display Lexus GS350 2014 Using the air conditioning system and defogger / LEXUS 2014 GS350 QUICK GUIDE (OM30D73U) Owner's Guide

64
GS350_QG_OM30D73U_(U)
■Calling using SMS/MMS message
Press the “MENU” button on the
Remote Touch.
Please refer to P.49 for the Remote
To u c h o p e r a t i o n .
Select “Phone”.
Select “Messages”.
Select “SMS/MMS” tab.
Select the desired received message
from the displayed list.
Press on the steering wheel.21
2
3
4
5
6
3
The tab display may vary depending on the type of cellular phone.

65
GS350_QG_OM30D73U_(U)
■Receiving a call
When a call is received, this screen is
displayed with a sound.
Press on the steering wheel to
talk on the phone.
To refuse the call, press on the steer-
ing wheel.
■Steering switches
Sending/Receiving/“Phone” screen
display
End call/Refuse call
Start the voice command system
Return to the previous screen
Increases/decreases volume
11
2
2
1
2
3
4
5

66
GS350_QG_OM30D73U_(U)
Audio System
■Audio control screen
Follow the procedure below to display the audio control screen.
Press the “MENU” button on the
Remote Touch.
Please refer to page 49 for the Remote
To u c h o p e r a t i o n .
The “Menu” screen will be displayed.
Using the Remote Touch, select
“Radio” or “Media” and select each tab.
■Side Display (vehicles with a navigation system)
Operations such as selecting a preset sta-
tion or track are carried out on the screen.
Changing the audio sources
Station selector/selecting a track/file/
chapter
■Remote control (steering wheel switches)
Some audio features can be controlled using the switches on the steering wheel.
Radio mode: Selects a radio station
Audio CD mode: Selects a track
MP3/WMA disc mode: Selects a file
and folder
DVD mode: Selects a chapter
iPod mode: Selects a song
Increases/decreases volume
Turns the power on, selects an audio
source
1
2
1
2
1
2
3

69
GS350_QG_OM30D73U_(U)
■Playing a DVD
Image display (full screen)
Reverse
Stop
Playback/pause
Fast for ward
Chapter selection
DVD eject
■Operating an iPod
Shuffle playback
Repeat play
Playback/pause
Select play mode
Song selection
■Rear seat audio controls (if equipped)
Some front audio features can be controlled from the rear seats.
Preset station or folder etc.
Track or file etc.
Vo l u m e
Audio sources
Pow e r
1
2
3
4
5
6
7
1
2
3
4
5
1
2
3
4
5

70
GS350_QG_OM30D73U_(U)
Front Air Conditioning System
Without rear air conditioning system
With rear air conditioning system
Outside temperature
Passenger’s side temperature control
Passenger’s side temperature display
Front seat air outlet selector
Windshield wiper de-icer
Micro dust and pollen filter
Outside air or recirculated mode
Rear window and outside rear view
mirror defoggers
S-FLOW mode
Off
Automatic mode
Driver’s side temperature displayDriver’s side temperature control
Windshield defogger
DUAL mode
Cooling and dehumidification func-
tion on/off
Fan speed control
Air flows to the feet and the wind-
shield defogger operates
Rear air conditioning operation
screen
Passenger’s side air outlet selector
3-ZONE mode
Driver’s side air outlet selector1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22

71
GS350_QG_OM30D73U_(U)
■Side Display (vehicles with a navigation system)
Without rear air conditioning system
Operations such as changing the air outlets
or fan speed are carried out on the screen.
Fan speed control
Passenger’s side temperature control
Passenger’s side temperature display
DUAL mode
Automatic mode
Cooling and dehumidification function
on/off
Driver’s side temperature display
Driver’s side temperature control
Front seat air outlet selector
Passenger’s side air outlet selector
3-ZONE mode
Driver’s side air outlet selector With rear air conditioning system
1
2
3
4
5
6
7
8
9
10
11
12

73
GS350_QG_OM30D73U_(U)
Rear Air Conditioning System (if equipped)
Air outlet mode display
Temperature display
Temperature control
Air outlet selector
Off
Automatic mode
■Front controller
Temperature control
Off
Automatic mode
Disabling the switches on the rear arm-
rest
1
2
3
4
5
6
1
2
3
4

74
GS350_QG_OM30D73U_(U)
Seat Heaters/Seat Ventilators (if equipped)
■Front seat heaters and ventilators (if equipped)/rear seat heaters (if
equipped)
The seat can be warmed and air from the seat can improve ventilation.
Front seats
Seat heater switches
The indicator light (yellow) on the
switch comes on when the seat
heater is operating.
Seat ventilator switches (front seats
only)
The indicator light (green) on the
switch comes on when the seat ven-
tilator is operating.
Level indicator lights
The seat heater temperature level
or the seat ventilator fan speed level
(for front seats only) is displayed.
“AUTO” indicator lights Rear seats1
2
3
4

77
GS350_QG_OM30D73U_(U)
■Command list
Set a Destination (vehicles with a navigation system)
*1: For example; Gas stations, Restaurants, etc.
*2: To use this function, say “Main menu” and then “Set a destination” while the “Shortcut
Menu” screen is being displayed.
Use the Phone
*: To use this function, say “Main menu” and then “Use the phone” while the “Shortcut
Menu” screen is being displayed.
CommandAction
“Find Nearby ”Displays a list of near the current
position.
“Enter an Address”Enables setting a destination by saying the address.
“Go Home”Displays the route to home.
“Call Destination Assist”Connects Lexus Enform with Safety Connect
response center.
“Destination by Phone Num-
ber”
*2Enables setting a destination by saying the phone
number.
CommandAction
“Call ”
Calls made by saying a name from the phonebook.
For example: Say “Call John Smith”, “Call John Smith,
mobile” etc.
“Dial ”Calls made by saying the phone number.
For example: Say “Dial 911”, “Dial 5556667777” etc.
“International Call”*Calls international numbers by saying the phone
number.

78
GS350_QG_OM30D73U_(U)
Play Music
*1: Say the desired artist name or album name in the place of the “<>”.
*2: To use this function, say “Main menu” and then “Play music” while the “Shortcut Menu”
screen is being displayed.
Get Information (vehicles with a navigation system)
Navigation command (When destinations are set) (vehicles with a navigation system)
CommandAction
“Play Artist ”Plays tracks by the selected artist.
For example: Say “Play artist ”
*1
“Play Album ”Plays tracks from the selected album.
For example: Say “Play album ”
*1
“Play Song ”*2Plays the selected track.
For example: Say “Play song Summertime”, “Play
song Concerto in A Major” etc.
“Play Playlist ”*2Plays tracks from the selected playlist.
For example: Say “Play playlist My Favorite Songs”,
“Play Playlist Classic Hits” etc.
CommandAction
“Traffic”Displays the traffic incident list.
“Weather”Displays weather information.
“Sports Scores”Displays the sports list.
“Stock Quotes”Displays the stocks list.
“Fuel Prices”Displays the fuel prices list.
“Lexus Insider”Displays the Lexus insider list.
CommandAction
“Delete next destination”Deletes the next destination.
“Pause guidance”Pauses the route guidance.
“Resume guidance”Resumes the route guidance.
