light Lexus GS350 2013 Using the driving support systems / LEXUS 2013 GS350 QUICK GUIDE OWNERS MANUAL (OM30C68U)

2
GS350_QG_U (OM30C68U)
Headlights ............................................................................................................................................... 27
Head-up Display................................................................................................................ ...................25
Intuitive Parking Assist ....................................................................................................... ............... 38
Keys............................................................................................................................................................... 9
Lexus Enform with Safety Connect ............................................................................................. 80
Lexus Night View ............................................................................................................... .................. 44
LKA (Lane-Keeping Assist)...................................................................................................... .......40
Moon Roof ...................................................................................................................... ....................... 86
Multi-information Display ...................................................................................................... ...........23
Navigation System
Register home .................................................................................................................. ................ 51
Destination input - Search by address .................................................................................. 52
Destination input - Search points of interest by name....................................................54
Destination input - Search points of interest by category.............................................55
Destination input - Search points of intere st by telephone number .........................56
Parking Brake.................................................................................................................. ....................... 22
Portable Audio Device Ports.................................................................................................... ........76
Power Windows .................................................................................................................. ................. 85
Rear Air Conditioning System
Front controller ................................................................................................................................ 71
Remote Touch ................................................................................................................... ..................... 47
Safety Connect ................................................................................................................. .................... 78
Seat Heaters/Seat Ventilators ........................... ............................................................................. 72
Smart Access System with Push-button Start........ ................................................................... 10
Theft Deterrent System ......................................................................................................... ............. 12
Tire Pressure Warning System ................................................................................................... ..... 46
Trunk .......................................................................................................................... ............................... 88
Turn Signal Lever .............................................................................................................. ..................... 21
Voice Command System
Basic operation ............................................................................................................................... 73
Command list ................................................................................................................... ................74
Windshield Wipers and Washer ................................................................................................... .29
XM Services.................................................................................................................... .......................82

3
GS350_QG_U (OM30C68U)
OverviewInstrument Panel
Windshield wiper and washer switch P.29
Multi-information display P.23
Headlight switch Turn signal lever
Fog light switch
*1
P.27
P.21
Inside lock buttons P.83
Trunk opener P.88
Hood lock release lever*1
Driving position memory switches
 P.14
See P.6
See P.5
Window lock switch P.85
Outside rear view mirror switches
*1
Power window switches
P.85
Door lock switches P.83
Pre-collision braking off switch*1
Tire pressure warning reset switch P.46
AFS OFF switch P.28

5
GS350_QG_U (OM30C68U)
OverviewInstrument Panel
Odometer/trip meter and trip meter reset button*1
Instrument panel light control switches*1
Headlight cleaner switch*1
VSC OFF switch*1
HUD (Head-up display) switches P.25
Heated steering wheel switch*1
BSM (Blind Spot Monitor) main switch P.39

8
GS350_QG_U (OM30C68U)
OverviewRoof
: If equipped
*1: Refer to “Owner’s Manual”.
Moon roof switches 
P.86
Personal lights*1
“SOS” button P.78
Garage door opener switches P.76
Interior light*1Vanity lights*1

12
GS350_QG_U (OM30C68U)
Theft Deterrent System
■Engine immobilizer system
The indicator light flashes after the engine
switch has been turned off to indicate that
the system is operating.
The indicator light stops flashing after the
engine switch has been turned to ACCES-
SORY or IGNITION ON mode to indicate
that the system has been canceled.
■Alarm
The alarm uses light and sound to give an alert when an intrusion is detected.
To set the alarm:
Close the doors, trunk and hood, and lock all th e doors. The system will be set automatically
after 30 seconds. The indicator light changes from being on to flashing when the system is set.
To deactivate or stop the alarm:
● Unlock the doors or open the trunk.
● Turn the engine switch to ACCESSORY or IGNITION ON mode, or start the engine.
(The alarm will be deactivated or stopped after a few seconds.)

22
GS350_QG_U (OM30C68U)
Parking Brake
■Manual mode
Sets the parking brake
Releases the parking brake
Operate the parking brake switch
while depressing the brake pedal.
Make sure that the parking brake indi-
cator light goes off.
■Automatic mode
The parking brake is set or released automa tically according to shift lever operation.
Tu r n s a u t o m a t i c m o d e o n /o f f
● When the shift lever is moved out of P,
the parking brake will be released.
● When the shift lever is moved into P, the
parking brake will be set.
Operate the shift lever with the brake
pedal depressed.
U.S.A. Canada
1
2

27
GS350_QG_U (OM30C68U)
Headlights
The side marker, parking, tail,
license plate and instrument
panel lights turn on.
The headlights and all the lights
listed above turn on.
The headlights, daytime run-
ning lights and all the lights
listed above turn on and off
automatically. (When the
engine switch is in IGNITION
ON mode.)
Off
The daytime running lights turn
on.
■ Turning on the high beam headlights
With the headlights on, push the lever
away from you to turn on the high
beams.
Pull the lever toward you to the center
position to turn the high beams off.
Pull the lever toward you and release it
to flash the high beams once.
You can flash the high beams with the
headlights on or off.
(Canada)
(U.S.A.)
1
2
3
4
(U.S.A.)
(Canada)
1
2

28
GS350_QG_U (OM30C68U)
■AFS (Adaptive Front-lighting System) (if equipped)
AFS (Adaptive Front-lighting System) secures ex cellent visibility at intersections and on
curves by automatically adjusting the direction of the light axis of the headlights according
to vehicle speed and the degree of the tire’s angle as controlled by steering input.
Turns the AFS on/offThe indicator turns on when the AFS is
deactivated.

38
GS350_QG_U (OM30C68U)
Intuitive Parking Assist (if equipped)
■Turning the system on and off
Turns the intuitive parking assist on/off
When on, the indicator light comes on
and the buzzer sounds to inform the
driver that the syst em is operational.
The distance from your vehicle to nearby ob stacles when parallel parking or maneuver-
ing into a garage is measured by the sens ors and communicated via the multi-informa-
tion display, Remote touch screen and a buzzer. Always check the surrounding area
when using this system.

40
GS350_QG_U (OM30C68U)
LKA (Lane-Keeping Assist) (if equipped)
Lane departure warning function
If the system judges that the vehicle may deviate from its lane, it alerts the driver using
beeping, screen displays and a sensory warning
* given via the steering wheel.
*: A slight steering torque is applied for a short period of time in the direction of the center of the lane.
Lane keeping assist function
• This function will be active when the vehicl e-to-vehicle distance control mode of the
cruise control is set with vehicle speed above approximately 45 mph (72 km/h) and
while the lane departure wa rning function is active.
• When the lane keeping assist function is acti ve, a slight steering torque will be applied,
to help the driver maintain the vehicle inside the lane.
■ Tu r n i n g t h e L K A s y s t e m o n
Press the “LKA” switch to activate the sys-
tem.
“LKA” indicator will come on.
Press the switch again to turn the LKA
system off.
The LKA system will revert to off each
time the engine switch is turned to
IGNITION ON mode.
While driving on a freeway or motor highway that has lane markers and no sharp curves,
the system recognizes the lanes using a came ra located above the inside rear view mir-
ror as a sensor to assist the driver with st aying in the lane. The LKA system has two func-
tions.
1
2
