STARTING AND DRIVING
440
TIRE PRESSURE WARNINGSYSTEM
The tire pressure warning system warns you that the tire
inflation pressure is low.
The tire pressure warning syst em is not a substitute for
checking n ormal tire inflation pressure. Check the tire inflation
pressure with a tire pressure gauge regularly.
CAUTION
The warning system may not activate immediately if
bursts or sudden air leakage should occur.
G31003
 Tire pressure warning light
The tire pressure warning light comes on when the engine
switch “IG−ON” mode is selected, and goes off after a few
seconds. This means the tire pressure warning light is
operating properly. If the tire inflation pressure becomes low,
the light comes on again. At this time, the master warning light
comes on and the message “LOW TIRE” appears on the
multi−information display.
In this case, adjusting the tire inflation pressure will turn off the
light after a few minutes. If the light blinks, the tire pressure
warning system is not working properly. At this time, the
master warning light comes on and the message “CHECK
SYSTEM” appears on the multi −information display.

STARTING AND DRIVING
444If the tire pressure warning light blinks...
G31048
If the tire pressure warning light blinks when the engine
switch “IGON” mode is selected, the tire pressure
warning system is not working properly.
The system will be disabled in the following conditions:
(When the condition becomes normal, the system will work
properly.)

If tires not equipped with tire pressure warning valves and
transmitters are used.
 If the ID code on the tire pressure warning valves and
transmitters is not registered.
 If electronic devices or facilities using similar radio wave
frequencies are nearby.
 If a radio set at similar frequencies is in use in the vehicle.
If a window tint that affects the radio wave signals is
installed.
 If the tire pressure warning select switch is set to a dif ferent
tire setting.
 If there is a lot of snow or ice on the vehicle, in particular
around the wheels or wheel housings.
 If non− genuine Lexus wheels are used.
 If tire chains are used.
 If the tire inflation pressure is more than 500 kPa (5.1
kgf/cm
2 or bar, 73 psi).
If the tire pressure warning light blinks frequently when the
engine switch “IG −ON” mode is selected, have it checked by
your Lexus dealer.
Even if you use genuine wheels, the tire pressure warning
system may not work properly with some types of tires.
Pushing the tire pressure warning reset switch should not turn
off the tire pressure warning light.

STARTING AND DRIVING
447
To initialize the system, perform the following:
1. Park
the vehicle in a safe place and select the engine switch
in “OFF” mode.
2. Adjust the pressure of all the installed tires to the specified
cold tire inflation pressure level. (See “Tire and wheels” on
pages 542 and 546.)
3. Select the engine switch in “IG −ON” mode.
4. Push and hold the tire pressure warning reset switch until
the tire pressure warning light blinks slowly three times and the
message “PRESSURE INITIAL” appears on the
multi−information display.
5. Wait for a few minutes with the engine switch in “IG −ON”
mode, and then select the engine switch in “OFF” position.
If you push the tire pressure reset switch while the vehicle is
moving, initialization is not performed.
If you push the tire pressure reset switch accidentally and
initialization is performed, adjust the tire inflation pressure to
the specified level and initialize the system again.
G31007
If the tire pressure warning light does not blink slowly three
times and the message “PRESSURE INITIAL” does not
appear on the multi −information display when you push and
hold the reset switch, initialization has failed and the tire
pressure warning system may not work properly. In this case,
initialize the system again. If initialization cannot be
performed, have the system checked at your Lexus dealer.

STARTING AND DRIVING
452
Adaptive variable suspension control (GS430
only)
When the precollision sensor detects an object or
vehicle with which your vehicle may collide, and
determines that a collision may be unavoidable, the
adaptive variable suspension adjusts the damping effect
on the shock absorbers and regulates the vehicle not to
pitch forward so much.
The adaptive variable suspension will operate when the
following all conditions are met.
When the vehicle speed is about 5 km/h (3 mph) or over.
 When the approaching speed in regard to the object or the
vehicle exceeds about 30 km/h (18 mph).
Precollision system failure warning
G31079
Precollision system warning light
The light warns that there is a problem somewhere in the
precollision system.
The light comes on when the engine switch is selected in
“IG−ON” mode. If the system works properly, the light goes off
after a few seconds.
If the light does not come on when the engine switch is selected
in “IG−ON” mode, have your vehicle checked by your Lexus
dealer.
If the system has a problem, the pre− collision system warning
light comes on or blinks. At this time, the master warning light
comes on, a warning tone sounds, and either of the following
messages appears on the multi−information display.
 PCS DISABLED NOW
 CHECK PCS

