garage door opener Lexus GS450h 2008 Scheduled Maintenace Guide / LEXUS 2008 GS450H OWNER'S MANUAL (OM30A96U)

TABLE OF CONTENTSIndex
4
GS_HV_U
December 12, 2007 3:33 pm
3-4. Using the hands-free system 
(for cellular phone)................ 306
Hands-free system 
(for cellular phone) .................. 306
Using the Bluetooth
® phone ..... 311
Setting the hands-free 
system ............................................ 326
3-5. Using the interior lights .......... 352 Interior lights list............................ 352
3-6. Using the storage features .... 355 List of storage fe atures.............. 355
3-7. Other interior features........... 362 Sun visors......................................... 362
Vanity mirror .................................. 363
Clock ................................................. 364
Outside temperature 
display ........................................... 365
Ashtrays ........................................... 366
Cigarette lighter ........................... 367
Power outlet .................................. 368
Seat heaters/vent ilators ............ 369
Armrest ............................................. 371
Rear sunshade ............................... 372
Floor mats........................................ 374
Trunk features................................ 375
Garage door opener .................. 377
Compass......................................... 383
Lexus Link System ....................... 387 4-1. Maintenance and care............ 402
Cleaning and protecting 
the vehicle exterior................... 402
Cleaning and protecting 
the vehicle interior ................... 405
4-2. Maintenance............................. 408 Maintenance requir ements .... 408
General maintena nce ................. 410
Emission inspection and 
maintenance (I/M) 
programs ....................................... 413
4-3. Do-it-yourself 
maintenance............................. 414
Do-it-yourself service 
precautions ................................... 414
Hood................................................... 417
Positioning a floor jack................ 418
Engine compartment.................. 420
Tires ................................................... 435
Tire inflation pressure................. 445
Wheels.............................................. 449
Air conditioning filter................... 451
Electronic key battery ................ 454
Checking and replacing 
fuses ................................................ 456
Headlight aim.................................. 471
Light bulbs ....................................... 474
4Maintenance and care

9
GS_HV_U
December 12, 2007 3:50 pm
Compass P. 383
Garage door opener switches P. 377
Inside rear view mirror P. 74
Personal light P. 354
Moon roof switch P. 80
Interior light P. 353
Vanity mirror P. 363
Personal light P. 354
Interior light P. 353
Sun visor P. 362
SRS curtain shield airbag P. 95
A
: If equipped
Lexus Link System switches P. 387

Interior features3
223
GS_HV_U
December 12, 2007 3:30 pm
3-3. Using the audio 
system ............................ 241
Audio system type................... 241
Using the radio........................ 244
Using the cassette player .... 253
Using the CD player ............. 257
Playing MP3 and 
WMA discs............................ 262
Using the DVD player........... 266
Playing DVD 
video/audio............................ 269
Playing video CD .................... 281
DVD player and DVD 
video disc information ...... 285
Optimal use of the 
audio/video system ............. 297
Using the AUX adapter ...... 302
Using the steering 
switches ................................. 303
3-4. Using the hands-free 
system (for cellular 
phone)........................... 306
Hands-free system 
(for cellular phone) ............. 306
Using the Bluetooth
® 
phone ........................................ 311
Setting the hands-free  system ..................................... 326 3-5. Using the interior

lights ............................. 352
Interior lights list .................... 352
3-6. Using the storage 
features ........................ 355
List of storage features......... 355
3-7. Other interior  features ........................ 362
Sun visors ................................. 362
Vanity mirror ........................... 363
Clock ......................................... 364
Outside temperature 
display..................................... 365
Ashtrays.................................... 366
Cigarette lighte r ..................... 367
Power outlet ............................ 368
Seat heaters/ventilators ...... 369
Armrest ..................................... 371
Rear sunshade ........................ 372
Floor mats ................................. 374
Trunk features ......................... 375
Garage door opener ............. 377
Compass .................................. 383
Lexus Link System ................. 387

377
3-7. Other interior features
3
Interior features
GS_HV_U
December 13, 2007 10:51 am
Garage door opener
The garage door opener (HomeLink Universal Transceiver) is manufactured
under license from HomeLink.
Programming the HomeLink (for U.S.A. owners)
The HomeLink
 compatible transceiver in your vehicle has 3 buttons
which can be programmed to operate 3 different devices. Refer to the
programming method below appropriate for the device.
Indicator
Buttons
■ Programming the HomeLink

Point the remote control for the
device 1 to 3 in. (25 to 75 mm)
from the HomeLink
 control but-
tons.
Keep the indicator light on the
HomeLink in view while pro-
gramming.
The garage door opener can be pr ogrammed to operate garage doors,
gates, entry doors, door locks, home lighting systems, and security systems,
and other devices.
STEP1

