lights Lexus GS460 2011 Owner's Manual / LEXUS 2011 GS350/GS460 OWNERS MANUAL QUICK GUIDE (OM30C25U)

1
Quick_GS_G_U_(OM30C25U)
Contents
Air Conditioning System
Basic operation .................................................................................................................................33
Using the automatic mode ...........................................................................................................34
Adjusting the temperature in DUAL mode ..........................................................................34
Ashtrays ................................................................................................................................................... 37
Audio System
Basic operation .................................................................................................................................35
Listening to the radio ......................................................................................................................36
Playing the CD/DVD player .......................................................................................................36
Automatic Transmission ..................................................................................................................... 18
AVS (Adaptive Variable Suspension System)..........................................................................25
Compass................................................................................................................................................... 41
Console Box...........................................................................................................................................39
Cruise Control ...................................................................................................................................... 22
Cup Holders ..........................................................................................................................................40
Door Locks ............................................................................................................................................. 49
Driving Position Memory System................................................................................................... 12
Dynamic Radar Cruise Control..................................................................................................... 23
Emergency Flasher Switch...............................................................................................................20
Engine (Ignition) Switch.......................................................................................................................17
Fog Lights ................................................................................................................................................ 27
Fuel Tank Cap ......................................................................................................................................... 51
Garage Door Opener ....................................................................................................................... 43
Glove Box ...............................................................................................................................................40
Hands-free System (For Cellular Phone) .................................................................................. 37
Headlight Cleaner ...............................................................................................................................30
Headlights ............................................................................................................................................... 26
Head Restraints...................................................................................................................................... 13
Hood........................................................................................................................................................... 51
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manuals so you will have a better
understanding of your vehicle’s capabilities and limitations.

2
Quick_GS_G_U_(OM30C25U)
Depending on specifications, the vehicle shown in the illustration may
differ from your vehicle in terms of color and equipment.
Inside Rear View Mirror ..................................................................................................................... 15
Instrument Panel Light Control ..................................................................................................... 30
Interior Lights .......................................................................................................................................... 41
Intuitive Parking Assist ........................................................................................................................ 21
Keys...............................................................................................................................................................8
Lexus Enform with Safety Connect .............................................................................................. 47
Luggage Mat.......................................................................................................................................... 42
Mode Select Switch ............................................................................................................................20
Moon Roof ............................................................................................................................................. 50
Multi-Information Display.................................................................................................................. 19
Odometer/Trip Meter and Trip Meter Reset Buttons ........................................................... 16
Outside Rear View Mirrors .............................................................................................................. 15
Overview .................................................................................................................................................... 3
Parking Brake.......................................................................................................................................... 18
Power Windows ................................................................................................................................... 50
Rear Sunshade ....................................................................................................................................... 41
Rear Window and Outside Rear View Mirror Defoggers ................................................ 30
Safety Connect ..................................................................................................................................... 45
Seat Belts .................................................................................................................................................. 14
Seat Heaters/Ventilators ................................................................................................................. 38
Seats .............................................................................................................................................................11
Smart Access System with Push-button Start............................................................................. 9
Steering Wheel ...................................................................................................................................... 16
Theft Deterrent System ...................................................................................................................... 10
Touch Screen........................................................................................................................................... 31
TRAC/VSC Off Mode......................................................................................................................25
Trunk .......................................................................................................................................................... 52
Turn Signal Lever ..................................................................................................................................20
Windshield Wipers and Washers ..................................................................................................28

Quick_GS_G_U_(OM30C25U)
20
Tu r n S i g n a l L e v e r
Right turn signal
Left turn signal
Emergency Flasher Switch
Engaging the emergency flasher switch causes all
the turn signal lights to flash.
Mode Select Switch
Powe r m o d e
For more powerful acceleration and uphill
driving.
Normal mode
Snow mode
For starting or accelerating on snow-covered
roads or other slippery surfaces.
An indicator comes on when in power or snow
mode.
1
2
To signal a lane change, move the lever partway and hold.
Use the mode select switch to select the driving mode that best suits the driving and road
conditions.
1
2
3

