481-1. For safe use
GS350_U (OM30C34U)
■Adult*1
■Child*3 or child restraint system*4
Condition and operation in the front passenger occupant classifi-
cation system
Indicator/
warning light
“AIR BAG ON” and “AIR BAG OFF” indicator lights“A I R B A G O N ”
SRS warning lightOff
Seat belt reminder lightFlashing*2
Devices
Front passenger airbag
Activated
Side airbag
on the front passenger seat
Curtain shield airbag
in the front passenger side
Front passenger knee airbag
Front passenger’s seat belt pretensioner
Indicator/
warning light
“AIR BAG ON” and “AIR BAG OFF” indicator lights“A I R B A G OFF”
*5
SRS warning lightOff
Seat belt reminder lightFlashing*2
Devices
Front passenger airbagDeactivated
Side airbag
on the front passenger seat
ActivatedCurtain shield airbag
in the front passenger side
Front passenger knee airbagDeactivated
Front passenger’s seat belt pretensionerActivated

491-1. For safe use
GS350_U (OM30C34U)
1
For safety and security
■Unoccupied
■There is a malfunction in the system
Indicator/
warning light
“AIR BAG ON” and “AIR BAG OFF” indicator lights“AIR BAG OFF”
SRS warning light
Off
Seat belt reminder light
Devices
Front passenger airbagDeactivated
Side airbag
on the front passenger seat
ActivatedCurtain shield airbag
in the front passenger side
Front passenger knee airbagDeactivated
Front passenger’s seat belt pretensionerActivated
Indicator/
warning light
“AIR BAG ON” and “AIR BAG OFF” indicator lights“AIR BAG OFF”
SRS warning light
On
Seat belt reminder light
Devices
Front passenger airbagDeactivated
Side airbag
on the front passenger seat
ActivatedCurtain shield airbag
in the front passenger side
Front passenger knee airbagDeactivated
Front passenger’s seat belt pretensionerActivated

511-1. For safe use
GS350_U (OM30C34U)
1
For safety and security
CAUTION
■Front passenger occupant classification system precautions
●Do not recline the front passenger seatback so far that it touches a rear seat. This
may cause the “AIR BAG OFF” indicator light to be illuminated, which indicates
that the passenger’s airbags will not deploy in the event of a severe accident. If the
seatback touches the rear seat, return th e seatback to a position where it does
not touch the rear seat. Keep the front passenger seatback as upright as possible
when the vehicle is moving. Reclining the seatback excessively may lessen the
effectiveness of the seat belt system.
●If an adult sits in the front passenger seat, the “AIR BAG ON” indicator light is illu-
minated. If th e “AIR BAG OFF” indicator is illumi nated, ask the passenger to sit
up straight, well back in the seat, feet on the floor, and with the seat belt worn cor-
rectly. If the “AIR BAG OFF” indicator stil l remains illuminated, either ask the pas-
senger to move to the rear seat, or if that is not possible, move the front passenger
seat fully rearward.
●When it is unavoidable to install a forward-facing child restraint system on the
front passenger seat, install the child rest raint system on the front passenger seat
in the proper order. ( P. 5 7 )
●Do not modify or remove the front seats.
●Do not kick the front passenger seat or subject it to severe impact. Otherwise,
the SRS warning light may come on to indi cate a malfunction of the detection sys-
tem. In this case, contact your Lexus dealer immediately.
●Child restraint systems installed on the rear seat should not contact the front seat-
backs.
●Do not modify or replace the upholstery of the front seat.

73
GS350_U (OM30C34U)
Instrument cluster2
2. Instrument cluster Warning lights and indicators ............................... 74
Gauges and meters ..................... 79
Multi-information display .......... 82
Head-up display ............................ 90

74
GS350_U (OM30C34U)
2. Instrument cluster
Warning lights and indicators
◆Instrument cluster
The units used on the speedometer and some indicators may differ depending on
the target region.
◆Center panel
The warning lights and indicators on the instrument cluster and center
panel inform the driver of the status of the vehicle’s various systems.
For the purpose of explanation, th e following illustration displays all
warning lights and indicators illuminated.

