GX460_U.S.A. (OM60E69U)
3-6. Using the storage featuresList of storage fe atures................ 515
• Glove box ..................................... 516
• Console box ................................. 517
• Coin holder................................... 519
• Bottle holders/ 
door pockets .............................. 520
• Cup holders................................. 522
• Auxiliary boxes........................... 525
3-7. Other interior features Cool box ......................................... 528
Sun visors.......................................... 531
Vanity mirror .................................. 532
Clock ................................................ 533
Conversation mirror ................... 534
Power outlet (12 V DC) .................................... 535
Power outlet  (120 V AC [type A]) ................ 537
Power outlet  (120 V AC [type B]) ................ 542
Heated steering wheel............... 549
Seat heaters and 
ventilators ...................................... 551
Armrest ............................................ 554
Coat hooks .................................... 555
Floor mats........................................ 556
Luggage compartment 
features.......................................... 557
Garage door opener.................. 567
Compass.......................................... 575
Safety Connect ............................ 580 4-1. Maintenance and care
Cleaning and protecting 
the vehicle exterior.................. 588
Cleaning and protecting 
the vehicle interior .................... 592
4-2. Maintenance Maintenance requirements.............................. 595
General maintenance ................ 597
Emission inspection and 
maintenance (I/M) 
programs ....................................... 601
4-3. Do-it-yourself maintenance Do-it-yourself service 
precautions .................................. 602
Hood ................................................. 607
Engine compartment................. 608
Tires ................................................... 627
Tire inflation pressure................. 634
Wheels ............................................ 638
Air conditioning filter.................. 640
Electronic key battery ................ 642
Checking and replacing 
fuses ................................................ 645
Headlight aim (vehicles with low 
beam halogen bulbs) ............. 658
Light bulbs ....................................... 660
4Maintenance and care

11
GX460_U.S.A. (OM60E69U)
Anti-glare inside rear view mirror Compass P. 96
P. 575
Moon roof switches
Garage door opener switches
“SOS” button

P. 104
P. 567
P. 580
Vanity mirrors Sun visors P. 532
P. 531
Personal/interior lights P. 513
SRS curtain shield airbags P. 121
: If equipped
Auxiliary box
Conversation mirror P. 525
P. 534
A
Personal/interior lights P. 512
Vanity lights P. 532

Interior features3
383
GX460_U.S.A. (OM60E69U)
3-4. Using the hands-free system 
(for cellular phone)
Hands-free system for 
cellular phones..................... 477
Using the hands-free system 
(for cellular phones) ............ 481
Making a phone call .............. 489
Setting a cellular phone ....... 494
Security and system 
setup ........................................ 499
Using the phone book.......... 503
3-5. Using the interior lights Interior lights list ....................... 511
• Personal/interior light main switch ................................ 512
• Personal/interior lights ......... 513
3-6. Using the storage features List of storage features .......... 515
• Glove box .................................. 516
• Console box .............................. 517
• Coin holder................................ 519
• Bottle holders/ 
door pockets ........................... 520
• Cup holders.............................. 522
• Auxiliary boxes........................ 525 3-7. Other interior features
Cool box ................................... 528
Sun visors .................................. 531
Vanity mirror ........................... 532
Clock ......................................... 533
Conversation mirror............. 534
Power outlet (12 V DC)........ 535
Power outlet 
(120 V AC [type A]) ........... 537
Power outlet 
(120 V AC [type B]) ........... 542
Heated steering wheel ........ 549
Seat heaters and 
ventilators .............................. 551
Armrest .................................... 554
Coat hooks .............................. 555
Floor mats ................................ 556
Luggage compartment  features .................................. 557
Garage door opener ............. 567
Compass ................................... 575
Safety Connect ...................... 580

567
3-7. Other interior features
3
Interior features
GX460_U.S.A. (OM60E69U)
Garage door opener
The garage door opener (HomeLink® Universal Transceiver) is manufactured
under license from HomeLink®.
Programming HomeLink® (for U.S. owners)
The HomeLink
® compatible transceiver in your vehicle has 3 buttons
which can be programmed to operate 3 different devices. Refer to the
programming method below appropriate for the device.
Indicator light
Buttons
The garage door opener can be programmed to operate garage doors,
gates, entry doors, door locks, home lighting systems, and security systems,
and other devices.

