lights Lexus GX460 2013 Owner's Manual

1
2
3
4
5
6
7
3
GX460_OM_OM60J63U_(U)
2-1. Driving proceduresDriving the vehicle ......................... 172
Engine (ignition) switch .............. 183
Automatic transmission.............. 190
Turn signal lever ............................ 196
Parking brake ................................. 197
Horn.................................................... 198
2-2. Instrument cluster Gauges and meters ..................... 199
Indicators and warning lights................................................ 202
Multi-information display (Optitron meters) .................... 208
Multi-information display (Accessory meters)................... 216
2-3. Operating the lights and windshield wipers
Headlight switch ........................... 223
Automatic High Beam .............. 230
Fog light switch ............................. 237
Windshield wipers and washer............................................ 240
Rear window wiper and washer............................................ 246
Headlight cleaner switch .......... 249 2-4. Using other driving systems
Cruise control .............................. 250
Dynamic radar cruise control............................................ 254
Intuitive parking assist ................ 270
LDA (Lane Departure Alert) .............................................. 279
Rear view monitor system ....... 285
Wide view front & side monitor .......................................... 290
Multi-terrain Select .................... 300
Multi-terrain Monitor ................ 308
Rear height control air suspension ................................... 320
AVS (Adaptive Variable Suspension System) ................. 325
Four-wheel drive system........... 326
Crawl Control ............................... 332
DAC (Downhill Assist Control system) ......................... 336
Driving assist systems................. 339
PCS (Pre-Collision System).......................................... 347
2-5. Driving information Off-road precautions ................ 358
Cargo and luggage ..................... 363
Vehicle load limits........................ 369
Winter driving tips ........................ 371
Trailer towing ................................. 375
Dinghy towing ............................... 394
2When driving
GX460_OM_OM60J63U_(U).book Page 3 Thursday, March 29, 2012 9:10 AM

TABLE OF CONTENTSIndex
4
GX460_OM_OM60J63U_(U)
3-1. Using the air conditioning system and defogger
Front automatic air conditioning system ................ 398
Rear automatic air conditioning system .................. 413
Rear window defogger switch............................................... 417
Windshield wiper de-icer .......... 418
3-2. Using the audio system Audio system .................................. 419
Using the radio ............................... 421
Using the CD player ................... 429
Playing MP3 and WMA discs.................................. 437
Operating an iPod ....................... 446
Operating a USB memory....... 454
Optimal use of the audio system ............................................ 463
Using the AUX port.................... 465
Using the steering wheel audio switches ............................ 466 3-3. Using the Bluetooth
® audio
system
Bluetooth
® audio system ......... 470
Using the Bluetooth
® audio
system ............................................ 474
Operating a Bluetooth
®
enabled portable player ........ 480
Setting up a Bluetooth
®
enabled portable player ........ 483
Bluetooth
® audio system
setup .............................................. 490
3-4. Using the hands-free system (for cellular phone)
Hands-free system for cellular phones ............................ 491
Using the hands-free system (for cellular phones) ................. 495
Making a phone call................... 503
Setting a cellular phone ............ 508
Security and system setup ......... 513
Using the phone book................. 517
3-5. Using the interior lights Interior lights list............................ 525
• Personal/interior light main switch .................................. 526
• Personal/interior lights ........... 527
3Interior features
GX460_OM_OM60J63U_(U).book Page 4 Thursday, March 29, 2012 9:10 AM

8
GX460_OM_OM60J63U_(U)
Pictorial indexExterior
Fog lights P. 237
Parking/front side marker lights P. 223
Headlights (low beam) P. 223
Hood P. 617
Windshield wipers P. 240
Moon roof P. 108
Outside rear view mirrors P. 101
Front turn signal lights P. 196
Side turn signal lights
P. 196
Headlights (high beam)
and daytime running lights
P. 223, 228
GX460_OM_OM60J63U_(U).book Page 8 Thursday, March 29, 2012 9:10 AM

9
GX460_OM_OM60J63U_(U)
Rear window wiper
P. 246
Rear turn signal lights P. 196
Stop/tail lights P. 223
License plate lights P. 223
Back door P. 57
Roof luggage carrier∗ P. 363
Side doors P. 52
Rear window defogger Glass hatch P. 417
P. 62
Tire
●Rotation
● Replacement
● Inflation pressure
● Information
P. 636
P. 726
P. 768
P. 774
Fuel filler door P. 113
Rear side marker lights P. 223
∗: If equipped
GX460_OM_OM60J63U_(U).book Page 9 Thursday, March 29, 2012 9:10 AM

