INTERIOR EQUIPMENT
11 0
CAUTION
To reduce the chance of injury in case of an accident
or a sudden stop, always keep the rear console box
closed while driving.
 Do not apply excessive load over the tray with your
hand, or closing the console box lid may injure your
fingers.
 Do not open the rear console box while operating the
rear vents, or closing the console box lid may injure
your fingers.
GLOVE BOX
G14012
 1
Unlock 2Open 3Lock
To open the glove box door, push the button. To lock the
glove box door, insert the mechanical key and turn it
clockwise.
With the tail lights on, the glove box light will come on.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the glove box door closed
while driving.

INTERIOR EQUIPMENT
111
GARAGE DOOR OPENER
The garage door opener (\b Universal
Transceiver) is manufactured under license from
HomeLink
\b and can be programmed to operate garage
doors, gates, entry doors, door locks, home lighting
systems, and security systems, etc.
(a) Programming the HomeLink\b
G14013
 1 Indicator light 2Buttons
The HomeLink
\b in your vehicle has 3 buttons and you can
store one program for each button.
To ensure correct programming into the HomeLink
\b, install a
new battery in the hand −held transmitter prior to programming.
The battery side of the hand −held transmitter must be pointed
away from the HomeLink
\b during the programming process. For Canadian users, follow the procedure in “Programming an
entrance gate/Programming all devices in the Canadian
market”.
1. Decide
which of 3 HomeLink
\b buttons you want to program.
2. Place your hand− held garage transmitter 25 to 75 mm (1 to
3 in.) away from the surface of the HomeLink
\b.
G14058
Keep the indicator light on the HomeLink\b in view while
programming.

INTERIOR EQUIPMENT
11 23. Simultaneously press and hold the hand
−held garage
transmitter button along with the selected HomeLink
\b button.
G14059
Do not release the buttons until step 4 has been completed.
4. When the indicator light on the HomeLink
\b changes from a
slow to a rapid flash after 20 seconds, you can release both
buttons.
5. Test the operation of the HomeLink
\b by pressing the newly
programmed button. If programming a garage door opener,
check to see if the garage door opens and closes.
G14060
If the garage door does not operate, identify if your garage
transmitter is of the “Rolling Code” type. Press and hold the
programmed HomeLink
\b button. The garage door has the
rolling code feature if the indicator light (on the HomeLink\b)
flashes rapidly and then remains lit after 2 seconds. If your
garage transmitter is the “Rolling Code” type, proceed to the
heading “Programming a rolling code system”.
6. Repeat steps 2 through 5 for each remaining HomeLink
\b
button to program another device.

INTERIOR EQUIPMENT
11 3
Programming a rolling code system
If your device is “Rolling Code” equipped, it is necessary
to follow steps 1 through 4 under the heading
“Programming the HomeLink
\b” before proceeding with
the steps listed below.
1. Locate the “training” button on the ceiling mounted garage
door opener motor. The exact location and color of the button
may vary by brand of garage door opener. Refer to the owner’s
guide supplied by the garage door opener manufacturer for the
location of this “training” button.
2. Press the “training” button on the ceiling mounted garage
door opener motor.
Following this step, you have 30 seconds in which to initiate
step 3 below.
3. Press and release the vehicle’s programmed HomeLink
\b
button twice. The garage door may open. If the door does
open, the programming process is complete. If the door does
not open, press and release the button a third time. This third
press and release will complete the programming process by
opening the garage door.
The ceiling mounted garage door opener motor should now
recognize the HomeLink
\b unit and be able to activate the
garage door up/down.
4. Repeat steps 1 through 3 for each remaining HomeLink
\b
button to program another rolling code system.
Programming an entrance gate /
Programming all devices in the Canadian
market
1. Decide which of the 3 HomeLink\b buttons you want to
program.
2. Place your hand −held gate/device transmitter 25 to 75 mm
(1 to 3 in.) away from the surface of the HomeLink
\b.
Keep the indicator light on the HomeLink
\b in view while
programming.
3. Press and hold the selected HomeLink
\b button.
4. Continuously press and release (cycle) the hand−held
gate/device transmitter button every two seconds until step 5
is complete.
5. When the indicator light on the HomeLink
\b changes from a
slow to a rapid flash after 20 seconds, you can release both
buttons.
6. Test the operation of the HomeLink
\b by pressing the newly
programmed button. Check to see if the gate/device operates
correctly.
7. Repeat steps 1 through 6 for each remaining HomeLink
\b
button to program another device.
Programming other devices
To program other devices such as home security systems,
home door locks or lighting, contact your authorized Lexus
dealer for assistance.

