Lexus GS460 2011 Owner's Manual / LEXUS 2011 GS350/GS460 QUICK GUIDE (OM30C25U) Service Manual

41
Quick_GS_G_U_(OM30C25U)
Interior Lights
ON
OFF
The light comes on if a door is opened.
Rear Sunshade
To raise the rear sunshade, press the switch.
Press the switch again to lower it.
Compass
To turn the compass on or off, press the button for
more than 3 seconds.
1
2
3
: If equipped

Quick_GS_G_U_(OM30C25U)
42
Luggage Mat
Pull the lever upwards when lifting the luggage
mat up.
The lever can be hooked on the edge of the trunk.

43
Quick_GS_G_U_(OM30C25U)
Garage Door Opener
The garage door opener (HomeLink® Universal Transceiver) is manufactured under
license from HomeLink®.
The HomeLink
® compatible transceiver in your
vehicle has 3 buttons which can be programmed
to operate 3 different devices.
Indicator
Buttons
■Programming HomeLink®
Hold your hand-held transmitter within 3
inches of the HomeLink® buttons.
Press and hold down the desired HomeLink
®
button.
For U.S.A. owners:
While pressing the HomeLink
® button,
press and hold down the button on the
hand-held transmitter until the indicator
light changes from a slow to a rapid flash.
For Canadian owners:
While pressing the HomeLink
® button,
repeatedly press and release (cycle) the
button on the hand-held transmitter every
2 seconds until the indicator light changes
from a slow to a rapid flash.
If your garage door is of the rolling code type:
Press the learn button on the motor-head unit
in your garage.
Press and hold the vehicle’s programmed
HomeLink
® button for 2 seconds and release
it. Repeat this step once again. The garage
door may open.
If the door does not open, press and
release the same button once again.
The garage door opener can be programmed to operate garage doors, gates, entry
doors, door locks, home lighting systems, security systems, and other devices.
1
2

Quick_GS_G_U_(OM30C25U)
44
■Programming other devices
For U.S.A. owners:
To program an entry gate, see the Owner’s Manual.
To program other devices, contact your Lexus dealer.
For Canadian owners:
To program all devices, follow the same procedure as for garage door programming.
■Operating HomeLink®
Press the appropriate HomeLink® button. The
indicator light should come on.

45
Quick_GS_G_U_(OM30C25U)
Safety Connect
■System components
“SOS” button
LED light indicators
Microphone
■Services
Subscribers have the following Safety Connect services available:
●Automatic Collision Notification*
In case of either airbag deployment or severe collision, the system is designed to auto-
matically call the response center. The responding agent receives the vehicle’s location
and attempts to speak with the vehicle occupants to assess the level of emergency. If the
occupants are unable to communicate, the agent automatically treats the call as an
emergency, contacts the nearest emergency services provider to describe the situation,
and requests that assistance be sent to the location.
*: U.S. Patent No. 7,508,298 B2
●Stolen Vehicle Location
If your vehicle is stolen, Safety Connect can work with local authorities to assist them in
locating and recovering the vehicle. After filing a police report, call the Safety Connect
response center at 1-800-25-LEXUS (1-800-255-3987) and follow the prompts for
Safety Connect to initiate this service.
In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-Con-
nect-equipped vehicle location data may, under certain circumstances, be shared with
third parties to locate your vehicle. Further information is available at Lexus.com.
: If equipped
Safety Connect is a subscription-based telematics service that uses Global Positioning
System (GPS) data and embedded cellular technology to provide safety and security
features to subscribers. Safety Connect is supported by Lexus’ designated response
center, which operates 24 hours per day, 7 days per week.
Safety Connect service is available by subscription on select, telematics hardware-
equipped vehicles.
1
2
3

Quick_GS_G_U_(OM30C25U)
46
●Emergency Assistance Button (SOS)
In the event of an emergency on the road, push the “SOS” button to reach the Safety
Connect response center. The answering agent will determine your vehicle’s location,
assess the emergency, and dispatch the necessary assistance required.
If you accidentally press the “SOS” button, tell the response-center agent that you are
not experiencing an emergency.
●Enhanced Roadside Assistance
Enhanced Roadside Assistance adds GPS date to the already included warranty-based
Lexus roadside service.
Subscribers can press the “SOS” button to reach a Safety Connect response-center
agent, who can help with a wide range of needs, such as: towing, flat tire, fuel delivery, etc.
For a description of the Roadside Assistance services and their limitations, please see the
Safety Connect Terms and Conditions, which are available at Lexus.com.
■Subscription
After you have signed the Telematics Subscription Service Agreement and are enrolled,
you can begin receiving services.
A variety of subscription terms is available for purchase. Contact your Lexus dealer, call
1-800-25-LEXUS (1-800-255-3987) or push the “SOS” button in your vehicle for fur-
ther subscription details.