11
GX460_OM_OM60J63U_(U)
Anti-glare inside rear view mirror Compass
∗
Garage door opener switches
P. 99
P. 582
P. 574
Personal/interior lights “SOS” button
∗
P. 526
P. 587
Vanity mirrors Sun visors P. 545
P. 544
Personal/interior lights P. 527
SRS curtain shield airbags P. 126
∗: If equipped
Auxiliary box
Conversation mirror P. 539
P. 547
A
Moon roof switches P. 108
Vanity lights P. 545Assist grips P. 562
Assist grips P. 562
GX460_OM_OM60J63U_(U).book Page 11 Thursday, March 29, 2012 9:10 AM

50
1-2. Opening, closing and locking the doors
GX460_OM_OM60J63U_(U)
■Operation signals
Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: Once; Unlocked: Twice)
Windows and moon roof: A buzzer sounds to indicate that the windows and moon
roof are operating.
Glass hatch: A buzzer sounds once to indicate that the glass hatch have been
opened.
■Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a buzzer
sounds continuously. Fully close the door to stop the buzzer, and lock the vehicle
once more.
■Pa n ic m o d e
■Security feature
→P. 3 9
■Alarm
Using the wireless remote control to lock the doors will set the alarm system.
(→ P. 1 2 1 ) When is pressed for longer than about
one second, an alarm will sound intermit-
tently and the vehicle lights will flash to deter
any person from trying to break into or dam-
age your vehicle.
To stop the alarm, press any button on the
electronic key.
GX460_OM_OM60J63U_(U).book Page 50 Thursday, March 29, 2012 9:10 AM

99
1
1-3. Adjustable components (seats, mirrors, steering wheel, etc.)
Before driving
GX460_OM_OM60J63U_(U)
Inside rear view mirror
In automatic mode, sensors are used to detect the headlights of vehicles
behind and the reflected light is automatically reduced.
Without compass
Turns automatic mode on
Turns automatic mode off
The indicator comes on when
automatic mode is turned on.
The mirror reverts to automatic
mode each time the “ENGINE
START STOP” switch is turned
to IGNITION ON mode.
With compassTurns automatic mode on/off
The indicator comes on when
automatic mode is turned on.
The mirror reverts to automatic
mode each time the “ENGINE
START STOP” switch is turned
to IGNITION ON mode.
GX460_OM_OM60J63U_(U).book Page 99 Thursday, March 29, 2012 9:10 AM

121
1
1-6. Theft deterrent system
Before driving
GX460_OM_OM60J63U_(U)
Alarm
The system sounds the alarm and flashes the lights when forced entry is
detected.
■Triggering of the alarm
The alarm is triggered in the following situations when the alarm is
set:
● A locked door or glass hatch is unlocked or opened in any way
other than using the entry function, wireless remote control or
mechanical key. (The doors will lock again automatically.)
● The hood is opened.
■ Setting the alarm system
Vehicles without a navigation system Close the doors, glass hatch
and hood, and lock all the doors.
The system will be set automati-
cally after 30 seconds.
The indicator light changes from
being on to flashing when the
system is set.
GX460_OM_OM60J63U_(U).book Page 121 Thursday, March 29, 2012 9:10 AM

123
1-6. Theft deterrent system
1
Before driving
GX460_OM_OM60J63U_(U)
■Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
■Alarm-operated door lock
●When the alarm is operating, the doors are locked automatically to prevent
intruders.
●Do not leave the key inside the vehicle when the alarm is operating, and make
sure the key is not inside the vehicle when recharging or replacing the battery.
■Alarm memory function
After the alarm is activated, when you unlock any door using a entry function, wire-
less remote control or mechanical key, the tail lights turn on for about 2 seconds to
inform you that the system was activated.
NOTICE
■To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper operation
of the system cannot be guaranteed.
●A person inside the vehicle opens a door
or hood.
●The battery is recharged or replaced
when the vehicle is locked.
GX460_OM_OM60J63U_(U).book Page 123 Thursday, March 29, 2012 9:10 AM

128
1-7. Safety information
GX460_OM_OM60J63U_(U)
SRS airbag system componentsFront passenger occupant
classification system (ECU and
sensors)
Knee airbag
Curtain shield airbag
Front passenger airbag
“A I R B A G O N ” a n d “A I R B A G
OFF” indicator lights
Side and curtain shield airbag
sensor
Front side airbag
SRS warning light and “RSCA
OFF” indicator light Rear side (if equipped) and
curtain shield airbag sensor
Rear side airbag (outer second
seat) (if equipped)
Driver airbag
Driver’s seat belt buckle switch
Floor sensor
“RSCA OFF” switch
Airbag sensor assembly
Front airbag sensor
Front passenger’s seat belt
buckle switch
Seat belt pretensioners
GX460_OM_OM60J63U_(U).book Page 128 Thursday, March 29, 2012 9:10 AM
