display Lexus GX460 2010 Scheduled Maintenance Guide / LEXUS 2010 GX460 OWNERS MANUAL (OM60E69U)

499
3-4. Using the hands-free system (for cellular phone)
3
Interior features
GX460_U.S.A. (OM60E69U)
Security and system setup
■Security setting items and operation procedures
To enter the menu for each function , follow the steps below using a
voice command or the “TUNE/SEL” knob:
●Setting or changing the PIN (Personal Identification Number) 
1. “Setup”  2. “Security”  3. “Set PIN”
● Locking the phone book 
1. “Setup”  2. “Security”  3. “Phonebook Lock (Phbk Lock)”
● Unlocking the phone book 
1. “Setup”  2. “Security”  
3. “Phonebook Unlock (Phbk Unlock)”
■ System setup items and operation procedures
To enter the menu for each function , follow the steps below using the
“TUNE/SEL” knob:
●Setting voice guidance volume 
1. “Setup”  2. “System Setup”  3. “Guidance Vol”
● Displaying the Bluetooth
® device address and name 
1. “Setup”  2. “System Setup”  3. “Device Name”
● Initializing the system 
1. “Setup”  2. “System Setup”  3. “Initialize”

501
3-4. Using the hands-free system (for cellular phone)
3
Interior features
GX460_U.S.A. (OM60E69U)
Setting voice guidance volumeSelect “Guidance Vol” using the “TUNE/SEL” knob.
Change the voice guidance volume.
To decrease the volume: Turn the “TUNE/SEL” knob counterclockwise.
To increase the volume: Turn the “TUNE/SEL” knob clockwise.
Displaying the Bluetooth® device address and name
Select “Device Name” using the “TUNE/SEL” knob.
Turn the “TUNE/SEL” knob to display the Bluetooth
® device
address and name.
Select “Go Back” using the “TUNE/SEL” knob to return to “Sys-
tem Setup”.
Initializing the system
Select “Initialize” and then “Confirm” using the “TUNE/SEL”
knob.
Select “Confirm” again using the “TUNE/SEL” knob.
STEP1
STEP2
STEP1
STEP2
STEP3
STEP1
STEP2

506
3-4. Using the hands-free system (for cellular phone)
GX460_U.S.A. (OM60E69U)Selecting a phone number from outgoing or incoming call history:
STEP2-1 Select “Call History” us ing a voice command or the
“TUNE/SEL” knob.
STEP2-2 Select “Outgoing” or “Incoming” using a voice com-
mand or the “TUNE/SEL” knob.
STEP2-3 Select the data to be reg istered by either of the follow-
ing methods:
a. Say “Previous” or “Go back” until the desired data is
displayed, and select “Confirm” using a voice com-
mand.
b. Select the desired data using the “TUNE/SEL” knob.
Select the name to be registered by either of the following meth-
ods, and select “Confirm” usin g a voice command or the “TUNE/
SEL” knob:
a. Press the talk switch and say the desired name.
b. Select “Record Name” using the “TUNE/SEL” knob, and say the desired name.
Select “Confirm” using a voic e command or the “TUNE/SEL”
knob.
In , selecting “Set Speed Dial (Speed Dial)” instead of “Con-
firm” registers the newly added phone number as a speed dial.
STEP3
STEP4
STEP4

529
3-7. Other interior features
3
Interior features
GX460_U.S.A. (OM60E69U)
■Items unsuitable for the cool box
●Drinks in unsealed containers
●Fragile items, perishables or anything with strong odor
●Owner’s manual, electronic devices, CDs, etc.
■When the indicator light flashes
The cool box is not operated when any of the following conditions occurs.
●When the air conditioning system is off 
Turn the air conditioning system on also turns on the cool box.
●When outside air temperature is about 32 F (0 C) or below.
●When the “A/C ON” in the multi-information display (accessory meter) 
(  P. 3 8 4 ) a l s o f l a s h e s 
Press the “A/C” button to turn off the cooling and dehumidification function and
turn it on again.
If the indicator light continues to flash, there may be a malfunction in the system.
Turn the air conditioning system off and have it inspected by your Lexus dealer.
■When using the cool box lid as an armrest
Slide the cool box lid forward or backward as
needed. Slide the lid while pulling up the
upper lever to release the lock.