GS350_U (OM30C34U)
752. Instrument cluster
2
Instrument cluster
Warning lights inform the driver of malfunctions in the indicated vehicle’s
systems.
Warning lights
*1
(U.S.A.)
Brake system warning light
(  P. 686)*1
Slip indicator ( P. 6 8 8 )
*1
(Canada)
Brake system warning light
( P. 686)*1, 2
(if equipped)
“AFS OFF” indicator
( P. 6 8 8 )
*1Charging system warning
light ( P. 6 8 7 )*2
(U.S.A.)
Parking brake indicator
( P. 688)
*1
(U.S.A.)
Malfunction indicator
lamp ( P. 6 8 7 )*2
(Canada)
Parking brake indicator
( P. 6 8 8 )
*1
(Canada)
Malfunction indicator
lamp ( P. 6 8 7 )*1Brake system warning light
( P. 6 8 9 )
*1SRS warning light
( P. 6 8 7 )*1Open door warning light
( P. 6 8 9 )
*1
(U.S.A.)
ABS warning light
( P. 6 8 7 )*1Low fuel level warning light
( P. 6 8 9 )
*1
(Canada)
ABS warning light
( P. 6 8 7 )*1Seat belt reminder light
( P. 6 8 9 )
*1Electric power steering
system warning light
( P. 6 8 7 )*1Master warning light
( P. 6 8 9 )

76
GS350_U (OM30C34U)
2. Instrument cluster
*1: These lights turn on when the engine switch is turned to IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine
is on, or after a few seconds. There may be a malfunction in a system if the lights
do not come on, or turn off. Have the vehicle inspected by your Lexus dealer.
*2: The light flashes to indicate a malfunction.
*1, 2
(if equipped)
“PCS” warning light
(  P. 6 8 7 , 7 0 2 )*1
Tire pressure warning light
( P. 6 9 0 )

GS350_U (OM30C34U)
772. Instrument cluster
2
Instrument cluster
The indicators inform the driver of the operating state of the vehicle’s vari-
ous systems.
Indicators
Turn signal indicator
(  P. 1 8 4 )
(if equipped)
LKA (Lane-Keeping
Assist) indicator
( P. 2 2 8 )
(U.S.A.)
Headlight indicator
( P. 1 9 0 )

(if equipped)
Intuitive parking assist indi-
cator ( P. 2 3 8 )
(Canada)
Tail light indicator
( P. 1 9 0 ) *1
(if equipped)
“AFS OFF” indicator
( P. 1 9 2 )
Headlight high beam indi-
cator ( P. 1 9 1 )
*1, 2 Slip indicator
( P. 270, 276)
(if equipped)
Front fog light indicator
( P. 195)*1VSC OFF indicator
( P. 2 76 )
Cruise control indicator
(  P. 2 0 9 , 2 1 3 )
*1, 3
(if equipped)
“PCS” warning light
( P. 2 8 0 )
(if equipped)
Radar cruise control indi-
cator ( P. 2 1 3 )
(U.S.A.)
Parking brake indicator
( P. 1 8 6 )
Cruise control “SET” indi-
cator ( P. 2 0 9 , 2 1 3 )
(Canada)
Parking brake indicator
( P. 1 8 6 )
*1“A I R B A G O N /
OFF” indicator
( P. 4 7 )

78
GS350_U (OM30C34U)
2. Instrument cluster
*1: These lights turn on when the engine switch is turned to IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine
is on, or after a few seconds. There may be a malfunction in a system if the lights
do not come on, or turn off. Have the vehicle inspected by your Lexus dealer.
*2: The light flashes to indicate that the system is operating.
*3: The light comes on when the system is turned off. The light flashes faster than
usual to indicate that the system is operating.
CAUTION
■If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning light not come on
when you start the engine, this could mean that these systems are not available to
help protect you in an accident, which coul d result in death or serious injury. Have
the vehicle inspected by your Lexus dealer immediately if this occurs.

188
GS350_U (OM30C34U)
4-2. Driving procedures
■When there is a malfunction in the system
Warning lights and/or warning message will turn on or flash. (P. 6 8 8 , 7 0 1 )
Depending on the condition, the parking brake indicator light may flash.
■Usage in winter time
 P. 2 9 9
NOTICE
■When parking the vehicle
Before you leave the vehicle, set the parking brake, shift the shift lever to P and
make sure that the vehicle does not move.
■When the system malfunctions
Stop the vehicle in a safe place and check the warning messages.
■When the parking brake cannot be released due to a malfunction
Use the parking brake release tool to manually release the parking brake.
( P. 7 3 8 )
Driving the vehicle with the parking brake set will lead to brake components over-
heating, which may affect braking performance and increase brake wear.