DRIVING TIPS
456
BREAKIN PERIOD
Drive gently and avoid high speeds.
You need not follow a break−in schedule with your new Lexus.
But following a few simple tips for the first 1600 km (1000 miles)
can add to the future economy and long life of your vehicle:
 Avoid full throttle acceleration when starting and driving.
 Avoid racing the engine.
 Try to avoid hard stops during the first 300 km (200 miles).
 Do not drive for a long time at any single speed, either fast
or slow.
OPERATION IN FOREIGN
COUNTRIES
If you plan to drive your Lexus in another country ...
First, comply with the vehicle registration laws.
Second, confirm the availability of the correct fuel (unleaded
and minimum octane rating).
TIPS FOR DRIVING IN VARIOUS CONDITIONS
Always slow down in gusty crosswinds. This will allow you
much better control.
 Drive slowly onto curbs and, if possible, at a right angle.
Avoid driving onto high, sharp −edged objects and other
road hazards. Failure to do so can lead to severe tire
damage such as a tire burst.
Drive slowly when passing over bumps or travelling on a
bumpy road. Otherwise, the impact could cause severe
damage to the tires and/or wheels.
 When parking on a hill, turn the front wheels until they touch
the curb so that the vehicle will not roll. Apply the parking
brake, and place the transmission in ”P”. If necessary, block
the wheels.
 Washing your vehicle or driving through deep water may get
the brakes wet. To see whether they are wet, check that
there is no traffic near you and then press the pedal lightly.
If you do not feel a normal braking force, the brakes are
probably wet. To dry them, drive the vehicle cautiously while
lightly pressing the brake pedal with the parking brake
applied. If they still do not work safel y, pull to the side of the
road and call a Lexus dealer for assistance.

IN CASE OF AN EMERGENCY
468
IF YOUR ENGINE STALLS WHILEDRIVING
If your engine stalls while driving . . .
1. Reduce your speed gradually, keeping a straight line. Move
cautiously off the road to a safe place.
2. Turn on your emergency flashers.
3. Turn the engine switch off, and try starting the engine again.
If the engine will not start, see ”If your vehicle will not start”\
.
CAUTION
If the engine is not running, the power assist for the
brakes and steering will not work, so steering and
braking will be much harder than usual.
IF YOUR VEHICLE WILL NOT START
(a) Simple checks
Before making these checks, make sure you have followed the
correct starting procedure instructions in ”Operating the
engine switch” on page 348 and that you have sufficient fuel.
Since your vehicle is equipped with the engine immobilizer,
also check whether the other keys will start the engine. If they
work, your electronic key may be broken. Have the key
checked at your Lexus dealer. If none of your keys work, there
may be a malfunction in the engine immobilizer. Call your
Lexus dealer. See ”Keys” on page 8.
If the engine is not turning over or is turning over too
slowly
1. Check that the battery terminals are tight and clean.
2. If the battery terminals are O.K., switch on the interior light.
3. If the light is out, dim or goes out when the starter is cranked,
the battery is discharged. You may try jump starting. See ”(c)
Jump starting” for further instruction.
4. If the engine does not start even after the battery has been
recharged or replaced, see “(d) Starting the engine after a
battery discharge” on page 472.
If the light is O.K., but the engine still will not start, it needs
adjustment or repair. Call a Lexus dealer, Roadside
Assistance or Customer Service Assistance. (See
”Foreword”.)

IN CASE OF AN EMERGENCY
472
CAUTION
When making the connections, to avoid serious injury,
do not lean over the battery or accidentally let the
jumper cables or clamps touch anything except the
correct battery terminals or the ground.
5. Charge the discharged battery with the jumper cables
connected for approximately 5 minutes. At this time, run the
engine in the vehicle with the booster battery at about 2000
rpm with the accelerator pedal lightly depressed.
6. Start your engine in the normal way. After starting, run it at
about 2000 rpm for several minutes with the accelerator pedal
lightly depressed.
7. Carefully disconnect the cables in the exact reverse order:
the negative cable and then the positive cable.
8. Carefully dispose of the battery cover cloths which may now
contain sulfuric acid.
9. If removed, replace all the battery vent plugs.
The engine may not restart even after battery charging or
replacement. If this happens, see “(d) Starting the engine after
a battery discharge”.
If the cause of your battery discharging is not apparent (for
example, lights left on), you should have it checked at your
Lexus dealer. If the first start attempt is not successful...
Check
that the clamp on the jumper cables are tight. Recharge
the discharged battery with the jumper cables connected for
several minutes and restart your engine in the normal way.
If another attempt is not successful, the battery may be
depleted. Have it checked at your Lexus dealer.(d) Starting the engine after a battery discharge
In the event that the battery is discharged, the engine may
not restart even after the battery is recharged or replaced.
For safety reasons, the engine may be disabled when
battery voltage is extremely low. If the engine is disabled,
the start system must be normalized.
To normalized the start system:
1. Shift the transmission to the “P” position and set the engine
switch off.
2. Open and close any of the doors.
3. Start the engine.