533
3-7. Other interior features
3
Interior features
GX460_U.S.A. (OM60E69U)
Clock
■The clock is displayed when
The “ENGINE START STOP” switch is in IGNITION ON mode.
■When disconnecting and reconnecting battery terminals
The clock data will be reset.
Vehicles with a navigation system
Refer to the “Navigation System Owner’s Manual”.
Vehicles without a navigation systemAdjusts the hours
Adjusts the minutes

575
3-7. Other interior features
3
Interior features
GX460_U.S.A. (OM60E69U)
Compass
The compass on the inside rear view mirror indicates the direction in which
the vehicle is heading.
■ Operation
To turn the compass on or off,
press “AUTO” for more than 3
seconds.
■ Displays and directions
DisplayDirection
“N”North
“NE”Northeast
“E”East
“SE”Southeast
“S”South
“SW”Southwest
“W”We s t
“NW”Northwest

576
3-7. Other interior features
GX460_U.S.A. (OM60E69U)
Calibrating the compassThe direction display deviates from the true direction determined by the
earth’s magnetic field. The amount of deviation varies according to the
geographic position of the vehicle.
If you cross over one of the map boundaries shown in illustration, the com-
pass will deviate. 
To obtain higher precision or perfect calibration, refer to “Deviation calibra-
tion”.

577
3-7. Other interior features
3
Interior features
GX460_U.S.A. (OM60E69U)■
Deviation calibration
Stop the vehicle in a place where it is safe to drive in a circle.
Press and hold “AUTO”. 
A number (1 to 15) appears on the
compass display.
Referring to the map above, pres s “AUTO” to select the number
of the zone you are in.
If the direction is displayed severa l seconds after adjustment, the cali-
bration is complete.
■ Circling calibration
When “C” appears on the display,
drive the vehicle at 5 mph (8 km/h)
or less in a circle until a direction is
displayed.
If there is not enough space to
drive in a circle, drive around the
block until the direction is dis-
played.
STEP1
STEP2
STEP3

578
3-7. Other interior features
GX460_U.S.A. (OM60E69U)
■Conditions unfavorable to correct operation
The compass may not show the correct direction in the following conditions:
●The vehicle is stopped immediately after turning.
●The vehicle is on an inclined surface.
●The vehicle is in a place where the earth’s magnetic field is subject to interfer-
ence by artificial magnetic fields (underground car park/parking lot, under a
steel tower, between buildings, roof car park/parking lot, near an intersection,
near a large vehicle, etc.).
●The vehicle has become magnetized. 
(There is a magnet or metal object near the inside rear view mirror.)
●The battery has been disconnected.
●A door is open.
CAUTION
■While driving the vehicle
Do not adjust the display. Adjust the di splay only when the vehicle is stopped.
■When doing the circling calibration
Secure a wide space, and watch out for people and vehicles in the vicinity. Do not
violate any local traffic rules while performing circling calibration.

613
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_U.S.A. (OM60E69U)
■After changing the engine oil (U.S.A. only)
The engine oil maintenance data should be reset. Perform the following proce-
dures:
Press the Menu switch ( P. 212) to change the multi-information display
to blank.
Turn the “ENGINE START STOP” switch off.
While pressing the ODO/TRIP button ( P. 1 9 5 ) , t u r n t h e “ E N G I N E
START STOP” switch to IGNITION ON mode.
Continue to press and hold the butto n for more than 7 seconds after the
“ENGINE START STOP” switch is turned to IGNITION ON mode.
STEP1
STEP2
STEP3
STEP4
The message shown in the illustration will
appear on the display. After 5 seconds, the
system reset will be completed.
