4-3. Do-it-yourself maintenance
GX460_U.S.A. (OM60E69U)
■Engine oil consumption
●The amount of engine oil consumed depends on the oil viscosity, the quality of
the oil and the way the vehicle is driven.
●More oil is consumed under driving co nditions such as high speeds and fre-
quent acceleration and deceleration.
●A new engine consumes more oil.
●When judging the amount of oil consumpt ion, keep in mind that the oil may
have become diluted, making it difficult to judge the true level accurately.
●Oil consumption: Max. 1.1 qt./600 miles, 0.9 lmp.qt./600 miles (1.0 L per 1000
km).
●If your vehicle consumes more than 1.1 qt. (1.0 L, 0.9 lmp.qt.) every 600 miles
(1000 km), contact your Lexus dealer.

753
6-1. Specifications
6
Vehicle specifications
GX460_U.S.A. (OM60E69U)
Lubrication system■ Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil” or equivalent to satisfy the follow-
ing grade and viscosity.
Oil grade: ILSAC multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good
starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced with
SAE 0W-20 at the next oil
change.
Oil capacity 
Drain and refill 
(Reference)
With filter
Without filter

8.2 qt. (7.8 L, 6.9 Imp.qt.)
7.8 qt. (7.4 L, 6.5 Imp.qt.)
Outside temperature

754
6-1. Specifications
GX460_U.S.A. (OM60E69U)
The 0W portion of the oil viscosity rating indicates the characteristic of the oil
which allows cold startability. Oils with a lower value before the W allow for
easier starting of the engine in cold weather.
The 20 in 0W-20 indicates the oil viscosity when the oil is at its operating
temperature. An oil with a higher viscosity may be better suited if the vehicle
is operated at high speeds, or under extreme load conditions.
How to read oil container label:
The ILSAC (International Lubricant St andardization and Approval Com-
mittee) Certification Mark is added to some oil containers to help you
select the oil you should use.

756
6-1. Specifications
GX460_U.S.A. (OM60E69U)
Electrical system
Front differential
*: “Toyota Genuine Differential Gear Oil” is filled in your Lexus vehicle at factory fill. 
Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equivalent of
matching quality to satisfy the above specification. Please contact your Lexus
dealer for further details.
Battery
Open voltage* at 
68 F (20 C):12.6  12.8 V Fully charged 
12.2  12.4 V Half charged
11.8  12.0 V Discharged 
(
*: Voltage is checked 20 minutes after the
engine and all the lights are turned off.)
Charging rates5A max.
Oil capacity1.48 qt. (1.40 L, 1.23 Imp.qt.)
Oil type and viscosity*Toyota Genuine Differential 
Gear Oil LT 75W-85 GL5 or equivalent

757
6-1. Specifications
6
Vehicle specifications
GX460_U.S.A. (OM60E69U)
Rear differential
*: “Toyota Genuine Differential Gear Oil” is filled in your Lexus vehicle at factory
fill. 
Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equivalent of
matching quality to satisfy the above sp ecification. Please contact your Lexus
dealer for further details.
Oil capacity2.85 qt. (2.70 L, 2.38 Imp.qt.)
Oil type and viscosity*Toyota Genuine Differential 
Gear Oil LT 75W-85 GL5 or equivalent

759
6-1. Specifications
6
Vehicle specifications
GX460_U.S.A. (OM60E69U)
Tr a n s f e r
*: “Toyota Genuine Transfer Gear oil LF” is filled in your Lexus vehicle at factory
fill. Use Lexus approved “Toyota Genuine Tr ansfer Gear oil LF” or an equivalent
of matching quality to satisfy the above specification. Please contact your Lexus
dealer for further details.
Brakes
*1: Minimum pedal clearance when depressed with a force of 110 lbf (490 N, 50 kgf) while the engine is running.
*2: Parking brake pedal travel when depressed with a force of 45.0 lbf (200 N, 20.4 kgf).
Oil capacity1.5 qt. (1.4 L, 1.2 Imp.qt.)
Oil type*Toyota Genuine Transfer 
Gear oil LF or equivalent
Recommended oil viscositySAE 75W
Pe d a l c l e a r a n c e*13.4 in. (86 mm) Min.
Pedal free play0.04  0.24 in. (1.0  6.0 mm)
Brake pad wear limit0.04 in. (1.0 mm)
Parking brake lining wear limit0.04 in. (1.0 mm)
Parking brake pedal travel*25  7 clicks
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3

824
GX460_U.S.A. (OM60E69U)
GAS STATION INFORMATION
Auxiliary catch leverP. 6 0 7Fuel filler doorP. 1 0 9
Hood lock release lever P. 6 0 7Fuel filler door leverP. 1 0 9Tire inflation pressure P. 76 0
Fuel tank capacity23.0 gal. (87 L, 19.1 lmp.gal.)
Fuel typePremium unleaded gasoline only P. 111, 752
Cold tire inflation 
pressureP. 76 0
Engine oil capacity
(Drain and refill)qt. (L, Imp.qt.)
With filter 8.2 (7.8, 6.9)
Without filter 7.8 (7.4, 6.5)
Engine oil type“Toyota Genuine Motor Oil” or equivalent
Oil grade: ILSAC multigrade engine oil P. 753
Recommended oil viscosity: SAE 0W-20