IN CASE OF AN EMERGENCY
474B: If no steam is coming from your engine:
Leave the engine running and turn off the air conditioning.
Check the following.

Is the cooling fan operating?
 Is the coolant in the acceptable range?
 Is the engine drive belt O.K.?
CAUTION
When the engine is running, keep hands and clothing
away from the moving fan and engine drive belt.
 Do not attempt to remove the radiator cap when the
engine and radiator are hot. Serious injury could
result from scalding hot fluid and steam blown out
under pressure.
If the cooling fan is not operating or the coolant is not in the
acceptable range, turn off the engine and call your Lexus
dealer.
If both conditions are O.K., after the engine coolant
temperature has cooled to normal, continue driving your
vehicle.
If the engine coolant temperature does not cool down, or your
vehicle overheats again, have it checked as soon as possible
by your Lexus dealer.
IF YOU HAVE A FLAT TIRE
(Vehicles with runflat tires)
G63004
You may continue driving a vehicle with runflat
tires even if any tire goes flat. It may be able to run
for a maximum of 160 km (100 miles) at a speed
below 90 km/h (55 mph) after the tire pressure
warning light comes on. When you drive your
vehicle after the tire pressure warning light comes
on, the tire must be replaced. Do not use the
repaired tire.
Observe the following precautions and take your vehicle
to the nearest Lexus dealer or authorized tire dealer.

MAINTENANCE
502Battery
Your Lexus has a maintenance free battery. You do not have
to add distilled water. For longer life of the battery, however,
see page 581 for additional information.
Brake fluid level
Make sure the brake fluid level is correct. See page 547 for
additional information.
Engine oil level
Check the level on the dipstick with the engine turned off and
the vehicle parked on a level spot.
See page 530 for additional
information.
Exhaust system
If you notice any change in the sound of the exhaust or smell
exhaust fumes, have the cause located and corrected
immediately. (See “Engine exhaust caution” on page 347.)
Vehicle interior
Items listed below should be checked regularly, e.g. while
performing periodic services, cleaning the vehicle, etc.
Lights
Make sure the headlight, stop lights, tail lights, turn signal
lights, and other lights are working. Check headlight aim.
Service reminder indicators and warning buzzers
Check that all service reminder indicators and warning
buzzers function properly.
Steering wheel
Check that it ha s the specified free play. Be alert for changes
in steering condition, such as hard steering, excessive free
play or strange noise.
Seats
Check that all front seat controls such as seat adjusters,
seatback recliner, etc. operate smoothly. Check that the head
restraints move up and down smoothly and that the locks hold
securely in any latched position.
Seat belts
Check that the seat belt system such as buckles, retractors
and anchors operate properly and smoothly. Make sure the
belt webbing is not cut, frayed, worn or damaged.

ENGINE
522– COOLING SYSTEM
Capacity
10.1 L (10.7 qt., 8.9 lmp.qt.)
Coolant type”Toyota Super Long Life Coolant” or similar high quality ethylene glyco\
l
based non −silicate, non− amine, non−nitrite, and non −borate coolant
with long −life hybrid organic acid technology (Coolant with long −life
hybrid organic acid technology is a combination of low phosphates and
organic acids.)
Do not use plain water alone.
NOTE:
“Toyota Super Long Life Coolant” is used in your Lexus vehicle at factory fil\
l. In order to avoid technical problems, only use ”Toyota
Super Long Life Coolant” or similar high quality ethylene glycol based non −silicate, non −amine, non −nitrite, and non −borate coolant
with long−life hybrid organic acid technology. (Coolant with long −life hybrid organic acid technology is a combination of low
phosphates and organic acids.) Do not use plain water alone. Please contact you\
r Lexus dealer for further details.
– IGNITION SYSTEM
Spark plug – Make DENSO NGK
– Gap
SK20R11
IFR6A11
1.1 mm (0.043 in.)
– ELECTRICAL SYSTEM
Battery – Open voltage at 20 C (68F):
– Charging rates
12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the engine switch is off with all
the lights turned off]
5A max.