570
3-7. Other interior features
GX460_U.S.A. (OM60E69U)■
Programming a rolling code system (for U.S. owners)
If your device is rolling code eq uipped, follow the steps under the
heading “Programming HomeLink
®” before proceeding with the
steps listed below.
Locate the learn button on the ceiling mounted garage door
opener motor. The exact location and color of the button may
vary by brand of garage door opener.
Refer to the operation manual supplied with the garage door opener
for the location of the learn button.
Press the learn button.
Following this step, you have 30 se conds in which to initiate step 3
below.
Press and release the vehicle’s programmed HomeLink® button
for 2 seconds and release it. Repe at this step once again. The
garage door may open.
If the garage door opens, the programming process is complete. If the
door does not open, press and release the button a third time. This third
press and release will complete the programming process by opening
the garage door.
The ceiling mounted garage door op ener motor should now recognize
the HomeLink
® signal and operate the garage door.
Repeat the steps above to prog ram another rolling code system
for any of the remaining HomeLink® buttons.
STEP1
STEP2
STEP3
STEP4

573
3-7. Other interior features
3
Interior features
GX460_U.S.A. (OM60E69U)
■Before programming
●Install a new battery in the remote control transmitter.
●The battery side of the remote control transmitter must be pointed away from
the HomeLink button.
■Certification for the garage door opener
For vehicles sold in the U.S.A.
FCC ID: CB2070NHL4
NOTE:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC WARNING: 
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
For vehicles sold in Canada
NOTE:
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must a ccept any interference, including interfer-
ence that may cause undesired operation of the device.
■When support is necessary
Visit on the web at www.homelink.com
or call 1-800-355-3515.

574
3-7. Other interior features
GX460_U.S.A. (OM60E69U)
CAUTION
■When programming a garage door or other remote control device
The garage door or other devices may operate, so ensure people and objects are
out of danger to prevent potential harm.
■Conforming to federal safety standards
Do not use the HomeLink
 compatible transceiver with any garage door opener
or device that lacks safety stop and reverse features as required by federal safety
standards. 
This includes any garage door that cannot detect an interfering object. A door or
device without these featur es increases the risk of death or serious injury.

814
Alphabetical index
GX460_U.S.A. (OM60E69U)
Garage door opener .......................... 567
Gas station information......................824
Gauges ...................................................... 195
Glove box ................................................. 516
Glove box light ....................................... 516
Hands-free system for cellular 
phones.................................................... 477
Hazard lights Switch ...................................................... 674
Head restraints Adjustment............................................... 83
Headlights cleaner ................................ 241
Headlights Adaptive front lighting 
system .................................................. 223
Discharge headlights 
precautions ....................................... 672
Replacing light bulbs..........................661
Switch ...................................................... 220
Wattage.................................................... 761
Heaters Seat heaters ........................................... 551
Side mirror ............................................404
Heated steering..................................549
Height control Rear height control air 
suspension.......................................... 310
Hill-start assist control ......................... 331
Hood .......................................................... 607
Hooks Cargo ...................................................... 557
Cargo hooks .......................................559
Coat ........................................................ 555
Horn ............................................................ 194 I/M test ...................................................... 601
Identification
Engine ....................................................... 751
Vehicle...................................................... 751
Ignition switch .......................................... 179
Ignition switch light Ignition switch light ...............................511
Illuminated entry system ......................514
Indicator lights ........................................ 198
Initialization Items to initialize...................................801
Inside door handle light ........................ 511
Inside rear view mirror .......................... 96
Instrument cluster light control.........196
Interior lights Interior lights ............................................ 511
Switch ........................................................ 513
Wattage ................................................... 761
Intuitive parking assist......................... 259
Jack Vehicle-equipped jack....................720
Jack handle ............................................. 720
Keyless entry ................................................. 48
Keys Electronic key ......................................... 26
Engine switch .......................................... 29
If you lose your keys ......................... 737
If the electronic key does not 
operate properly............................ 738
Key number plate.................................. 26
Keyless entry........................................... 48
Keys.............................................................. 26
Mechanical key ...................................... 26
Wireless remote control key.......... 48G
H
I
J
K