INTERIOR EQUIPMENT
11 4
Reprogramming a button
Individual HomeLink\b
buttons cannot be erased, however, to
reprogram a single button, follow the procedure “Programming
the HomeLink
\b”.
(b) Operating the HomeLink\b
To operate the HomeLink\b, press the appropriate HomeLink\b
button to activate the programmed device. The HomeLink\b
indicator light should come on. The HomeLink\b continues to
send the signal for up to 20 seconds as long as the button is
pressed.
(c) Erasing the entire HomeLink\b memory
(all three programs)
To erase all previously programmed codes at one time, press
and hold down the 2 outside buttons for 20 seconds until the
indicator light flashes.
G14061
If you sell your vehicle, be sure to erase the programs stored
in the HomeLink\b memory.
CAUTION
 When programming the HomeLink\b Universal
Transceiver, you may be operating a garage door or
other device. Make sure people and objects are out
of the way of the garage door or other device to
prevent potential harm or damage.

This device complies with Part 15 of the FCC Rules
and with RSS−210 of the IC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference re-
ceived, including interference that may cause unde-
sired operation.
WARNING: This transmitter has been tested and
complies with FCC and IC rules. Changes or
modifications not expressly approved by the
party responsible for compliance could void the
user’s authority to operate the device.
INTERIOR EQUIPMENT
11 5
 Do not use this HomeLink\b Universal Transceiver
with any garage door opener that lacks the safety
stop and reverse feature as required by federal safety
standards. (This includes any garage door opener
model manufactured before April 1, 1982.) A garage
door opener which cannot detect an object
(signaling the door to stop and reverse), does not
meet current federal safety standards. Using a
garage door opener without these features increases
risk of serious injury or death.CUPHOLDERS
G14014
 Front
To use the cupholder, push the cupholder lid.
CAUTION
 Do not place anything else other than cups or
drinkcans in the cupholder, as such items may be
thrown about in the compartment and possibly injure
people in the vehicle during sudden braking or in an
accident.
 To reduce the chance of injury in case of an accident
or sudden stop while driving, keep the cupholder
closed when not in use.

INTERIOR EQUIPMENT
11 6
G14015
Rear
To use the cupholder, push the cup holder portion of the
center armrest in the rear seat.
The cup holder is designed for holding cups or drink −cans
securely.
CAUTION
 Do not place anything else other than cups or
drinkcans in the cupholder, as such items may be
thrown about in the compartment and possibly injure
people in the vehicle during sudden braking or in an
accident.
 To reduce the chance of injury in case of an accident
or sudden stop while driving, keep the cupholder
closed when not in use.
COIN BOXES
G14016
On the instrument panel
To use the coin box, push the button.
CAUTION
Keep the coin box closed when not in use.

INTERIOR EQUIPMENT
11 7
G14034
Under the lid of the rear console box
To use the coin box, slide the rear console box as shown.
OVERHEAD CONSOLE BOX
G14020
To use the overhead console box, push the lid as shown.
CAUTION
 To reduce the chance of injury in case of an accident
or a sudden stop, always keep the overhead console
box closed while driving.
 Do not place any object heavier than 100 g (0.22 lb.)
in it. Heavier objects may cause the box to open and
the contents to fly out resulting in injuries.

INTERIOR EQUIPMENT
11 8
NOTICE
During hot weather, the interior of the vehicle becomes
very hot. Do not leave anything flammable or
deformable such as a lighter, glasses, etc. inside.
DOOR POCKETS
G14030
To use the door pocket, open it as shown.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the door pockets closed
while driving.

INTERIOR EQUIPMENT
11 9
TRUNK STORAGE EXTENSION
G14021
 1Lock 2Unlock 3Open
Pull down the center armrest in the rear seat. Push down
the handle and open the armrest door.
Access to the trunk can be prevented by locking the armrest
door with the mechanical key.
See “Stowage precautions” on page 457 for precautions when
loading luggage.
CAUTION
Be sure to close the door when the trunk storage
extension is not in use. Luggage or cargo in the trunk
may be thrown into the passenger compartment in a
sudden stop or crash resulting in injury.
FLOOR MAT
G14025
Use a floor mat of the correct size.
If the floor carpet and floor mat have 2 holes, then they are
designed for use with locking clips. Fix the floor mat with
locking clips into the holes in the floor carpet.
