Lexus GS450h 2008 Using the audio system / LEXUS 2008 GS450H OWNER'S MANUAL (OM30A96U)

571
6-2. Customization
6
Vehicle specifications
GS_HV_U
December 12, 2007 3:50 pm
ItemFunctionDefault settingCustomizedsetting
Door lock (
P. 5 0 )
Unlocking using a key
Driver’s door
unlocked in 1-
step, all doors
unlocked 
in 2-step
All doors
unlocked in 1-step
Speed-detecting auto-
matic door lock functionOFFON
Opening driver’s door
unlocks all doors OFFON
Shift the shift lever to “P”
unlocks all doorsONOFF
Shift the shift lever to posi-
tion other than “P” locks
all doors
ONOFF
Pow e r w i n -
dows 
(
P. 7 7 )
Linked door lock opera-
tionONOFF
Linked door key opera-
tionOpen and closeOpen only
Close only
Wireless remote control
linked operationONOFF
Linked entry functionONOFF

572
6-2. Customization
GS_HV_U
December 12, 2007 3:50 pm
*: Vehicles sold outside Canada
ItemFunctionDefault settingCustomizedsetting
Moon roof 
(
P. 8 0 )
Linked door lock opera-
tionONOFF
Linked door key opera-
tionOpen and closeOpen only
Close only
Linked operation of com-
ponents when door key is
used
Slide onlyTilt only
Wireless remote control
linked operationONOFF
Linked operation of com-
ponents when wireless
remote control used
Slide onlyTilt only
Linked entry functionONOFF
Automatic
light control
system 
(
P. 1 5 8 )
Light sensor sensitivityLevel 3Levels 1 to 5
Ti m e e l a p s e d b e f o r e
headlights automatically
turn off after doors are
closed
30 seconds
0 seconds
60 seconds
90 seconds
Daytime running lightONOFF*

573
6-2. Customization
6
Vehicle specifications
GS_HV_U
December 12, 2007 3:50 pm
ItemFunctionDefault settingCustomizedsetting
Windshield
wipers and
washer 
(
P. 1 6 2 )
Switching operation when
the vehicle is stationaryONOFF
Drip prevention functionONOFF
Time elapsed before the
drip prevention function
operatesVa r i a b l e
depending on
the vehicle
speed
3 seconds
Illumination 
(
P. 3 5 2 )
Time elapsed before lights
turn off15 seconds7. 5 s e c o n d s
30 seconds
Operation when the
doors are unlockedONOFF
Operation after the
“POWER” switch turned
OFF
ONOFF
Front/rear personal lights
turned on when a door is
openedCorresponding light onlyAll lights
OFF
Foot lights ONOFF
Shift lever lightONOFF
Outer foot lightONOFF
Rear sunshade 
(
P. 3 7 2 )
Time elapsed before the
reverse operation feature
activates
0.7 seconds
0 seconds
0.9 seconds
1.2 seconds

574
6-2. Customization
GS_HV_U
December 12, 2007 3:50 pm
Multi-information display (P. 1 5 5 )
CountryAvailable language
CanadaEnglish and French

575
6
Vehicle specifications
GS_HV_U
December 12, 2007 3:50 pm
6-3. Initialization
Items to initialize
ItemWhen to initializeReference
Intuitive parking assist
• After reconnecting or changing the battery
• After changing a fuse
P. 5 1 2
Engine oil maintenance
data• After changing engine oilP. 4 2 5
Tire pressure warning
system
• When rotating the tires on vehicles differing with front and rear tire infla-
tion pressures.
• When changing the tire inflation pressure by changing traveling speed
or load weight, etc.
• When changing the tire size.
P. 4 3 7
After reconnecting or performing main tenance on the 12 volt battery, the
hybrid system may not start. ( P. 431) Also, the following items must be
initialized for normal system operation.

576
6-3. Initialization
GS_HV_U
December 12, 2007 3:50 pm

For owners7
577
GS_HV_U
December 12, 2007 3:30 pm
Reporting safety defects for 
U.S. owners ........................... 578
Seat belt instructions for 
Canadian owners 
(in French) .............................. 579

578
GS_HV_U
December 12, 2007 3:30 pm
Reporting safety defects for U.S. owners
If you believe that your vehicle has a defect which could cause a crash
or could cause injury or death, you should immediately inform the
National Highway Traffic Safety Administration (NHTSA) in addition
to notifying the Lexus Division of Toyota Motor Sales, U.S.A., Inc. (Toll-
free: 1-800-25-LEXUS).
If NHTSA receives similar complaints, it may open an investigation,
and if it finds that a safety defect exists in a group of vehicles, it may
order a recall and remedy camp aign. However, NHTSA cannot
become involved in individual problems between you, your dealer, or
the Lexus Division of Toyota Motor Sales, U.S.A., Inc.
To contact NHTSA, you may call the Vehicle Safety Hotline toll-
free at 1-888-327-4236 (TTY : 1-800-424-9153); go to
http://
www.safercar.gov
; or write to: Administrator, NHTSA, 1200
New Jersey Ave, S.E., Washington, DC 20590. You can also
obtain other informati on about motor vehicle safety from
http://
www.safercar.gov
.

579
7
GS_HV_U
December 12, 2007 3:30 pm
For owners
Seat belt instructions for Canadian owners (in French)
The following is a French explanation of seat belt instructions extracted
from the seat belt section in this manual.
See the seat belt section for more d etailed seat belt instructions in
English.
Utilisation adéquate des ceintures de sécurité
Tirez sur la ceinture épaulière
jusqu’à ce qu’elle recouvre
entièrement l’épaule; elle ne
doit cependant pas toucher le
cou ni glisser de l’épaule.
Placez la ceinture abdominale
le plus bas possible sur les
hanches.
Réglez la position du dossier du
siège. Tenez-vous assis dans le
fond du siège, le dos droit.
Ne vrillez pas la ceinture de
sécurité.
Guide des ceintures de sécurité (sièges latéraux arrière)
Si la ceinture épaulière est trop
près du cou d’une personne,
glissez le guide de la ceinture vers
l’avant.

580
GS_HV_U
December 12, 2007 3:30 pm
Entretien et soin
Ceintures de sécurité
Avec un tissu ou une éponge, nettoyez à l’aide d’un savon doux et de l’eau tiède.
Vérifiez aussi les ceintures régulièrement pour vous assurer qu’elles ne présentent
pas d’usure excessive, d’effilochage ou de coupures.
ATTENTION
Dommages et usure de la ceinture de sécuritéVérifiez périodiquement le système de ceintures de sécurité. Assurez-vous qu’il
n’y a pas de coupures, d’effilochures ni de pièces desserrées. N’utilisez pas une
ceinture de sécurité endommagée avant qu’elle soit remplacée. Les ceintures de
sécurité endommagées ne peuvent pas protéger les occupants contre les
blessures.
