DRIVING TIPS
450
BREAKIN PERIOD
Drive gently and avoid high speeds.
You need not follow a break−in schedule with your new Lexus.
But following a few simple tips for the first 1600 km (1000 miles)
can add to the future economy and long life of your vehicle:
 Avoid full throttle acceleration when starting and driving.
 Avoid racing the engine.
 Try to avoid hard stops during the first 300 km (200 miles).
 Do not drive for a long time at any single speed, either fast
or slow.
OPERATION IN FOREIGN
COUNTRIES
If you plan to drive your Lexus in another country ...
First, comply with the vehicle registration laws.
Second, confirm the availability of the correct fuel (unleaded
and minimum octane rating).
TIPS FOR DRIVING IN VARIOUS CONDITIONS
Always slow down in gusty crosswinds. This will allow you
much better control.
 Drive slowly onto curbs and, if possible, at a right angle.
Avoid driving onto high, sharp −edged objects and other
road hazards. Failure to do so can lead to severe tire
damage such as a tire burst.
Drive slowly when passing over bumps or travelling on a
bumpy road. Otherwise, the impact could cause severe
damage to the tires and/or wheels.
 When parking on a hill, turn the front wheels until they touch
the curb so that the vehicle will not roll. Apply the parking
brake, and place the transmission in ”P”. If necessary, block
the wheels.
 Washing your vehicle or driving through deep water may get
the brakes wet. To see whether they are wet, check that
there is no traffic near you and then press the pedal lightly.
If you do not feel a normal braking force, the brakes are
probably wet. To dry them, drive the vehicle cautiously while
lightly pressing the brake pedal with the parking brake
applied. If they still do not work safel y, pull to the side of the
road and call a Lexus dealer for assistance.

DRIVING TIPS
451
CAUTION
Before driving off, make sure the parking brake is
fully released and that the parking brake reminder
light is off.
 Do not leave your vehicle unattended while the
engine is running.
 Do not rest your foot on the brake pedal while driving.
It can cause dangerous overheating, needless wear,
and poor fuel economy.
 To drive down a long or steep hill, reduce your speed
and downshift. Remember, if you ride the brakes
excessively, they may overheat and not work
properly. See page 359.
 Be careful when accelerating, upshifting,
downshifting or braking on a slippery surface. The
abrupt change in engine speed, such as sudden
acceleration or engine braking, could cause the
vehicle to skid or spin.
 Even if the legal speed limit permits it, do not drive
over 140 km/h (85 mph) unless your vehicle has
highspeed capability tires. Driving over 140 km/h
(85 mph) may result in tire failure, loss of control and
possible injury. Be sure to consult a tire dealer to
determine whether the tires on your vehicle are
highspeed capability tires or not before driving at
such speeds.
Do not continue normal driving when the brakes are
wet. If they are wet, your vehicle will require a longer
stopping distance, and it may pull to one side when
the brakes are applied. Also, the parking brake will
not hold the vehicle securely.

DRIVING TIPS
452
WINTER DRIVING TIPS
Make sure your coolant is properly protected against
freezing.
Only use ”Toyota Super Long Life Coolant” or similar high
quality ethylene glycol based non−silicate, non −amine,
non− nitrite, and non −borate coolant with long −life hybrid
organic acid technology. (Coolant with long −life hybrid organic
acid technology is a combination of low phosphates and
organic acids.)
See “Checking the engine coolant level” on page 527 for
details of coolant type selection.
For the U.S.A.—“Toyota Super Long Life Coolant” is a mixture
of 50% coolant and 50% deionized water. This coolant
provides protection down to about −35C (− 31F).
For Canada—“Toyota Super Long Life Coolant” is a mixture of
55% coolant and 45% deionized water. This coolant provides
protection down to about −42C (− 44F).
NOTICE
Do not use plain water alone.
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to pr ovide enough power for winter
starting. Page 571 tells you how to visually inspect the battery.
Your Lexus dealer and most service stations will be pleased to
check the battery charge level. Make sure the engine oil viscosity is suitable for the cold
weather.
See page 525 for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call
your Lexus dealer
− they will be pleased to help.
Check the electronic ignition system for loose
connections or obvious damage.
Keep the door locks from freezing.
Squirt lock de −icer or glycerine into the locks to keep them from
freezing.
Use a washer fluid containing an antifreeze solution.
This product is available at your Lexus dealer and most auto
parts stores. Follow the manufacturer’s directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute
because it may damage your vehicle’s paint.
Do not use your parking brake when there is a possibility
it could freeze.
When parking, put the transmission into ”P” and block the front
wheels. Do not use the parking brake, or snow or water
accumulated in and around the parking brake mechanism may
freeze the parking brake, making it hard to release.

