display Lexus GX460 2011 Do-It-Yourself Maintenance / LEXUS 2011 GX460 OWNERS MANUAL QUICK GUIDE (OM60G26U)

2
GX460_QG_U (OM60G26U)
Hands-free System For Cellular Phone (Without Navigation System)
Bluetooth® phone pairing .........................................................................................................60
Calling by number .......................................................................................................................... 61
Calling by name............................................................................................................................... 61
Calling by speed dial .................................................................................................................... 62
Phonebook transfer ......................................................................................................................63
Changing the registered name ................................................................................................ 64
Registering a speed dial ..............................................................................................................65
Headlights ................................................................................................................................................ 31
Intuitive Parking Assist ....................................................................................................................... 24
Keys............................................................................................................................................................. 10
LDA (Lane Departure Alert) ..........................................................................................................23
Lexus Enform with Safety Connect .............................................................................................. 79
List of Warning/Indicator Lights ................................................................................................... 85
Moon Roof ............................................................................................................................................. 83
Multi-information Display (Accessory Meters) ....................................................................... 17
Multi-information Display (Optitron Meters) ........................................................................... 16
Multi-terrain Monitor ......................................................................................................................... 27
Multi-terrain Select .............................................................................................................................25
Navigation System
Register home .................................................................................................................................36
Destination input
 Search by address ................................................................................ 37
Destination input
 Search points of interest by name..................................................39
Destination input
 Search points of interest by category...........................................40
Destination input
 Search points of interest by telephone number ........................ 41
Portable Audio Device Port..............................................................................................................76
Power Windows ....................................................................................................................................82
Rear Air Conditioning System (With Navigation System)
Front controller (touch screen) ................................................................................................59
Rear Air Conditioning System (Without Navigation System)
Using the automatic mode.......................................................................................................... 71
Rear Seat Entertainment System................................................................................................... 52
Rear Window Wiper and Washer .................................................................................................35
Safety Connect ..................................................................................................................................... 77
Smart Access System with Push-button Start.............................................................................11
Theft Deterrent System ...................................................................................................................... 12
Turn Signal Lever ................................................................................................................................... 18
Voice Command System
Basic operation ............................................................................................................................... 72
Command list .................................................................................................................................. 73
Wide View Front & Side Monitor ................................................................................................. 24
Windshield Wipers and Washers ..................................................................................................34
Depending on specifications, the vehicle shown in the illustration may
differ from your vehicle in terms of color and equipment.

13
GX460_QG_U (OM60G26U)
■Alarm
The system sounds the alarm and flashes the lights when forced entry is detected.
To set the alarm: Close the doors, glass hatch and hood, and lock all the doors. The system
will be set automatically after 30 seconds.
The indicator light changes from being on to flashing when the system is set.
To deactivate or stop the alarm: Start the engine (The alarm will be deactivated or stopped
after a few seconds), or unlock the doors.
■Steering lock
After turning the “ENGINE START STOP”
switch off and opening and closing the
doors, the steering wheel will be locked due
to the steering lock function. Operating the
“ENGINE START STOP” switch again
automatically cancels the steering lock.
When the steering lock cannot be released,
the green indicator light on the “ENGINE
START STOP” switch will flash and a mes-
sage will be shown on the multi-information
display. Press the “ENGINE START STOP”
switch again while turning the steering
wheel left and right.

16
GX460_QG_U (OM60G26U)
Multi-information Display (Optitron Meters)
●Trip information contents
Displays driving range, fuel consumption and other cruising-related information.
●Electronic features control contents
●Multi-terrain Select display (if equipped)
●Intuitive parking assist display* (if equipped)
●Crawl Control display* (if equipped)
●Dynamic radar cruise control display* (if equipped)
●LDA (Lane Departure Alert) display* (if equipped)
●Wa r n i n g m e s s a g e s
Automatically displayed when a malfunction occurs in one of the vehicles systems.
(Refer to the “Owner’s Manual”.)
●Customization
Settings (e.g.available language) can be changed.
(Customizable features Refer to the “Owner’s Manual”.)
*: Automatically displayed when the system is used
■Switching the display
Menu switch
Changes modes to electronic features
control mode, customization mode or
back to normal display mode.
“ENTER” switch
Changes trip information items. This
switch is also used to turn on/off elec-
tronic features controls and to change
customization settings.
The multi-information display presents the driver with a variety of driving-related data.

17
GX460_QG_U (OM60G26U)
Multi-information Display
(Accessory Meters) (If Equipped)
●Clock
Indicates the time.
●Outside temperature
Indicates the outside temperature.
The temperature range that can be displayed is from -40 F (-40 C) to 122 F (50 C).
●Air conditioning system display
●Rear view monitor
Automatically displayed when the shift lever is moved into R.
(Refer to the “Owner’s Manual” or “Navigation System Owner’s Manual”.)
●Multi-terrain Monitor (if equipped)
●Wide view front & side monitor (if equipped)
●Trip information
Displays driving range, fuel consumption and other cruising-related information.
●Intuitive parking assist display (if equipped)
■Switching the display
Items displayed can be switched by press-
ing the “MODE” switch.
“MODE” switch
“RESET” switch
“DISP” switch
Display adjustment switch
The multi-information display presents the driver with a variety of driving-related data
including the current outside air temperature.