Quick_GS_G_U_(OM30C25U)
26
Headlights
The side marker, parking, tail, license plate and
instrument panel lights turn on.
The headlights and all lights listed above turn on.
The headlights and parking lights turn on/off
automatically in accordance with ambient light
levels.
To engage the high beams, push the lever forward.
To flash the high beams, pull the lever and hold.
■AFS (Adaptive Front lighting System) (if equipped)
AFS improves visibility on curves by automatically adjusting the horizontal orientation of the
headlights in accordance with vehicle speed and the degree of the tire angle that are con-
trolled by steering input.
The system can be turned on and off using the
“AFS OFF” switch.
1
2
3

27
Quick_GS_G_U_(OM30C25U)
Fog Lights
The fog lights can be used only when the head-
lights (low beam) are on.

Quick_GS_G_U_(OM30C25U)
30
Headlight Cleaner
The headlight cleaner can be used only when the
“ENGINE START STOP” switch is in IGNITION
ON mode and the headlights are on.
Rear Window and Outside Rear View
Mirror Defoggers
To defog the rear window and outside mirrors,
press the button.
Press again to cancel.

Instrument Panel Light Control
Brighter
Darker
Maximum brightness
Changes the cluster glass tint
: If equipped
The system turns off automatically after 15 to 60 minutes.
1
2
3
4

41
Quick_GS_G_U_(OM30C25U)
Interior Lights
ON
OFF
The light comes on if a door is opened.
Rear Sunshade
To raise the rear sunshade, press the switch.
Press the switch again to lower it.
Compass
To turn the compass on or off, press the button for
more than 3 seconds.
1
2
3
: If equipped

What to do if ...
53
Quick_GS_G_U_(OM30C25U)
List of Warning/Indicator Lights
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
(U.S.A.)
(Canada)Brake system warning light
Stop the vehicle immediately.
Charging system warning light
Have the vehicle inspected immediately.
(U.S.A.)
(Canada)Malfunction
indicator lampSRS warning light
ECB*1 warning light
(U.S.A.)
(Canada)ABS warning light
Electric power steering
warning light
Pre-collision system
warning light*2
(Flashing and
then continu-
ously on)Tire pressure warning light
For further information, refer to the Owner’s Manual.

Customizing Your Lexus
61
Quick_GS_G_U_(OM30C25U)
*1: This function cannot be customized unless power window operation using the wireless
remote control is enabled.
*
2: Vehicles sold outside Canada
ItemFunctionDefault
settingCustomized
setting
Moon roof
Linked door key operationOpen and
closeOpen only
Close only
Linked operation of components
when door key is usedSlide onlyTilt only
Wireless remote control linked
operation*
1OFFOpen
Linked operation of components
when wireless remote control
used*
1
OFFSlide only
Tilt only
Automatic light
control system
Light sensor sensitivityLevel 3Levels 1 to 5
Time elapsed before headlights
automatically turn off after
doors are closed
30 seconds
0 seconds
60 seconds
90 seconds
Daytime running lightONOFF*2
Windshield
wipers and
washer
Switching operation when the
vehicle is stationaryONOFF
Drip prevention functionONOFF
Time elapsed before the drip
prevention function operates
Va r i a b l e
depending on
the vehicle
speed
3 seconds

Quick_GS_G_U_(OM30C25U)
62
ItemFunctionDefault
settingCustomized
setting
Illumination
Time elapsed before lights turn
off15 seconds7. 5 s e c o n d s
30 seconds
Operation when the doors are
unlockedONOFF
Operation after the “ENGINE
START STOP” switch turned
OFF
ONOFF
Front/rear personal lights
turned on when a door is
openedCorrespond-
ing light onlyAll lights
OFF
Foot lightsONOFF
Shift lever lightONOFF
Outer foot lightONOFF
Front/rear personal lights
turned on when the interior
lights are switched “ON”
ONOFF
Rear sunshade
Time elapsed before the
reverse operation feature acti-
vates
0.7 seconds
0 seconds
0.9 seconds
1.2 seconds