47
Quick_GS_G_U_(OM30C25U)
Lexus Enform with Safety Connect
For details, refer to the “Owner’s Manual” and “Navigation System Owner’s Manual”.
■Services
With an active Lexus Enform subscription, the following features are available:
●Safety Connect features (P. 4 5 )
• Automatic collision notification*
1
• Stolen vehicle location
• Emergency assistance button (SOS)
• Enhanced roadside assistance
●Destination Assist
Destination Assist provides you with live assistance for finding destinations via the Lexus
Enform response center. You can request either a specific business, address, or ask for
help locating your desired destination by category, such as restaurants, gas stations,
shopping centers or other points of interest (POI).
After you tell the agent your choice of destination, its coordinates are sent wirelessly to
your vehicle’s navigation system.
●eDestination
With the eDestination feature, you can go online, via the Lexus.com owner’s Web site, to
select and organize destinations of your choice and then wirelessly send them to your
vehicle’s navigation system.
You can store up to 200 locations online to access and update at any time.
Your locations can be organized into up to 20 personalized folders.
You must first go online at www. lexus.com and go to the “Owners” section where you will
need to register and log in. After this, you can create your personalized folders contain-
ing the locations you wish to send to your vehicle. (See Lexus Enform Guide for more
information.)
: If equipped
Lexus Enform and Safety Connect are subscription-based telematics services that use
Global Positioning System (GPS) data, embedded cellular technology an XM® satellite
data services to provide safety and security as well as convenience features to subscrib-
ers.
Lexus Enform and Safety Connect services are supported by Lexus’ designated
response center, which operates 24 hours per day, 7 days per week.
Lexus Enform service is available by subscription on select, telematics hardware-
equipped vehicles.

Quick_GS_G_U_(OM30C25U)
48
●XM® Sports and Stocks*2
XM® Sports and Stocks is a service included with XM® satellite radio subscriptions for
Lexus Enform vehicles. With this service, you can receive updates via the navigation sys-
tem on your personally selected sports teams and stocks.
●XM NavWeather
TM*3
The subscription-based XM NavWeatherTM service allows the navigation system to dis-
play weather information on the map.
●XM
® NavTraffic*3
The subscription-based XM® NavTraffic service allows the navigation system to display
traffic information on the map.
The following navigation-based Lexus Enform features are available without a sub-
scription:
●Lexus Insider
Lexus Insider is an optional service that can send audio messages, or articles, to partici-
pating owner’s vehicles via the navigation system. Potential Lexus Insider subjects might
include, for example, Lexus vehicle technology tips, updates on regional Lexus events, or
audio excerpts from Lexus Magazine articles. Up to 20 articles can be stored at a time.
●Vo i c e C o m m a n d
The voice command system enables you to operate the navigation system, audio/video
system, air conditioning system and hands-free system by giving a command.
*
1: U.S. Patent No. 7,508,298 B2
*
2: Available at no extra charge with an active XM® satellite radio subscription.
*
3: Available via separate XM® subscription(s).
■Subscription
After you have signed the Telematics Subscription Service Agreement and are enrolled,
you can begin receiving services. A variety of subscription terms is available for purchase.
Contact your Lexus dealer, call 1-800-25-LEXUS (1-800-255-3987), or touch the “Des-
tination Assist” button in your vehicle for further subscription details. XM
® NavTraffic and
XM NavWeather
TM require separate XM® subscription(s). XM® Sports and Stocks is
available with an XM® Satellite Radio subscription. After a 90-day free trial, you must set up
the appropriate XM® subscription(s) to continue receiving these services.

49
Quick_GS_G_U_(OM30C25U)
Door Locks
■Locking the vehicle from inside
Inside lock button
Locks
Unlocks
Door lock switch
Operates all door locks.
Locks
Unlocks
■Locking the vehicle from outside
Using the entry function or wireless remote control (P. 8 , 9 )
■Rear door child-protector lock
Setting the switch to the LOCK position prevents
the rear doors from being opened from the inside.
1
2
1
2

Quick_GS_G_U_(OM30C25U)
50
Powe r Wi n d ows
Powe r w i n d ow s w i t c h e s
To o p e n : press the switch.
To c l o s e : pull the switch up.
Fully pulling up and releasing the switches
causes the windows to close fully. Fully
pressing down and releasing the switches
causes the windows to open fully.
Window lock switch
The window lock switch disables the opera-
tion of all windows other than the driver’s
door window.
Moon Roof
■Opening and closing
Open
Stops just before it is opened fully. Press the
switch again to fully open.
Close
To stop partway, press the switch lightly.
■Tilt up and down
Tilt up
Tilt down
To stop partway, press the switch lightly.
1
2
: If equipped
1
2
1
2