DRIVING TIPS
453
Keep ice
and snow from accumulating under the fenders.
Ice and snow built up under your fenders can make steering
difficult. During bad winter driving, stop and check under the
fenders occasionally.
Depending on where you are driving, we recommend you
carry some emergency equipment.
Some of the things you might put in the vehicle are tire chains,
window scraper, bag of sand or salt, flares, small shovel,
jumper cables, etc.
DINGHY TOWING
G32001
Your vehicle is not designed to be dinghy towed (with four
wheels on the ground) behind a motorhome.
NOTICE
Do not tow your vehicle with four wheels on the ground.
This may cause serious damage to your vehicle.

DRIVING TIPS
454
TRAILER TOWING
G32002
Lexus does not recommend towing a trailer with your
vehicle. It is not designed for trailer towing.
HOW TO SAVE FUEL AND MAKEYOUR VEHICLE LAST LONGER
Improving fuel economy is easy − just take it easy. It will help
make your vehicle last longer, too. Here are some specific tips
on how to save money on both fuel and repairs:
 Keep your tires inflated at the correct pressure. Check
the inflation pressure every two weeks, or at least once a
month. Underinflation causes tire wear and wastes fuel.
 Do not carry unneeded weight in your vehicle. Excess
weight puts a heavier load on the engine, causing greater
fuel consumption.
 Avoid lengthy warmup idling. Once the engine is
running smoothly, begin driving − but gently. Remember,
however, that on cold winter days this may take a little
longer.
 Always keep the automatic transmission selector lever
in the “D” position when engine braking is not required.
Driving with the overdrive off will reduce the fuel economy.
(For details, see “Automatic transmission” on page 353.)
 Accelerate slowly and smoothly. Avoid jackrabbit starts.
 Avoid long engine idling. If you have a long wait and you
are not in traffic, it is better to turn off the engine and start
again later.
 Avoid engine overrevving. Use a gear position suitable
for the road on which you are traveling.

DRIVING TIPS
455

Avoid continuous speeding up and slowing down.
Stop−and−go driving wastes fuel.
 Avoid unnecessary stopping and braking. Maintain a
steady pace. Try to time the traf fic signals so you only need
to stop as little as possible or take advantage of through
streets to avoid traffic lights. Keep a proper distance from
other vehicles to avoid sudden braking. This will also
reduce wear on your brakes.
 Avoid heavy traffic or traffic jams whenever possible.
 Do not rest your foot on the brake pedal. This causes
premature wear, overheating and poor fuel economy.
 Maintain a moderate speed on highways. The faster you
drive, the greater the fuel consumption. By reducing your
speed, you will cut down on fuel consumption.
 Keep the front wheels in proper alignment. Avoid hitting
the curb and slow down on rough roads. Improper
alignment not only causes faster tire wear but also puts an
extra load on the engine, which, in turn, wastes fuel.
 Keep the bottom of your vehicle free from mud, etc.
This not only lessens weight but also helps prevent
corrosion.
Keep your vehicle tunedup and in top shape. A dirty air
cleaner, improper valve clearance, dirty plugs, dirty oil and
grease, brakes not adjusted, etc. all lower engine
performance and contribute to poor fuel economy. For
longer life of all parts and lower operating costs, keep all
maintenance work on schedule, and if you often drive under
severe conditions, see that your vehicle receives more
frequent maintenance (For scheduled maintenance
information, please refer to the “Owner’s Manual
Supplement / Scheduled Maintenance”.)
CAUTION
Never turn off the engine to coast down hills. Your
power steering and brake booster will not function
without the engine running. Also, the emission control
system operates properly only when the engine is
running.

