radiator cap Lexus GS450h 2018 Owner's Manual / LEXUS 2018 GS450H OWNER'S MANUAL (OM30G62U)

353
GS450h_OM_OM30G62U_(U)6-3. Do-it-yourself maintenance
6
Maintenance and care
Engine compartment
■12-volt battery
→ P. 362
Engine oil level dipstick
(→P. 355)
Engine coolant reservoir (→P. 358)
Engine oil filler cap (→ P. 356)
Power control unit coolant
reservoir ( →P. 358) Brake fluid reservoir
(→P. 360)
Fuse box ( →P. 384)
Washer fluid tank ( →P. 361)
Electric cooling fans
Condenser ( →P. 359)
Radiator (→ P. 359)1
2
3
4
5
6
7
8
9
10

358
GS450h_OM_OM30G62U_(U)
6-3. Do-it-yourself maintenance
The coolant level is satisfactory if it is between the “FULL” and “LOW” lines on
the reservoir when the hybrid system is cold.
■Engine coolant reservoir
Reservoir cap
“FULL” line
“LOW” line
If the level is on or below the “LOW”
line, add coolant up to the “FULL”
line. ( →P. 461)
■Power control unit coolant reservoir
Reservoir cap
“FULL” line
“LOW” line
If the level is on or below the “LOW”
line, add coolant up to the “FULL”
line. ( →P. 461)
■Coolant selection
Only use “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol
based non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid
organic acid technology.
U.S.A.:
“Toyota Super Long Life Coolant” is a mixt ure of 50% coolant and 50% deionized water.
(Minimum temperature: -31 °F [-35 °C])
Canada:
“Toyota Super Long Life Cool ant” is a mixture of 55% coolant and 45% deionized water.
(Minimum temperature: -44° F [-42°C])
For more details about coolant, contact your Lexus dealer.
■If the coolant level drops within a short time of replenishing
Visually check the radiator, hoses, engine/power control unit coolant reservoir caps,
drain cock and water pump.
If you cannot find a leak, have your Lexus de aler test the cap and check for leaks in the
cooling system.
Coolant
1
2
3
1
2
3

GS450h_OM_OM30G62U_(U)
3596-3. Do-it-yourself maintenance
6
Maintenance and care
Check the radiator and condenser and clear away any foreign objects.
If either of the above parts is extremely dirty or you are not sure of their condi-
tion, have your vehicle inspected by your Lexus dealer.
WARNING
■When the hybrid system is hot
Do not remove the engine/power control un it coolant reservoir caps or the coolant
inlet cap. ( →P. 465)
The cooling system may be under pressure and may spray hot coolant if the cap is
removed, causing serious injuries, such as burns.
NOTICE
■When adding coolant
Coolant is neither plain water nor straight antifreeze. The correct mixture of water and
antifreeze must be used to provide proper lubrication, corrosion protection and cool-
ing. Be sure to read the antifreeze or coolant label.
■If you spill coolant
Be sure to wash it off with water to prevent it from damaging parts or paint.
Radiator and condenser
WARNING
■When the hybrid system is hot
Do not touch the radiator or condenser as they may be hot and cause serious injuries,
such as burns.

4627-2. Steps to take in an emergency
GS450h_OM_OM30G62U_(U)
The coolant level is satisfactory if it is between the “FULL” and “LOW” lines
on the reservoir.
Reservoir
“FULL”
“LOW”
Coolant inlet cap
Add coolant if necessary.
(→ P. 464)
Water can be used in an emergency
if engine coolant is unavailable.
Start the hybrid system and turn the air conditioning system on to check
that the radiator cooling fans operate and to check for coolant leaks from
the radiator or hoses.
The fans operate when the air conditioning system is turned on immediately after a
cold start. Confirm that the fans are operating by checking the fan sound and air
flow. If it is difficult to check these, tu rn the air conditioning system on and off
repeatedly. (The fans may not operate in freezing temperatures.)
If the fans are not operating:
Stop the hybrid system immediately and contact your Lexus dealer.
If the fans are operating:
Have the vehicle inspected at the nearest Lexus dealer.
4
1
2
3
4
5
6
7

4657-2. Steps to take in an emergency
GS450h_OM_OM30G62U_(U)
7
When trouble arises
WARNING
■When inspecting under the hood of your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.
●If steam is seen coming from under the h ood, do not open the hood until the steam
has subsided. The engine compartment may be very hot.
●After the hybrid system has been turned off, check that the indicator on the power
switch and the “READY” indicator are off.
When the hybrid system is operating, the gasoline engine may automatically start, or
the cooling fan may suddenly operate even if the gasoline engine stops. Do not touch
or approach rotating parts such as the fan, which may lead to fingers or clothing
(especially a tie, a scarf or a muffler) ge tting caught, resulting in serious injury.
NOTICE
■When adding engine/power control unit coolant
Add coolant slowly after the hybrid system has cooled down sufficiently. Adding cool
coolant to a hot hybrid system too quickly can cause damage to the hybrid system.
■To prevent damage to the cooling system
Observe the following precautions:
●Avoid contaminating the coolant with foreig n matter (such as sand or dust etc.).
●Do not use any coolant additive.
●Do not loosen the coolant inlet cap or the
coolant reservoir cap while the hybrid system
and radiator are hot.
High temperature steam or coolant could
spray out.

539Alphabetical index
GS450h_OM_OM30G62U_(U)
Radar cruise control (dynamic radar cruise control with
full-speed range) ............................... 243
Radiator .................................................... 359
Radio
*
RBDS (Radio Broadcast Data Systems)
*
Rear air conditioning system ........... 298
Rear door sunshades ........................... 318
Rear personal lights.............................305
Rear side marker lights ......................200 Light switch .......................................... 200
Replacing light bulbs ........................393
Welcome light illumination cont rol ..........................123
Rear seat heaters.................................. 302
Rear sunshade ........................................ 318 Operation ............................................... 318
Reverse operation feature.............. 319
Rear turn signal lights .......................... 195 Replacing light bulbs ........................393
Turn signal lever .................................. 195
Rear view mirror Inside rear view mirror ..................... 154
Outside rear view mirrors .............. 156
Rear view monitor system
*
Rear window defoggers .................... 293
Refueling ....................................................213 Capacity ................................................. 472
Fuel types ............................................... 472
Opening the fuel tank cap...............214
When the fuel filler door cannot be opened .......................... 215 Regenerative braking............................. 67
Remote Touch
*.................................... 282
Replacing Electronic key battery ..................... 382
Fuses ........................................................384
Light bulbs...............................................391
Tires ............................................................ 441
Reporting safety defects for U.S. owners ....................................510
Resetting the message indicating maintenance is required .................344
Rev indicator ............................................. 90
Rev peak ..................................................... 90
Road accident cautions ......................... 72
Seat belts .................................................... 30 Adjusting the seat belt........................ 30
Automatic Locking Retractor .......... 31
Child restraint system installation ............................................. 59
Cleaning and maintaining the seat belt ......................................... 341
Emergency Locking Retractor (ELR) ................................... 31
How to wear your seat belt............. 30
How your child should wear the seat belt ...........................................32
Pregnant women, proper seat belt use ......................................... 33
Reminder light and buzzer ...........406
Seat belt extender .................................32
Seat belt pretensioners........................ 31
SRS warning light .............................. 404
