2-4. Using other driving systems
GX460_U.S.A. (OM60E69U)
■The rear view monitor can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
■Displayed area
The area covered by the camera is limited.
Objects which that are close to either corner
of the bumper or under the bumper cannot
be seen on the screen.
The area displayed on the screen may vary
depending on vehicle orientation or road
conditions.
Corners of bumper

284
2-4. Using other driving systems
GX460_U.S.A. (OM60E69U)
■The wide view front & side monitor can be operated when
●The “ENGINE START STOP” switch is in IGNITION ON mode.
●The vehicle speed is less than approximately 6 mph (10km/h).
■Automatic system cancelation
In the following situations, the system is canceled automatically.
●When the vehicle speed exceeds approximately 7 mph (12 km/h).
●When the shift lever is in P or R.
■When the outside rear view mirrors have been folded
The side monitor screen can be displayed even if the outside rear view mirrors have
been folded. In this case, there will be a slight difference between the image dis-
played when the outside rear view mirrors are extended and when the outside rear
view mirrors have been folded.
If the side monitor is displayed while the outside rear view mirrors are folded, you
cannot check the area near the front edge of the vehicle as the base of the outside
rear view mirrors will be in the way.

291
2-4. Using other driving systems
2
When driving
GX460_U.S.A. (OM60E69U)
Multi-terrain Select
: If equipped
Multi-terrain Select is a system that improves drivability in off-road situa-
tions.
Select a mode that most closely matches the type of terrain on
which you are driving from among 4 modes. 
Engine control and brake control can be optimized in accordance
with the selected mode.
Menu switch
“ENTER” switch
Multi-information display
Displays status information
including operating status
and road type selection.
Multi-terrain Select indicator

311
2-4. Using other driving systems
2
When driving
GX460_U.S.A. (OM60E69U)
Rear height control air suspension
Selecting vehicle heightOperating the switch changes vehicle rear height as follows: Higher
Lower
Vehicle height can be adjusted
only when the engine is running.
The selected height mode will be
shown on the rear height control
air suspension display.
The selected mode will flash while
the height mode is being changed.
: If equipped
The rear height control air suspension allows the driver to control vehicle
rear height in order to adjust drivin g conditions. Select the desired height
with the height control switch.
Height control OFF switch
Height control switch

313
2-4. Using other driving systems
2
When driving
GX460_U.S.A. (OM60E69U)
Disabling the height controlWhen the height control OFF
switch is pressed with the vehicle
stopped, the vehicle height is fixed
at the current height.
This status is memorized in the sys-
tem even after the engine is
stopped.
The height can be adjusted by
pressing the height control OFF
switch again.
When vehicle speed exceeds
18 mph (30 km/h), the rear height
control air suspension turns on
automatically.

314
2-4. Using other driving systems
GX460_U.S.A. (OM60E69U)
■When HI mode is selected
The vehicle height will change to N mode when driving at the speeds of 18 mph (30
km/h). 
Even if vehicle speed is then reduced to under 18 mph (30 km/h), height will not
return to HI mode.
■When LO mode is selected
The vehicle height will change to N mode when vehicle speed exceeds 7 mph
(12 km/h). 
Even if vehicle speed is then reduced to under 7 mph (12 km/h), height will not
return to LO mode.
■Automatic leveling function
Regardless of the number of occupants and the luggage load, vehicle height in any
mode is always adjusted to a fixed height by the automatic leveling function.
■The rear height control air suspension will not operate in the following cases:
●The underbody of the vehicle is touching the surface of the road.
●The area around the suspension is covered with ice.
■Even if you hear an operating noise
This does not indicate a problem in the rear height control air suspension.
■Parking and stopping tips
●If you immediately stop the engine after of f-road driving, or park the vehicle for
a long time, the vehicle height may gradually lower. When parking, make sure
there is nothing under the vehicle that ma y come in contact with the underbody.
The vehicle will return to the set height when the engine is started.
●The vehicle height may change as the temperature changes when the engine is
stopped. The vehicle will return to the set height when the engine is started.