20
GX460_QG_U (OM60G26U)
■Adjusting the set speed
Increases the speed
Decreases the speed
Hold the lever until the desired speed
setting is obtained.
Fine adjustment of the set speed can be
made by lightly pushing the lever up or
down and releasing it.
■Canceling and resuming the constant speed control
Pulling the lever toward you cancels the
constant speed control.
The speed setting is also canceled when
the brakes are applied.
Pushing the lever up resumes the con-
stant speed control.
Dynamic Radar Cruise Control
(If Equipped)
Display
Indicators
Vehicle-to-vehicle distance button
Cruise control switch
Dynamic radar cruise control supplements conventional cruise control with a vehicle-to-
vehicle distance control. In vehicle-to-vehicle distance control mode, the vehicle automati-
cally accelerates or decelerates in order to maintain a set following distance from vehicles
ahead.

22
GX460_QG_U (OM60G26U)
■Adjusting the set speed
Increases the speed
Decreases the speed
Hold the lever until the desired speed
setting is displayed.
Fine adjustment of the set speed can be
made by lightly pushing the lever up or
down and releasing it.
■Canceling and resuming the constant speed control
Pulling the lever toward you cancels the
constant speed control.
The speed setting is also canceled when
the brakes are applied.
Pushing the lever up resumes the con-
stant speed control.
■Changing the vehicle-to-vehicle distance
Pressing the button changes the vehicle-to-
vehicle distance as follows:
Long
Medium
Short
The vehicle-to-vehicle distance is set
automatically to long mode when the
“ENGINE START STOP” switch is
turned to IGNITION ON mode.
If a vehicle is running ahead of you, the
preceding vehicle mark will be also dis-
played.Preceding vehicle mark
The vehicle-to-vehicle distance control mode maintains the preset cruising speed as long
as no vehicle is detected ahead.

23
GX460_QG_U (OM60G26U)
LDA (Lane Departure Alert)(If Equipped)
■Turning the LDA system on
The system will be activated depending on the recognizability of lane markings and on the
vehicle speed.
Press the “LDA” switch to activate the sys-
tem.
The “LDA” indicator will come on.
Press the switch again to turn the LDA
system off.
■Indication on the multi-information display
While the LDA system is on, a lane line display is shown on the multi-information display to
inform the driver that the LDA system is on.
●When thin lines are shown:
Lane markings are not recognized by
the system, or the LDA system is tempo-
rarily canceled.
●When solid lane lines are shown:
The LDA system is active.
While driving on a freeway or motor highway that has lane markings, this system recog-
nizes the lanes using a camera as a sensor to alert the driver when the vehicle deviates from
its lane.
If the system judges that the vehicle may deviate from its lane, it alerts the driver using rapid
beeping and indications on the multi-information display.
Lane line display

24
GX460_QG_U (OM60G26U)
Intuitive Parking Assist (If Equipped)
Press the menu switch.
The multi-information display will
change modes to electronic features
control mode.
Press the “ENTER” switch upwards or
downwards until the Intuitive parking
assist mark appears in the multi-informa-
tion display.
Press the “ENTER” switch to change to
“ON”.
The Intuitive parking assist indicator will
be displayed.
Each pressing of the switch turns the
Intuitive parking assist on and off.
When on, the buzzer sounds to inform
the driver that the system is operational.
Press the menu switch to change to the nor-
mal display.
Wide View Front & Side Monitor(If Equipped)
On/off
The camera image is displayed when the
wide view front & side monitor switch is
pressed.
The distance from your vehicle to nearby obstacles when parallel parking or maneuver-
ing into a garage is measured by the sensors and communicated via the multi-informa-
tion display and a buzzer. Always check the surrounding area when using this system.
This system can display the wide view front monitor and the side monitor.
The wide view front monitor uses a super-wide angle lens to display on screen the areas to
the left and right of the vehicle and the blind spots to the front of the vehicle. This system
helps the driver check for approaching cars, bicycles and pedestrians when at intersections
with poor visibility.
The side monitor uses a camera installed in the passenger’s side outside rear view mirror to
display on screen the area to the right of the vehicle, helping the driver check this area.

25
GX460_QG_U (OM60G26U)
Multi-terrain Select (If Equipped)
Menu switch
“ENTER” switch
Multi-information display
Displays status information including
operating status and road type selection.
Multi-terrain Select indicator
■Selectable modes
Multi-terrain Select is a system that improves drivability in off-road situations.
ModeRoad Conditions
MUD & SANDSuitable for muddy roads, sandy roads, snow-covered roads, dirt
trails and other slippery or dirty conditions
LO OSE
ROCKSuitable for slippery conditions consisting of mixtures of earth and
loose rock
MOGULSuitable for a wide range of off-road conditions, particularly very
bumpy conditions
ROCKSuitable for rocky terrain

26
GX460_QG_U (OM60G26U)
■Switching modes
Push the menu switch.
The multi-information display will
change to electronic features control
mode.
Press the “ENTER” switch upwards or
downwards until “MULTI-TERRAIN
SELECT” appears and then press the
“ENTER” switch.
The mode selection screen is displayed.
Press the “ENTER” switch upwards or
downwards to select a desired mode
and then press the “ENTER” switch.
The system switches to the selected
mode, and the multi-terrain select indi-
cator will turn on.
Once the mode has been set, the mode
name will be displayed and operation
will commence.
