remove seats Lexus GS350 2015 TIPS FOR THE NAVIGATION SYSTEM / LEXUS 2015 GS350 FROM MAR. 2015 PROD. OWNERS MANUAL (OM30F69U)

531-1. For safe use
GS350_OM_OM30F69U_(U)
1
For safety and security
CAUTION
■Front passenger occupant classification system precautions
●Do not recline the front passenger seatback so far that it touches a rear seat. This
may cause the “AIR BAG OFF” indicator light to be illuminated, which indicates
that the SRS airbags for the front passenger will not activate in the event of a
severe accident. If the seatback touches the rear seat, return the seatback to a
position where it does not touch the rear seat. Keep the front passenger seatback
as upright as possible when the vehicle is moving. Reclining the seatback exces-
sively may lessen the effectiveness of the seat belt system.
●If an adult sits in the front passenger seat, the “AIR BAG ON” indicator light is illu-
minated. If th e “AIR BAG OFF” indicator is illumi nated, ask the passenger to sit
up straight, well back in the seat, feet on the floor, and with the seat belt worn cor-
rectly. If the “AIR BAG OFF” indicator stil l remains illuminated, either ask the pas-
senger to move to the rear seat, or if that is not possible, move the front passenger
seat fully rearward.
●When it is unavoidable to install a forward-facing child restraint system on the
front passenger seat, install the child rest raint system on the front passenger seat
in the proper order. ( P. 5 9 )
●Do not modify or remove the front seats.
●Do not kick the front passenger seat or subject it to severe impact. Otherwise,
the SRS warning light may come on to indicate a malfunction of the front passen-
ger occupant classification system. In this case, contact your Lexus dealer imme-
diately.
●Child restraint systems installed on the rear seat should not contact the front seat-
backs.
●Do not use a seat accessory, such as a cushion and seat cover, that covers the
seat cushion surface.
●Do not modify or replace the upholstery of the front seat.

631-1. For safe use
GS350_OM_OM30F69U_(U)
1
For safety and security
While pushing the child
restraint system down into the
rear seat, allow the shoulder
belt to retract until the child
restraint system is securely in
place.
After the shoulder belt has
retracted to a point where there is
no slack in the belt, pull the belt to
check that it cannot be extended.
■Forward-facing Convertible seat
Rear outboard seats:
Remove the head restraint.
Place the child restraint system
on the seat facing the front of
the vehicle.
4
1
2

661-1. For safe use
GS350_OM_OM30F69U_(U)Rear outboard seats:
Remove the head restraint.
Secure the child restraint system
using the seat belt or LATCH
anchors.
Open the anchor bracket cover,
latch the hook
onto the anchor
bracket and tighten the top tether
strap.
Make sure the top tether strap is
securely latched.
■Laws and regulations pertaining to anchorages
The LATCH system conforms to FMVSS225 or CMVSS210.2.
Child restraint systems conforming to FM VSS213 or CMVSS213 specifications can
be used.
This vehicle is designed to conform to the SAE J1819.
Child restraint systems with a top tether strap
1
2
3

144
GS350_OM_OM30F69U_(U)
3-3. Adjusting the seats
■Adjusting the height of the head restraints
■Adjusting the rear seat head restraint
Always raise the head restraint one level from the stowed position when using. Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.
CAUTION
■Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to do so
may result in death or serious injury.
●Use the head restraints designed for each respective seat.
●Adjust the head restraints to the correct position at all times.
●After adjusting the head restraints, push down on them and make sure they are
locked in position.
●Do not drive with the head restraints removed.

GS350_OM_OM30F69U_(U)
3035-2. Using the air conditioning system and defogger
5
Interior features
■Option control screen
Select on the operation screen to display the option control
screen. The functions can be switched on and off.
Select to set cooling and de humidification function on/off
Vehicles without rear air conditioning system:
The temperature for the driver’s an d front passenger’s seats can be
adjusted separately (DUAL mode) ( P. 305)
Vehicles with rear air conditioning system:
The temperature for the driver’s, fr ont passenger’s and rear seats
( P. 319) can be adjusted separately (3-ZONE mode) ( P. 305)
Prevent ice from building up on the windshield and wiper blades
(if equipped) ( P. 325)
Remove pollen from the air (Micro dust and pollen filter) ( P. 313)
Without rear air conditioning sys-
temWith rear air conditioning sys-
tem
1
2
3
4

