Head-up Display (if equipped)
Head-up display
“HUD” button
Display position adjustment switch
Display brightness adjustment switch
“DISP” button
■ Head-up display contents
● Vehicle speed
● Tachometer
● Shift position and shift range
● Eco Driving Indicator
● Audio display
● Route guidance display (vehic les with navigation system)
● Lane departure warning display (LKA [Lane-Keeping Assist]) (if equipped)
● Approach warning display (dynamic radar cruise control) (if equipped)
● Pre-collision braking warning message (pre-collision system) (if equipped)
The head-up display can be used to project vehicle speed and other information onto the
windshield.
1
2
3
4
5

26
GS350_QG_U (OM30C68U)
Eco Driving Indicator
■Eco Driving Indicator Zone Display
Eco driving ratio based on accelera-
tion
If the acceleration exceeds Zone of
Eco driving, the right side of Eco Driv-
ing Indicator Zone Display blinks.
Zone of Eco driving
Eco Driving Indicator will not operate in the
following conditions:
● The shift lever is anything other than D.
● Paddle shift switch is operated.
● Neither normal mode nor Eco drive
mode is selected.
● The vehicle speed is approximately 80
mph (130 km/h) or higher.1
2

35
GS350_QG_U (OM30C68U)
Dynamic Radar Cruise Control (if equipped)
Vehicle-to-vehicle distance button
Display
Set speed
Indicators
Cruise control switch
■Setting the vehicle speed (vehicle-to-vehicle distance control mode)
Press the “ON-OFF” button to activate
the cruise control.
Radar cruise control indicator will
come on.
Press the button again to deactivate
the cruise control.
Accelerate or decelerate the vehicle to
the desired speed, and push the lever
down to set the speed.
“SET” indicator will be displayed.
The vehicle speed at the moment the
lever is released becomes the set
speed.
Dynamic radar cruise control supplements conventional cruise control with a vehicle-to-
vehicle distance control. In vehicle-to-vehicle distance control mode, the vehicle automat-
ically accelerates or decelerate s in order to maintain a set following distance from vehi-
cles ahead.
1
2
3
4
5
1
2

38
GS350_QG_U (OM30C68U)
Intuitive Parking Assist (if equipped)
■Turning the system on and off
Turns the intuitive parking assist on/off
When on, the indicator light comes on
and the buzzer sounds to inform the
driver that the syst em is operational.
The distance from your vehicle to nearby ob stacles when parallel parking or maneuver-
ing into a garage is measured by the sens ors and communicated via the multi-informa-
tion display, Remote touch screen and a buzzer. Always check the surrounding area
when using this system.

40
GS350_QG_U (OM30C68U)
LKA (Lane-Keeping Assist) (if equipped)
Lane departure warning function
If the system judges that the vehicle may deviate from its lane, it alerts the driver using
beeping, screen displays and a sensory warning
* given via the steering wheel.
*: A slight steering torque is applied for a short period of time in the direction of the center of the lane.
Lane keeping assist function
• This function will be active when the vehicl e-to-vehicle distance control mode of the
cruise control is set with vehicle speed above approximately 45 mph (72 km/h) and
while the lane departure wa rning function is active.
• When the lane keeping assist function is acti ve, a slight steering torque will be applied,
to help the driver maintain the vehicle inside the lane.
■ Tu r n i n g t h e L K A s y s t e m o n
Press the “LKA” switch to activate the sys-
tem.
“LKA” indicator will come on.
Press the switch again to turn the LKA
system off.
The LKA system will revert to off each
time the engine switch is turned to
IGNITION ON mode.
While driving on a freeway or motor highway that has lane markers and no sharp curves,
the system recognizes the lanes using a came ra located above the inside rear view mir-
ror as a sensor to assist the driver with st aying in the lane. The LKA system has two func-
tions.
1
2

41
GS350_QG_U (OM30C68U)
■Indication on the multi-information display
When the LKA system is on, the lane line display and steering wheel display are shown.
Lane keeping assist function operation
indication
Steering wheel displayed: 
Indicates that the function is currently
operating.
Steering wheel not displayed: 
Indicates that the function is not cur-
rently operating.
Dynamic radar cruise control display
Lane departure warning function indi-
cation (when the inside of the white line
is white):
The function has recognized lane
markers.
Lane departure warning function indi-
cation (when the inside of the white line
is black):
A lane marker is not recognized by the
system, or the LKA system functions
are temporarily canceled.
1
2
3
4

42
GS350_QG_U (OM30C68U)
Driving Mode Select Switch
■Vehicles without AVS
Normal mode
For normal driving.
Press the switch to change the driving mode to normal mode when selected to Eco
mode or sport mode.
Eco drive mode
Use Eco mode to help achieve low fuel cons umption during trips that involve frequent
accelerating.
When the driving mode select switch is tu rned left, the “ECO MODE” indicator comes
on in the multi-information display.
Sport mode
An acceleration response suitable for sports driving is provided by controlling steering
response and transmission. Suitable for when precise handling is desirable, for example
when driving on mountain roads.
When the driving mode select switch is turned right, the “SPORT” indicator comes on
in the instrument cluster.
The driving modes can be select ed to suit driving condition.
1
2
3

43
GS350_QG_U (OM30C68U)
■Ve h i c l e s w i t h AV S
Normal mode
For normal driving.
Press the switch to change the driving mode to normal mode when selected to Eco
mode or sport mode.
Eco drive mode
Use Eco mode to help achieve low fuel cons umption during trips that involve frequent
accelerating.
When the driving mode select switch is turned left, the “ECO MODE” indicator comes
on in the multi-information display.
Sport mode
•SPORT S mode Improves acceleration response by contro lling the transmission. Suitable for when
precise handling is desirable, for example when driving on mountain roads.
When the driving mode select switch is turned right while a made other than SPORT
S mode is selected, the “SPORT S” indicator comes on in the instrument cluster.
•SPORT S+ mode Improves steering performance and driving st ability by simultaneously controlling the
steering and suspension in addition to th e transmission. Suitable for sporty driving.
When the driving mode select switch is turned right while SPORT S mode is selected,
the “SPORT S+” indicator comes on in the instrument cluster.1
2
3

44
GS350_QG_U (OM30C68U)
Lexus Night View (if equipped)
■Displaying the Lexus night view
Turn the engine switch to IGNITION ON mode.
The headlights turn on
Press the Lexus night view switch
The Lexus night view is displayed on the
Remote Touch screen.
To return the screen to its previous state,
press the switch again.
When the light sensor determines that it is
currently night time from the brightness of
the surrounding area, the Lexus night view
can be operated by pressing the Lexus
night view switch while the headlights are
on.
Lexus night view is a system which assists with nighttime driving. Near-infrared rays are
irradiated forward and an image converted from the irradiated light is shown on the
Remote Touch screen. The image shows pede strians, obstacles, and road conditions
ahead of the vehicle, which are difficult to see at nighttime with the naked eye.
1
2
3

45
GS350_QG_U (OM30C68U)
■The Lexus night view display
● When displaying on the “Main Display”
Lexus night view screen
“Side Display” switching button
Brightness adjustment button
● When displaying on the “Side Display”
When another screen is displayed on the
“Main Display” while the Lexus night view is
being shown on the “Main Display”, the
Lexus night view screen will be displayed on
the “Side Display”.
Lexus night view screen
“Main Display” switching button
1
2
3
1
2
