GS350_U (OM30C34U)
772. Instrument cluster
2
Instrument cluster
The indicators inform the driver of the operating state of the vehicle’s vari-
ous systems.
Indicators
Turn signal indicator
(  P. 1 8 4 )
(if equipped)
LKA (Lane-Keeping
Assist) indicator
( P. 2 2 8 )
(U.S.A.)
Headlight indicator
( P. 1 9 0 )

(if equipped)
Intuitive parking assist indi-
cator ( P. 2 3 8 )
(Canada)
Tail light indicator
( P. 1 9 0 ) *1
(if equipped)
“AFS OFF” indicator
( P. 1 9 2 )
Headlight high beam indi-
cator ( P. 1 9 1 )
*1, 2 Slip indicator
( P. 270, 276)
(if equipped)
Front fog light indicator
( P. 195)*1VSC OFF indicator
( P. 2 76 )
Cruise control indicator
(  P. 2 0 9 , 2 1 3 )
*1, 3
(if equipped)
“PCS” warning light
( P. 2 8 0 )
(if equipped)
Radar cruise control indi-
cator ( P. 2 1 3 )
(U.S.A.)
Parking brake indicator
( P. 1 8 6 )
Cruise control “SET” indi-
cator ( P. 2 0 9 , 2 1 3 )
(Canada)
Parking brake indicator
( P. 1 8 6 )
*1“A I R B A G O N /
OFF” indicator
( P. 4 7 )

GS350_U (OM30C34U)
1914-3. Operating the lights and wipers
4
Driving
With the headlights on, push the
lever away from you to turn on
the high beams.
Pull the lever toward you to the center
position to turn the high beams off.
Pull the lever toward you and
release it to flash the high beams
once.
You can flash the high beams with the
headlights on or off.
Turning on the high beam headlights
1
2

GS350_U (OM30C34U)
2954-5. Using the driving support systems
4
Driving
■When displaying on the “Side Display”
When another screen is displayed on
the “Main Display” while the Lexus
night view is being shown on the
“Main Display”, the Lexus night view
screen will be displayed on the “Side
Display”.
Lexus night view screen
“Main Display” switching but-
ton
Switches the Lexus night view from
the “Side Display” to the “Main Dis-
play”.
■Imaging range
The image is shown ranging from the ti p of the low beam to the high beam.
■If the vehicle speed is less than approximately 9 mph (15 km/h) when the Lexus
night view is operating
An image will be displayed on the Lexus night view screen, but both the range and
the distance of the projection will be limi ted as near-infrared rays are not being radi-
ated outward.
■When the Lexus night view switch is pressed while the Lexus night view cannot be
operated
Advice information will be displayed on the Lexus night view screen. Follow the dis-
played advice.
■If the Lexus night view switch is pressed at a time when the Lexus night view opera-
tion is not possible
Follow the advice displayed on the Remote Touch screen.
■When the shift lever is shifted to R wh ile the Lexus night view is operating
The Lexus night view screen switches as follows.
“Main Display”: Switches to the rear view monitor system screen.
“Side Display”: The display blacks out and no image is displayed.
1
2
