................464
MP3/WMA disc ................................ 414
Optimal use .......................................... 474
Portable music player ...................... 476
Radio ....................................................... 390
Rear seat audio controls ................ 477
Steering wheel audio switch ........482
USB memory .......................................454
Automatic headlight leveling system ......................................................193
Automatic light control system ..................................................... 190
Automatic transmission .......................178 If the shift lever cannot be shifted from P ............ 737
M mode ..................................................... 181
Paddle shift switches .........................180
AUX port................................................. 476
Auxiliary boxes ...................................... 557
AVS (Adaptive Variable Suspension system).......................... 269 Back-up lights
Replacing light bulbs ....................... 670
Wattage ................................................... 761
Battery .......................................................624 Battery checking ................................ 624
If the vehicle battery is discharged .................................... 743
Preparing and checking before winter.................................................... 298
Warning light ....................................... 687
Bluetooth
®
Audio system ....................................... 444
Hands-free system (for cellular phone) .......................485
Brake Fluid .......................................................... 623
Parking brake ....................................... 186
Warning light ..........................686, 689
Warning message............................. 697
Brake assist ............................................. 268
Break-in tips ............................................. 156
Brightness control Instrument panel light control ........80
BSM (Blind Spot Monitor) ................287
