cruise control Lexus GS350 2013 Using the driving support systems / LEXUS 2013 GS350 OWNERS MANUAL (OM30C34U)

3
1
8 7
6
5
4
3
2
GS350_U (OM30C34U)
4-1. Before drivingDriving the vehicle ......................154
Cargo and luggage.....................165
Vehicle load limits ....................... 168
Trailer towing .................................169
Dinghy towing ............................... 170
4-2. Driving procedures Engine (ign ition) switch .............. 171
Automatic transmission ............ 178
Turn signal lever ........................... 184
Parking brake ............................... 186
Horn ................................................. 189
4-3. Operating the lights and wipers
Headlight switch ......................... 190
Fog light switch .............................195
Windshield wipers and washer ..................................196
Headlight cleaner switch........ 203
4-4. Refueling Opening the fuel tank cap ..... 204 4-5. Using the driving support
systems
Cruise control ............................. 209
Dynamic radar cruise control..............................213
LKA (Lane-Keeping Assist) .......... 228
Intuitive parking assist .............. 238
Rear view monito r system ........251
Driving mode select switch ... 263
Driving assist systems .............. 268
Hill-start assist control .............. 276
PCS (Pre-Collision System) ..........278
BSM (Blind Spot Monitor) ..............287
Lexus night view ......................... 293
4-6. Driving tips Winter driving tips ..................... 298
4Driving

GS350_U (OM30C34U)
9
The installation of a mobile two-way radio system in your vehicle could affect elec-
tronic systems such as:
●Multiport fuel injection system/sequential multiport fuel injection system
●Dynamic radar cruise control system
●Cruise control system
●Anti-lock brake system
●Vehicle dynamics integrated management
●SRS airbag system
●Seat belt pretensioner system
Be sure to check with your Lexus dealer for precautionary measures or special
instructions regarding installation of a mobile two-way radio system.
Your Lexus equipped with several sophisticated computers that will record certain
data, such as: •Engine speed
• Accelerator status
•Brake status
• Vehicle speed
• Shift position
The recorded data varies according to the vehicle grade level and options equipped
with. Furthermore, these computers do not record conversations, sounds or pictures.
● Data usage
Lexus may use the data recorded in these computers to diagnose malfunctions,
conduct research and development, and improve quality.
Lexus will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if the
vehicle is leased
• In response to an official request by the police, a court of law or a government agency
• For research purposes where the data is not tied to a specific vehicle or vehicle owner
● Usage of data collected through Safety Connect / Lexus Enform (U.S. mainland
only)
If your Lexus has Safety Connect or Lexus Enform and if you have subscribed to
those services, please refer to the Safety Connect / Lexus Enform Telematics Sub-
scription Service Agreement for informat ion on data collected and its usage.
Installation of a mobile two-way radio system
Vehicle data recording

20Pictorial index
GS350_U (OM30C34U)
Audio remote control switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 482
Paddle shift switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 180
Back switch
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 334
Ta l k s w i t c h
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 334
Telephone switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 486
“DISP” button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 8 3
Vehicle-to-vehicle distance button
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 216
Cruise control switch
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 209
Dynamic radar cruise control switch
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 213
Tilt and telescopic steering control switch . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 139
LKA (Lane-Keeping Assist) switch
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 230
1
2
3
4
5
6
7
8
9
10

GS350_U (OM30C34U)
772. Instrument cluster
2
Instrument cluster
The indicators inform the driver of the operating state of the vehicle’s vari-
ous systems.
Indicators
Turn signal indicator
(  P. 1 8 4 )
(if equipped)
LKA (Lane-Keeping
Assist) indicator
( P. 2 2 8 )
(U.S.A.)
Headlight indicator
( P. 1 9 0 )

(if equipped)
Intuitive parking assist indi-
cator ( P. 2 3 8 )
(Canada)
Tail light indicator
( P. 1 9 0 ) *1
(if equipped)
“AFS OFF” indicator
( P. 1 9 2 )
Headlight high beam indi-
cator ( P. 1 9 1 )
*1, 2 Slip indicator
( P. 270, 276)
(if equipped)
Front fog light indicator
( P. 195)*1VSC OFF indicator
( P. 2 76 )
Cruise control indicator
(  P. 2 0 9 , 2 1 3 )
*1, 3
(if equipped)
“PCS” warning light
( P. 2 8 0 )
(if equipped)
Radar cruise control indi-
cator ( P. 2 1 3 )
(U.S.A.)
Parking brake indicator
( P. 1 8 6 )
Cruise control “SET” indi-
cator ( P. 2 0 9 , 2 1 3 )
(Canada)
Parking brake indicator
( P. 1 8 6 )
*1“A I R B A G O N /
OFF” indicator
( P. 4 7 )

