hood release Lexus GX460 2012 Owner's Manual

14
GX460_U.S.A. (OM60J00U)
Pictorial indexInstrument panel
Gauge and meters P. 195Engine (ignition) switch P. 179
Windshield wipers and washer switch
Rear window wiper and washer switch P. 236
P. 242
Headlight switch
Turn signal lever
Fog light switch
Automatic High Beam
∗
P. 219
P. 192
P. 233
P. 226
Center differential lock/unlock switch P. 323
Audio system* P. 413
Glove box P. 525
“RSCA OFF” switch P. 137
Emergency flasher switch P. 676
Parking brake pedal P. 193
Hood lock
release lever
P. 608
Tilt and telescopic steering control switch P. 93
Pre-collision braking off switch∗ P. 344

608
4-3. Do-it-yourself maintenance
GX460_U.S.A. (OM60J00U)
Hood
CAUTION
■Pre-driving check
Check that the hood is fully closed and locked.
If the hood is not locked properly, it may open while the vehicle is in motion and
cause an accident, which may result in death or serious injury.
Release the lock from the inside of the vehicle to open the hood.
Pull the hood lock release lever.
The hood will pop up slightly.
Move the auxiliary catch lever
to side direction and lift the
hood.
STEP1
STEP2

746
5-2. Steps to take in an emergency
GX460_U.S.A. (OM60J00U)
■Overheating
In the following situations, your vehicle may be overheating:
●The engine coolant temperature gauge enters the red zone or a loss of power is
experienced.
●Steam is coming from under the hood.
CAUTION
■To prevent an accident or injury when inspecting under the hood of your vehicle
●If steam is seen coming from under the hood, do not open the hood until the
steam has subsided. The engine compartment may be very hot, causing serious
injury such as burns.
●Keep hands and clothing away from the fan and engine drive belt while the
engine is running.
●Do not loosen the radiator cap while the engine and radiator are hot.
Serious injury, such as burns, may result from hot coolant and steam released
under pressure.
NOTICE
■When adding engine coolant
Wait until the engine has cooled down before adding coolant.
When adding coolant, do so slowly. Adding cold coolant to a hot engine too quickly
can cause damage to the engine.

836
GX460_U.S.A. (OM60J00U)
GAS STATION INFORMATION
Auxiliary catch leverP. 6 0 8Fuel filler doorP. 1 0 9
Hood lock release lever P. 6 0 8Fuel filler door leverP. 1 0 9Tire inflation pressure P. 76 2
Fuel tank capacity
(Reference)23.0 gal. (87 L, 19.1 Imp.gal.)
Fuel typePremium unleaded gasoline only P. 111, 754
Cold tire inflation
pressureP. 76 2
Engine oil capacity
(Drain and refill —
reference)qt. (L, Imp.qt.)
With filter 8.2 (7.8, 6.9)
Without filter 7.8 (7.4, 6.5)
Engine oil type
“Toyota Genuine Motor Oil” or equivalent
Oil grade: ILSAC multigrade engine oil P. 755
Recommended oil viscosity: SAE 0W-20