315
2-4. Using other driving systems
2
When driving
GX460_U.S.A. (OM60E69U)
■When lowering the vehicle
In order to prevent the vehicle height from rising as occupants leave the vehicle,
lowering control will occur for a short while after the engine has been stopped.
■The rear height control air suspension failure warning
●If a malfunction occurs in the rear height control air suspension, N mode is auto-
matically selected. However, the system may not switch to N mode depending
on the location of the malfunction.
●The warning message is displayed on the multi-information display, and the rear
height control air suspension cannot be activated until the malfunction is cor-
rected. 
Stop the engine and start it again. If th e warning message turns off, the system is
operating correctly. If the warning mess age continues to be displayed, have
your vehicle inspected by your Le xus dealer as soon as possible.
CAUTION
■The rear height control air suspension must be turned off when
In the following situations, the automatic leveling function may cause vehicle height
to change, resulting in an unexpected accident:
●When jacking up the vehicle, installing tire chains or tying the vehicle with chains/
wires for transportation via flat bed truck (Turn off the rear height control air sus-
pension and stop the engine.)
●When the vehicle must be towed or disconnecting a trailer (Put the vehicle height
in N mode and turn off the rear height control air suspension.)
●When the vehicle is stuck (Turn off th e rear height control air suspension.)

321
2-4. Using other driving systems
2
When driving
GX460_U.S.A. (OM60E69U)
■When the four-wheel drive control switch can be operated
●The “ENGINE START STOP” switch is in IGNITION ON mode.
●The shift lever is in the N position.
●The vehicle is stopped completely.
■The low speed four-wheel drive indicator light
●The indicator light blinks while switching between H4 and L4.
●If the low speed four-wheel drive indicator light continues to blink when you
operate the four-wheel drive control switch to the H4 or L4 position, stop the
vehicle completely, shift the shift lever securely into N and then operate the
switch again.
●If the shift lever is moved before the low speed four-wheel drive indicator turns
on/off, the transfer mode may not be shifted completely. The transfer mode dis-
engages both the front and rear drive shafts from the powertrain and allows the
vehicle to move regardless of the shift position. (At this time, the indicator blinks
and the buzzer sounds.) 
Therefore, the vehicle is free to roll even if the shift lever is in P. You or someone
else could be seriously injured. You must complete the shifting of the transfer
mode and confirm that the indicator light has turned off (H4) or turned on (L4).
●If the engine coolant temperature is too low, the four-wheel drive control system
may not be able to shift. When the engine is warmer operate the switch again.
If the indicator continue to blink even if doing so, have the vehicle inspected by your
Lexus dealer as soon as possible. There may be a trouble in the four-wheel drive
system.

322
2-4. Using other driving systems
GX460_U.S.A. (OM60E69U)
■When the center differential lock/unlock switch can be operated
The “ENGINE START STOP” switch is in IGNITION ON mode.
■The center differential lock indicator light
●The indicator light blinks while lockin g/unlocking the center differential.
●If the center differential lock indicator light blinks and the buzzer sounds when
the center differential is locked, stop the slipping or spinning and push the
switch again.
If the indicator continue to blink even if doing so, have the vehicle inspected by your
Lexus dealer as soon as possible. There may be a trouble in the four-wheel drive
system.
■Locking/unlocking the center differential
●When the four-wheel drive control switch is in L4 with the center differential
locked, VSC is automatically turned off. (The center differential lock and VSC
OFF indicator light will come on.)
●If the operation is not completed, the center differential lock indicator blinks. If
the indicator light does not turn off when unlocking the center differential, drive
straight ahead while accelerating or decelerating, or drive in reverse.
●Avoid turning suddenly while the center diff erential is locked. If you do turn sud-
denly, the difference in turning speeds between the front and rear wheels may
have a similar effect to braking, thus making driving difficult.

326
2-4. Using other driving systems
GX460_U.S.A. (OM60E69U)
■Automatic system cancelation
In the following situations, the system is canceled automatically:
At that time, the buzzer will sound, the slip indicator turns off, and the Crawl Con-
trol indicator flashes. 
A notification will be displayed on the multi-information display for several seconds.
(  P. 6 9 8 )
●When the shift lever is moved to P or N.
●When the four-wheel drive control switch is in H4.
●When the driver’s door is opened.
When turning off Crawl Control while traveling, stop the vehicle before the Crawl
Control indicator turns off, or drive extremely carefully.
■Function limit
●In the following situations, you will be able to use brake control to drive downhill
at a fixed low speed, but you will be unable to use engine control to drive uphill
at a fixed low speed.
• When the driving mode is set to second start mode.
• When the vehicle speed is higher than 6 mph (10 km/h).
●In the following situation, engine contro l and brake control will stop temporarily: 
At that time, the Crawl Control indicator flashes.
When the vehicle speed is higher than 15 mph (25 km/h).
■When the Crawl Control system is operated continuously
This may cause the brake actuator to overheat. In this case, the Crawl Control sys-
tem will stop operating, a buzzer will sound, the Crawl Control indicator will turn off
after flashing and the TRAC OFF will be show n on the multi-information display. In
this case, quickly stop the vehicle in a sa fe place and give the actuator adequate
time to cool off. Refrain from using the sy stem until the message goes off. (The vehi-
cle can be driven normally during this time.)