GS350_OM_OM30F69U_(U)
3135-2. Using the air conditioning system and defogger
5
Interior features
Select on the operation screen to display the option control
screen.
Operate micro dust and pollen
filter on/off.
Outside air mode switches to
(recirculated air) mode. Pollen is
removed from the air and the air flows
to the upper part of the body.
Usually the system will turn off auto-
matically after approximately 1 to 3
minutes.
Operates S-FLOW mode on/off.
When the S-FLOW mode button is
pressed, the airflow changes as fol-
lows.
Without rear air conditioning system:
Air flows to the front seats only.
*
With rear air conditioning system:
Air flows to the front seats only, and if
the passenger seat is unoccupied, the
set temperature, outside humidity and
temperature inside the cabin are
assessed, and air flows to the driver
seat only.
*
*
: Air may also flow to the rear seats depending on the situation.
Micro dust and pollen filter button
1
2
S-FLOW mode button

380
GS350_OM_OM30F69U_(U)
6-1. Maintenance and care
NOTICE
■Cleaning detergents
●Do not use the following types of detergent, as they may discolor the vehicle inte-
rior or cause streaks or damage to painted surfaces:
• Non-seat portions: Organic substances such as benzene or gasoline, alkalineor acidic solutions, dye, and bleach
• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alcohol
●Do not use polish wax or polish cleaner. The instrument panel’s or other interior
part’s painted surf ace may be damaged.
■Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of
leather surfaces:
●Remove any dust or dirt from leather surfaces immediately.
●Do not expose the vehicle to direct sunlight for extended periods of time. Park
the vehicle in the shade, especially during summer.
●Do not place items made of vinyl, plastic, or containing wax on the upholstery, as
they may stick to the leather surface if the vehicle interior heats up significantly.
■Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio syst em may be damaged if water comes into
contact with electrical components such as the audio system above or under the
floor of the vehicle. Water may also cause the body to rust.
■When cleaning the inside of the windsh ield (vehicles with LKA [Lane-Keeping
Assist])
Be careful not to touch the camera sensor ( P. 2 3 3 ) .
If the camera is accidentally scratched or hit, LKA may not operate properly or
may cause a malfunction.
■Cleaning the inside of the rear window
●Do not use glass cleaner to clean the rear window, as this may cause damage to
the rear window defogger heater wires or antenna. Use a cloth dampened with
lukewarm water to gently wipe the window clean. Wipe the window in strokes
running parallel to the heater wires or antenna.
●Be careful not to scratch or damage the heater wires or antenna.

596Alphabetical index
GS350_OM_OM30F69U_(U)
Care ................................................ 374, 378Aluminum wheels ..............................375
Exterior.................................................... 374
Interior .....................................................378
Seat belts ................................................379
Cargo capacity........................................ 174
Cargo hooks .......................................... 337
CD player
*
Chains ....................................................... 285
Child restraint system............................ 55 Booster seats, definition ....................55
Booster seats, installation..................65
Convertible seats, definition ............55
Convertible seats, installation ......... 62
Front passenger occupant classification system ......................... 47
Infant seats, definition ..........................55
Infant seats, installation ....................... 62
Installing CRS with LATCH anchors .....................60
Installing CRS with seat belts .......... 62
Installing CRS with top tether strap .........................66
Child safety ................................................ 54 Airbag precautions .............................. 39
Battery precautions ............. 405, 526
Child restraint system .........................55
How your child should wear the seat belt ................................... 31, 32
Installing child restraints.....................59
Moon roof precautions.................... 158
Power window lock switch .............. 151 Power window precautions ...........154
Rear door child-protectors ............ 124
Removed electronic
key battery precautions .............. 426
Seat belt comfort guide ....................... 31
Seat belt extender precautions .......................................... 35
Seat belt precautions .......................... 58
Seat heater precautions ................. 349
Trunk precautions .............................. 130
Child-protectors .................................... 124
Cleaning ....................................... 374, 378 Aluminum wheels .............................. 375
Exterior ................................................... 374
Interior ..................................................... 378
Seat belts................................................ 379
Clock........................................................... 341
Coat hooks ............................................. 356
Condenser.............................................. 402
Console box ........................................... 333
Console box light ................................. 333
Cooling system Engine overheating .......................... 527
Cruise control Cruise control ....................................... 214
Dynamic radar cruise control .......218
Cup holders............................................ 334
Curtain shield airbags ............................ 37
Customizable features ...................... 559
C
