Lexus GX460 2011 Intuitive Parking Assist / LEXUS 2011 GX460 QUICK GUIDE (OM60G26U) Service Manual

41
GX460_QG_U (OM60G26U)
■Destination input Search points of interest by telephone number
Push the “DEST” button.
Touch “Point of Interest”.
To u c h “ P h o n e # ” .
Input a telephone number and select
“OK”.
To u c h “ G o t o ” .
To u c h “ O K ” .STEP2
STEP3
STEP4
STEP5

42
GX460_QG_U (OM60G26U)
Hands-free System For Cellular Phone
(With Navigation System)
■Bluetooth® phone pairing
Compatible Bluetooth®-equipped phones can be connected to the vehicle, enabling
hands-free operation. Please refer to the cellular phone manufacturer’s user guide for pair-
ing procedures, or go to “www.lexus.com/bluetooth” for more phone information.
To use a Bluetooth
® phone, it is necessary
to first register it in the system.
Push the “SETUP” button.
Touch “Phone”.
Touch “Manage Phone”.
Touch “(add new)” to display the screen
for connecting Bluetooth
®.
Enter the passcode displayed on the
screen into the phone.
Refer to the cellular phone user’s manual
for cellular phone operation.
When the connection is completed,
“Bluetooth connection successful.” will
appear.
STEP2
STEP3
STEP4
STEP5

43
GX460_QG_U (OM60G26U)
■Phonebook transfer
Push the “SETUP” button.
To u c h “ P h o n e ” .
Touch “Phonebook”.
Touch “Manage Contacts”.
Touch “Transfer Contacts”.
Transfer the phonebook data to the sys-
tem using the cellular phone.
Refer to the cellular phone user’s manual
for cellular phone operation.STEP2
STEP3
STEP4
STEP6
Phonebook transfer may not be possible depending on phone model.

44
GX460_QG_U (OM60G26U)
■Registering a voice tag
Push the “SETUP” button.
Touch “Phone”.
Touch “Phonebook”.
Touch “Manage Voice Tags”.
Touch “New Voice Tag”.
Touch the data you want to register.
Touch “REC”, and record a voice tag.
To u c h “ O K ” .STEP2
STEP3
STEP4
STEP7

45
GX460_QG_U (OM60G26U)
■Registering a speed dial
Push the “SETUP” button.
To u c h “ P h o n e ” .
Touch “Phonebook”.
Touch “Manage Speed Dials”.
To u c h “ N e w S p e e d D i a l ” .
Touch the data you want to register.
Touch the desired phone number.
Touch the button you want to register in.
The registration completion message is
displayed on the screen.STEP2
STEP3
STEP4
STEP6

46
GX460_QG_U (OM60G26U)
■Calling by name
You can call by saying a voice tag registered in the phonebook. For setting the voice recog-
nition, refer to the “Navigation System Owner’s Manual”. Only when English is selected as
the system language can you call by saying a name registered in the phonebook without
registering any voice tags beforehand. (Names in the phonebook work as voice tags.)
Press .
Follow the voice guidance and say
“Phone”.
Follow the voice guidance and say “Dial
by name”.
Follow the voice guidance and say a
contact name.
Follow the voice guidance and say the
type of phone number (home, mobile,
work, other).
Follow the voice guidance and say “Dial”.
STEP1
STEP2
STEP4
: Pressing this switch turns the voice command system on. Say a command after
the beep.

47
GX460_QG_U (OM60G26U)
■Calling by speed dial
Press .
To u c h “ S p e e d D i a l s ” .
Touch the desired number to call.

48
GX460_QG_U (OM60G26U)
■Receiving a call
When a call is received, this screen is
displayed with a sound.
Push on the steering wheel to talk
on the phone.
To ignore the call, push on the steering
wheel.
Audio System (With Navigation System)
■Basic operation
Display the audio control screen
Sound quality modes
Audio sources
AM
FM:AM radio/FM radio
SAT:Satellite radio
DISC:DVD changer
(if equipped)
CD:CD changer
(if equipped)
AUX
USB:Auxiliary audio device/
USB memory/iPod/
Bluetooth
® audio
Pow e r/ Vo l u m e

49
GX460_QG_U (OM60G26U)
■Radio
Display the audio control screen
Station presets
Scanning radio stations
Radio tune
Station select
Seek
■Entering station presets
Select the desired station by using the tune, seek or scan function.
Touch one of the touch-screen buttons (1-6) you want and hold it until a beep is heard.

50
GX460_QG_U (OM60G26U)
■DVD player/CD player
■
Playing an audio CD
Display the audio control screen
Disc select
Repeat play
Random playback
Search playback
Disc load
Track select/rewind/fast-forward
Eject
■Playing a CD with MP3/WMA files
Display the audio control screen
Disc select
Repeat play
Random playback
Search playback
Folder select
File select
Disc load
Eject