378
3-7. Other interior features
GS_HV_U
December 13, 2007 10:51 am
Press and hold one of the buttons
on the HomeLink and the button
on the transmitter. When the indi-
cator light on the HomeLink

changes from a slow to a rapid
flash after 20 seconds, you can
release both buttons.
Test the operation of the
HomeLink
 by pressing the newly
programmed button.
If programming a garage door
opener, check to see if the garage
door opens and closes. If the
garage door does not operate, see
if your garage transmitter is of the
Rolling Code type. Press and hold
the programmed HomeLink
 but-
ton. The garage door has the roll-
ing code feature if the indicator
light (on the HomeLink
) flashes
rapidly for 2 seconds and then
remains lit. If your transmitter is the
Rolling Code type, proceed to the
heading “Programming a rolling
code system”.
Repeat the steps above to program another device for each of
the remaining HomeLink buttons.
STEP2
STEP3
STEP4

379
3-7. Other interior features
3
Interior features
GS_HV_U
December 13, 2007 10:51 am
■Programming a Rolling Code system (for U.S.A. owners)
If your device is Rolling Code eq uipped, follow the steps under the
heading “Programming the HomeLink
” before proceeding with the
steps listed below.
Locate the training button on the ceiling mounted garage door
opener motor. The exact location and color of the button may
vary by brand of garage door opener.
Refer to the operation manual supplied with the garage door opener
for the location of the training button.
Press the training button.
Press and release the vehicle’s programmed HomeLink
 button
twice. The garage door may open.
If the garage door opens, the programming process is complete. If the
door does not open, press and release the button a third time. This third
press and release will complete the programming process by opening
the garage door.
The ceiling mounted garage door op ener motor should now recognize
the HomeLink
 transceiver and operate the garage door.
Repeat the steps above to prog ram another rolling code system
for any of the remaining HomeLink buttons.
STEP1
STEP2
STEP3
STEP4

381
3-7. Other interior features
3
Interior features
GS_HV_U
December 13, 2007 10:51 am
Operating the HomeLink
Press the appropriate HomeLink button. The HomeLink indicator
light on the HomeLink transceiver should turn on.
The HomeLink continues to send a signal for up to 20 seconds as long as
the button is pressed.
Erasing the entire HomeLink memory (all three programs)
Press and hold the 2 outside but-
tons for 20 seconds until the indi-
cator light flashes.
If you sell your vehicle, be sure to
erase the programs stored in the
HomeLink
 memory.
■Before programming
●Install a new battery in the transmitter.
●The battery side of the transmitter must be pointed away from the HomeLink.
■Certification for the garage door opener
This device complies with Part 15 of the FCC Rules and with RSS-210 of the IC
Rules. 
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
WARNING: This transmitter has been tested and complies with FCC and IC rules.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the device.

382
3-7. Other interior features
GS_HV_U
December 13, 2007 10:51 am
CAUTION
■When programming a garage door or other remote control device
The garage door may operate, so ensure people and objects are out of danger to
prevent potential harm.
■Conforming to federal safety standards
Do not use the HomeLink
 Compatible Transceiver with any garage door opener
or device that lacks safety stop and reverse features as required by federal safety
standards. 
This includes any garage door that cannot detect an obstruction object. A door or
device without these featur es increases the risk of death or serious injury.

587
Alphabetical index
GS_HV_U
December 12, 2007 3:50 pm
Front passenger occupant 
classification system .......................... 107
Front passenger’s seat belt 
reminder light ..................................... 493
Front seats Adjustment .............................................. 58
Driver’s seat position memory ...... 60
Front turn signal lights Wattage ................................................. 552
Fuel Capacity................................................. 546
Fuel gauge ..............................................148
Gas station information ................. 596
Information............................................ 553
Refueling ................................................... 83
Messages ..................................................511
Fuel door..................................................... 83
Fuel filler door........................................... 83
Fuses.......................................................... 456
Garage door opener........................... 377
Gas station information ..................... 596
Gauges.......................................................148
Glove box ............................................... 356
Hands-free system 
(for cellular phone).......................... 306
Head restraints..........................................64
Headlight aim .......................................... 471
Headlight cleaner .................................. 165 Headlights
Adaptive front lighting system...... 159
Discharge headlights 
precautions........................................ 479
Replacing light bulbs ........................ 474
Switch........................................................ 158
Wattage ..................................................552
Heaters Seat heaters ......................................... 369
Side mirror.............................................240
Hill-start assist control ....................... 200
Hood ............................................................417
Hooks Cargo ......................................................375
Shopping bag ......................................375
Hybrid system ........................................... 22 Emergency shut off system.............. 27
Energy monitor/consumption 
screen...................................................... 27
High voltage components ............... 26
Power meter.......................................... 148
Power (ignition) switch .................... 138
Identification Engine..................................................... 545
Electric motor ..................................... 545
Vehicle ................................................... 545
Ignition switch Power switch......................................... 138
Illuminated entry system .................... 352
I/M test....................................................... 413
Immobilizer system ................................ 88
Indicator lights......................................... 152
Initialization Items to initialize .................................575
Inside rear view mirror .......................... 74
G
H
I
