glove box Lexus GS450h 2007 Using the audio system / LEXUS 2007 GS450H THROUGH JUNE 2006 PROD. QUICK REFERENCE MANUAL

Entering and Exiting
Before Driving
When Driving
Rain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
2
Driving Comfort
Topic 5
Opening and Closing
Topic 6
What to do if ...
Customizing Your LexusResponding to warning/indicator lights
and other problems that may arise.
A list of features that can be customized.
Rain and Night Driving
Topic 4
lHeadlightsP. 2 7
lFog LightsP. 2 8
lWindshield Wipers and
Wa s h e r sP. 2 8
lHeadlight CleanerP. 2 9
lRear Window and Outside Rear
View Mirror Defo ggersP. 2 9
lInstrument Panel Light ControlP. 2 9
lCup HoldersP. 4 0
lInterior LightsP. 4 1
lRear SunshadeP. 4 1
lCompassP. 4 1
lLuggage MatP. 4 2
lDoor LocksP. 4 5
lPo w e r Wi n d ow sP. 4 6
lMoon RoofP. 4 6
lFuel Tank CapP. 4 7
lHoodP. 4 7
lTr u n kP. 4 8
lTouch ScreenP. 3 1
lAir Conditioning SystemP. 3 2
lAudio SystemP. 3 4
lHands-free SystemP. 3 6
lAshtraysP. 3 7
lSeat Heaters/Seat Heaters
and VentilatorsP. 3 8
lConsole BoxP. 3 9
lGlove BoxP. 4 0
Depending on specifications, the vehicle shown in the illustration may
differ from your vehicle in terms of color and equipment.

4
Seat heater switches∗
Pow

er switch
P.17
Air conditioning system P.32
Emergency flashers P.20
Rear window and outside rear
view mirror defoggers
P.29
Security indicator P.9
Audio system P.34
Glove box P.40
Trunk opener main switch P.48
See P.5
“AVS” switch P.24
Seat heater/ventilator
switches
∗ P.38
Mode select switch P.20
∗ : If equipped
“TRAC OFF” switch
P.24

Topic 1
Entering and Exiting
7
Keys
nElectronic key
lLocks and unlocks the doors
lOpens the trunk
lStarts and stops the hybrid system
nMechanical key
lLocks and unlocks the doors
lOpens the trunk
lLocks and unlocks the glove box
The mechanical key is stored inside the electronic
key. To extract the key, release the latch and pull.
nWireless remote control
Locks the doors
Unlocks the doors
Opens the trunk
Sounds the alarm
(To stop the alarm, push any button on the
wireless remote control.)1
2
3
4
The wireless remote control can also be used to open the windows and moon roof.
To do so, simply press and hold button.

Driving ComfortTo p i c 5
Touch Screen .......................................................... 31
Air Conditioning System .................................... 32
Audio System ......................................................... 34
Hands-free System .............................................. 36
Ashtrays................................................................... 37
Seat Heaters / Seat Heaters and
Ventilators .............................................................. 38
Console Box ........................................................... 39
Glove Box ............................................................... 40
Cup Holders........................................................... 40
Interior Lights.......................................................... 41
Rear Sunshade ....................................................... 41
Compass................................................................... 41
Luggage Mat.......................................................... 42

Topic 5
Driving Comfort
40
Entering and Exiting
When Driving
Rain and
Night Driving
Driving ComfortDriving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Before Driving
Glove Box
Open: press the button.
Lock
Unlock
The glove box can be locked and unlocked using
the mechanical key.
Cup Holders
Front
To open, press down on the front of the lid.
Rear
To open, press in and release the rear cup holder
on the rear center armrest.
1
2
3

Topic 6
Opening and Closing
48
Entering and Exiting
Before DrivingBefore Driving
When Driving
Rain and
Night Driving
Driving Comfort
Opening and ClosingOpening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Trunk
nTrunk opener
To open the trunk from inside the cabin, simply
press the trunk opener.
To disable the trunk opener, turn OFF the main
switch in the glove box.
ON
OFF
When the trunk opener is disabled, the trunk can-
not be opened using the entry function or the
wireless remote control.
nEntry function and wireless remote control
→P. 7 , 8
1
2
