1-1. Key informationKeys ...................................................... 26
1-2. Opening, closing and locking 
the doors and trunk
Smart access system with  push-button start .......................... 29
Wireless remote control .............. 48
Side doors ........................................... 51
Back door ........................................... 54
Glass hatch ........................................ 59
1-3. Adjustable components (seats, 
mirrors, steering wheel, etc.)
Front seats .......................................... 64
Rear seats ........................................... 68
Driving position memory 
(driver’s seat) ................................. 79
Head restraints................................ 83
Seat belts ............................................ 86
Steering wheel.................................. 94
Inside rear view mirror .................. 96
Outside rear view mirrors ........... 97 1-4. Opening and closing the windows

and moon roof
Power windows............................... 101
Moon roof ........................................ 104
1-5. Refueling Opening the fuel tank cap......... 109
1-6. Theft deterrent system Engine immobilizer system ......... 114
Alarm.................................................... 116
1-7. Safety information Correct driving posture ............... 119
SRS airbags ....................................... 121
Front passenger occupant 
classification system .................. 140
Child restraint sy stems ............... 147
Installing child restraints ............. 152
1Before driving

Before driving1
25
GX460_U.S.A. (OM60E69U)
1-1. Key informationKeys ............................................... 26
1-2. Opening, closing and 
locking the doors and trunk
Smart access system with 
push-button start .................... 29
Wireless remote control ........ 48
Side doors..................................... 51
Back door .................................... 54
Glass hatch ................................. 59
1-3. Adjustable components 
(seats, mirrors, 
steering wheel, etc.)
Front seats ................................... 64
Rear seats .................................... 68
Driving position memory 
(driver’s seat) ........................... 79
Head restraints ......................... 83
Seat belts ..................................... 86
Steering wheel ........................... 94
Inside rear view mirror ............ 96
Outside rear view mirrors ...... 97 1-4. Opening and closing

the windows and moon roof
Power windows ......................... 101
Moon roof ................................. 104
1-5. Refueling Opening the fuel tank 
cap ............................................ 109
1-6. Theft deterrent system Engine immobilizer 
system....................................... 114
Alarm............................................ 116
1-7. Safety information Correct driving posture ........ 119
SRS airbags ............................... 121
Front passenger occupant 
classification system............ 140
Child restraint systems .......... 147
Installing child restraints....... 152

109
1
Before driving
GX460_U.S.A. (OM60E69U)
1-5. Refueling
Opening the fuel tank cap
Perform the following steps to open the fuel tank cap.
■Before refueling the vehicle
Turn the “ENGINE START STOP” swit ch off and ensure that all the
doors and windows are closed.
■ Opening the fuel tank cap
Press the opener to open the
fuel filler door.
Turn the fuel tank cap slowly to
open.
STEP1
STEP2

110
1-5. Refueling
GX460_U.S.A. (OM60E69U)
Closing the fuel tank capAfter refueling, turn the fuel tank
cap until you hear a click. Once
the cap is released, it will turn
slightly in the opposite direction.
Hang the fuel tank cap on the
back of the fuel filler door.STEP3

111
1-5. Refueling
1
Before driving
GX460_U.S.A. (OM60E69U)
■If the fuel filler door opener is inoperable
■Fuel types
Use premium unleaded gasoline. (Octane Rating 91 [Research Octane Number
96] or higher)
■Fuel tank capacity
Approximately 23.0 gal. (87 L, 19.1 Imp. gal.)
■Use of ethanol blended gasoline in a gasoline engine
Lexus allows the use of ethanol blended gasoline where the ethanol content is up to
10 %. Make sure that the ethanol blended gasoline to be used has a Research
Octane Number that follows the above.
The lever can be used to open the fuel filler
door if the fuel filler door cannot be opened
using the inside switch.