82
GS350_U (OM30C34U)
2. Instrument cluster
Multi-information display
The multi-information display presents the driver with a variety of driving-
related data including the cu rrent outside air temperature.
●Eco Driving Indicator (P. 8 8 )
●Outside temperature display
( P. 8 3 )
●Trip information ( P. 8 3 )
Displays driving range, fuel consump-
tion and other cruising related infor-
mation
●
Tire inflation pressure
(if equipped) ( P. 6 3 9 )
●Drive monitor ( P. 8 5 )
●Intuitive parking assist display*
(if equipped) ( P. 240)
●Dynamic radar cruise control dis-
play
* (if equipped)
( P. 213)
●LKA (Lane-Keeping Assist) dis-
play
* (if equipped) ( P. 232)
●Warning messages ( P. 6 9 7 )
Automatically displayed when a mal-
function occurs in one of the vehicle’s
systems. Display can be switched by
pressing the “DISP” button. ( P. 8 3 )
*: Automatically displayed when the sys-
tem is used. Display can be switched
by pressing the “DISP” button.
( P. 8 3 )
Display contents

GS350_U (OM30C34U)
912. Instrument cluster
2
Instrument cluster
●Vehicle speed
●Tachometer
●Shift position and shift range
Displays the selected shift position or selected shift range ( P. 1 7 8 )
●
Eco Driving Indicator ( P. 8 3 )
●Audio display
Displays audio information for approximately 3 seconds when the audio system is
operated
●
Route guidance display (vehicles with navigation system) (P. 9 4 )
When approaching an intersection while the navigation system is giving route
guidance, an arrow will automatically be displayed to indicate the direction of
travel.
●
Lane departure warning display (LKA [Lane-Keeping Assist])
(if equipped) ( P. 7 0 9 )
●Approach warning display (dyn amic radar cruise control)
(if equipped) ( P. 7 0 8 )
●Pre-collision braking warning message (pre-collision system)
(if equipped) ( P. 6 9 9 )
Head-up display contents

153
GS350_U (OM30C34U)
Driving4
4-1. Before driving Driving the vehicle ...................... 154
Cargo and luggage .................... 165
Vehicle load limits ....................... 168
Trailer towing ................................. 169
Dinghy towing............................... 170
4-2. Driving procedures Engine (ignition) switch .............. 171
Automatic transmission ............ 178
Turn signal lever ........................... 184
Parking brake ................................ 186
Horn.................................................. 189 4-3. Operating the lights
and wipers
Headlight switch.......................... 190
Fog light switch ............................ 195
Windshield wipers and washer.................................. 196
Headlight cleaner switch ........ 203
4-4. Refueling Opening the fuel tank cap ..... 204
4-5. Using the driving support systems
Cruise control .............................209
Dynamic radar cruise control ............................. 213
LKA (Lane-Keeping Assist) .......... 228
Intuitive parking assist ..............238
Rear view monitor system ....... 251
Driving mode select switch ... 263
Driving assist systems............... 268
Hill-start assist control .............. 276
PCS (Pre-Collision System).......... 278
BSM (Blind Spot Moni tor).............. 287
Lexus night view ......................... 293
4-6. Driving tips Winter driving tips .....................298

209
GS350_U (OM30C34U)4-5. Using the driving support systems
4
Driving
Cruise control
Use the cruise control to maintain a set speed without depressing the
accelerator pedal.
Indicators
Cruise control switch
Press the “ON-OFF” button to
activate the cruise control.
Cruise control indicator will come on.
Press the button again to deactivate
the cruise control.
Accelerate or decelerate the
vehicle to the desired speed, and
push the lever down to set the
speed.
“SET” indicator will come on.
The vehicle speed at the moment the
lever is released becomes the set
speed.
: If equipped
Summary of functions
1
2
Setting the vehicle speed
1
2

GS350_U (OM30C34U)
2114-5. Using the driving support systems
4
Driving
■Cruise control can be set when
●The shift lever is in D.
●Range 4 or higher of D has been selected by using the paddle shift.
●Vehicle speed is above approximately 25 mph (40 km/h).
■Accelerating after setting the vehicle speed
●The vehicle can be accelerated normally. After acceleration, the set speed
resumes.
●Even without canceling the cruise control, the set speed can be increased by first
accelerating the vehicle to the desired speed and then pushing the lever down to
set the new speed.
■Automatic cruise control cancelation
Cruise control will stop maintaining the vehicle speed in any of the following situa-
tions.
●Actual vehicle speed falls more than approximately 10 mph (16 km/h) below the
preset vehicle speed.
At this time, the memorized set speed is not retained.
●Actual vehicle speed is below approximately 25 mph (40 km/h).
●VSC is activated.
●TRAC is activated for a period of time.
●When the VSC or TRAC system is turn ed off by pressing the VSC OFF switch.
■If the warning message for the cruise control is shown on the multi-information dis-
play
Press the “ON-OFF” button once to deactivate the system, and then press the but-
ton again to reactivate the system.
If the cruise control speed cannot be set or if the cruise control cancels immediately
after being activated, there may be a malfunction in the cruise control system. Have
the vehicle inspected by your Lexus dealer.

212
GS350_U (OM30C34U)
4-5. Using the driving support systems
CAUTION
■To avoid operating the cruise control by mistake
Switch the cruise control off using the “ON-OFF” button when not in use.
■Situations unsuitable for cruise control
Do not use cruise control in any of the following situations.
Doing so may result in loss of control and could cause an accident resulting in
death or serious injury.
●In heavy traffic
●On roads with sharp bends
●On winding roads
●On slippery roads, such as those covered with rain, ice or snow
●On steep hills
Vehicle speed may exceed the set speed when driving down a steep hill.
●During emergency towing