DRIVING TIPS
456
VEHICLE LOAD LIMITS
Vehicle load limits include total load capacity, seating
capacity, towing capacity and cargo capacity . Follow the
load limits shown below. Total load capacity and seating
capacity are also described on the tire and loading
information label. For location of the tire and loading
information label, see “Checking tire inflation pressure”
on page 539.
Total load capacity: 370 kg (815 lb.)
Total load capacity means combined weight of
occupants, cargo and luggage.
Seating capacity: Total 5 (Front 2, Rear 3)
Seating capacity means the maximum number of
occupants whose estimated average weight is 68 kg
(150 lb.) per person. Depending on the weight of each
person, the seating capacity given may exceed the total
load capacity.
NOTICE
Even if the number of occupants are within the
seating capacity, do not exceed the total load
capacity.
Towing capacity
Lexus does not recommend towing a trailer with your
vehicle. Your vehicle is not designed for trailer towing.
Cargo capacity
Cargo capacity may increase or decrease depending on
the size (weight) and the number of occupants. For
details, see “Capacity and distribution” that follows.
CAUTION
Do not apply the load more than each load limit.
That may cause not only damage to the tires, but
also deterioration to the steering ability and
braking ability, which may cause an accident.

DRIVING TIPS
457
CARGO AND LUGGAGE
Stowage precautions
When stowing cargo and luggage in the vehicle,
observe the following:
Put cargo and luggage in the trunk when at all
possible. Be sure all items are secured in place.
 Be careful to keep the vehicle level. Placing the
weight as far forward as possible helps maintain
vehicle balance.
 For better fuel economy, do not carry unnecessary
weight.
CAUTION
Do not place anything on the package tray
behind the rear seatback. Such items may be
thrown about and possibly injure people in the
vehicle during sudden braking or an accident.
 Do not drive with objects left on top of the
instrument panel. They may interfere with the
driver’s field of view. Or they may move during
sharp vehicle acceleration or turning, and
impair the driver’s control of the vehicle. In an
accident they may injure the vehicle occupants.
NOTICE
Do not load the vehicle beyond the vehicle
capacity weight specified on the tire and loading
information label.

DRIVING TIPS
458
Capacity and distribution
Cargo capacity depends on the total weight of the
occupants.
(Cargo capacity) = (Total load capacity) – (Total weight
of occupants)
Steps for determining correct load limit
1. Locate the statement “The combined weight of
occupants and cargo should never exceed XXX pounds”
on your vehicle’s placard.
2. Determine the combined weight of the driver and
passengers that will be riding in your vehicle.
3. Subtract the combined weight of the driver and
passengers from XXX kilograms or XXX pounds.
4. The resulting figure equals the available amount of
cargo and luggage load capacity. For example, if the
“XXX” amount equals 1400 lbs. and there will be five 150
lb. passengers in your vehicle, the amount of available
cargo and luggage load capacity is 650 lbs. 1400 – 750
(5 x 150) = 650 lbs.
5. Determine the combined weight of luggage and cargo
being loaded on the vehicle. That weight may not safely
exceed the available cargo and luggage load capacity
calculated in Step 4. 6. If your vehicle will be towing a trailer, load from your
trailer will be transferred to your vehicle. Consult this
manual to determine how this reduces the available
cargo and luggage load capacity of your vehicle.
Lexus does not recommend towing a trailer with your
vehicle. Your vehicle is not designed for trailer towing.

DRIVING TIPS
459
Example on your vehicle
32SA03
 1Cargo capacity 2Total load capacity
In case that 2 people with the combined weight of 166 kg
(366 lb.) are riding in your vehicle with the total load
capacity of 370 kg (815 lb.), the available amount of
cargo and luggage load capacity will be as follows:
370 kg – 166 kg = 204 kg.
(815 lb. – 366 lb. = 449 lb.)
From this condition, if 3 more passengers with the
combined weight of 176 kg (388 lb.) get on, the available
cargo and luggage load will be reduced as follows:
204 kg – 176 kg = 28 kg.
(449 lb. – 388 lb. = 61 lb.) As shown in the above example, if the number of
occupants increases, the cargo and luggage load
equaling the
combined weight of occupants who got on
later must be reduced. In other words, if the increase in
the number of occupants causes the excess of the total
load capacity (combined weight of occupants plus cargo
and luggage load), you have to reduce the cargo and
luggage on your vehicle.
For details about total load capacity, see “Vehicle load
limits” on page 456.CAUTION
Even if the total load of occupant’s weight and the
cargo load is less than the total load capacity, do
not apply the load unevenly. That may cause not
only damage to the tire but also deterioration to
the steering ability due to unbalance of the
vehicle, causing an accident.