112
1-5. Refueling
GX460_U.S.A. (OM60E69U)
CAUTION
■When refueling the vehicle
Observe the following precautions while refueling the vehicle. Failure to do so may
result in death or serious injury.
●After exiting the vehicle and before opening the fuel door, touch an unpainted
metal surface to discharge any static electricity. It is important to discharge static
electricity before refueling because sparks resulting from static electricity can
cause fuel vapors to ignite while refueling.
●Always hold the grips on the fuel tank cap and turn it slowly to remove it. 
A whooshing sound may be heard when the fuel tank cap is loosened. Wait until
the sound cannot be heard before fully re moving the cap. In hot weather, pressur-
ized fuel may spray out the filler neck and cause injury.
●Do not allow anyone that has not discharged static electricity from their body to
come close to an open fuel tank.
●Do not inhale vaporized fuel.
Fuel contains substances that are harmful if inhaled.
●Do not smoke while refueling the vehicle. 
Doing so may cause the fuel to ignite and cause a fire.
●Do not return to the vehicle or touch an y person or object that is statically
charged. 
This may cause static electricity to build up , resulting in a possible ignition hazard.

113
1-5. Refueling
1
Before driving
GX460_U.S.A. (OM60E69U)
CAUTION
■When refueling
Securely insert the fuel nozzle into the fuel filler neck. If fuel is added with the nozzle
slightly lifted away from the fuel filler neck, the automatic shut off function may not
operate, resulting in fuel overflowing from the tank.
■When replacing the fuel cap
Do not use anything but a genuine Lexus fuel tank cap designed for your vehicle.
Doing so may cause a fire or other incident which may result in death or serious
injury.
NOTICE
■Refueling
Do not spill fuel during refueling. 
Doing so may damage the vehicle, such as causing the emission control systems to
operate abnormally or damaging fuel syst em components or the vehicle’s painted
surface.

353
2-5. Driving information
2
When driving
GX460_U.S.A. (OM60E69U)
Cargo and luggage
Take notice of the following information about storage precautions, cargo
capacity and load:
● Stow cargo and luggage in the luggage compartment whenever
possible.
● Be sure all items are secured in place.
● To maintain vehicle balance while driving, position luggage evenly
within the luggage compartment.
● For better fuel economy, do not carry unnecessary weight.

601
4-2. Maintenance
4
Maintenance and care
GX460_U.S.A. (OM60E69U)
Emission inspection and maintenance (I/M) programs
Some states have vehicle emission inspection programs which include
OBD (On Board Diagnostics) checks. The OBD system monitors the oper-
ation of the emission control system.
■ If the malfunction indicator lamp comes on
The OBD system determines that a problem exists somewhere in
the emission control system. Your vehicle may not pass the I/M test
and may need to be repaired. Contact your Lexus dealer to service
the vehicle.
■ Your vehicle may not pass the I/M test in the following situations:
●When the battery is disconnected or discharged
Readiness codes that are set during ordinary driving are erased. 
Also, depending on your driving habits, the readiness codes may
not be completely set.
● When the fuel tank cap is loose
The malfunction indicator lamp comes on a temporary malfunc-
tion and your vehicle may not pass the I/M test.
■ When the malfunction indicator la mp still remains on after several
driving trips
The error code in the OBD system will not be cleared unless the
vehicle is driven 40 or more times.
■ If your vehicle does not pass the I/M test
Contact your Lexus dealer to prep are the vehicle for re-testing.

636
4-3. Do-it-yourself maintenance
GX460_U.S.A. (OM60E69U)
.
■Tire inflation pressure check interval
You should check tire inflation pressure every 2 weeks, or at least once a month.
Do not forget to check the spare.
■Effects of incorrect tire inflation pressure
Driving with incorrect tire inflation pressure may result in the following:
●Reduced fuel efficiency
●Reduced driving comfort and tire life
●Reduced safety
●Damage to the drive train
If a tire needs frequent refilling, have it checked by your Lexus dealer.
■Instructions for checking tire inflation pressure
When checking tire inflation pressure, observe the following:
●Check only when the tires are cold. 
If your vehicle has been parked for at least 3 hours and has not been driven for
more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure
reading.
●Always use a tire pressure gauge. 
The appearance of the tire can be misleading. In addition, tire inflation pressures
that are even just a few pounds off can degrade ride and handling.
●Do not bleed or reduce tire inflation pressure after driving. It is normal for the
tire inflation pressure to be higher after driving.
●Never exceed the vehicle capacity weight. 
Passengers and luggage weight should be placed so that the vehicle is bal-
anced.
