270
2-4. Using other driving systems
GX460_OM_OM60J63U_(U)
Intuitive parking assist∗
∗: If equipped
The distance from your vehicle to nearby obstacles when parallel parking
or maneuvering into a garage is measured by the sensors and communi-
cated via the multi-information display and a buzzer. Always check the sur-
rounding area when using this system.
Vehicles with a navigation system
Refer to the “Navigation System Owner’s Manual”.
Vehicles without a navigation system
■ Types of sensors
Front corner sensors
Front center sensors
Rear corner sensors
Rear center sensors
GX460_OM_OM60J63U_(U).book Page 270 Thursday, March 29, 2012 9:10 AM

277
2-4. Using other driving systems
2
When driving
GX460_OM_OM60J63U_(U)
■Sensor detection information
●Certain vehicle conditions and the surrounding environment may affect the
ability of a sensor to correctly detect an obstacle. Particular instances where this
may occur are listed below.
• There is dirt, snow or ice on a sensor.
•A sensor is frozen.
• A sensor is covered in any way.
• The vehicle is leaning considerably to one side.
• On an extremely bumpy road, on an incline, on gravel, or on grass.
• The vicinity of the vehicle is noisy due to vehicle horns, motorcycle engines,air brakes of large vehicles, or other loud noises producing ultrasonic waves.
• There is another vehicle equipped with parking assist sensors in the vicinity.
• A sensor is coated with a sheet of spray or heavy rain.
• The vehicle is equipped with a fender pole or radio antenna.
• Towing eyelets are installed.
• A bumper or sensor receives a strong impact.
• The vehicle is approaching a tall or right-angled curb.
• In harsh sunlight or intense cold weather.
• A non-genuine Lexus suspension (lowered suspension etc.) is installed.
In addition to the examples above, there are instances in which, because of their
shape, signs and other objects may be judged by a sensor to be closer than they
are.
●The shape of the obstacle may prevent a sensor from detecting it. Pay particular
attention to the following obstacles:
• Wires, fences, ropes, etc.
• Cotton, snow and other materials that absorb sound waves
• Sharply-angled objects
•Low obstacles
• Tall obstacles with upper sections projecting outwards in the direction of your vehicle
GX460_OM_OM60J63U_(U).book Page 277 Thursday, March 29, 2012 9:10 AM

832
Alphabetical index
GX460_OM_OM60J63U_(U)
LightsDoor courtesy lights.........................525
Emergency flasher switch .............684
Engine switch light ............................ 525
Fog light switch................................... 237
Hazard light switch ...........................684
Headlights switch .............................. 223
Inside door handle light.................. 525
Interior lights list.................................. 525
Personal/interior lights ................... 527
Replacing light bulbs........................ 670
Running board lights........................ 525
Scuff lights.............................................. 525
Shift lever light ..................................... 525
Turn signal lever ...................................196
Vanity lights ..........................................545
Wattage.................................................. 769
Load capacity .........................................369
Luggage cover....................................... 567
Maintenance Do-it-yourself ma intenance ........... 612
General maintenance .....................607
Maintenance data..............................758
Maintenance requirements ..........604
Reset the maintenance data........ 605
Meter Instrument cluster light
control..................................................200
Meters .......................................................199
Micro dust and pollen filter............... 407
Mirrors Inside rear view mirror....................... 99
Side mirror heater ............................... 417
Side mirrors ............................................. 101
Vanity mirrors......................................545 Moon roof................................................. 108
MP3 disc.................................................. 437
Multi-information display
Brightness control .............................. 219
Multi-information display ........ 208, 216
Multi Terrain ABS ................................ 339
Multi-terrain Monitor .........................308
Multi-terrain Select..............................300
Navigation system
*
Noise from under vehicle .................... 20
Odometer .................................................199
Off-road precautions .........................358
Oil Engine oil............................................... 620
Opener Fuel filler door ......................................... 113
Hood ......................................................... 617
Outside rear view mirrors
Adjusting and folding ..........................101
Driving position memory ..................82
Outside temperature display .......................................... 209, 216
Overhead console ............................... 539
Overheating, Engine .......................... 749
Parking assist sensors......................... 270
Parking brake........................................... 197
Parking lights Replacing light bulbs ....................... 675
Switch .......................................................223
Wattage ................................................. 769
PCS ............................................................ 347
M
N
O
P
GX460_OM_OM60J63U_(U).book Page 832 Thursday, March 29, 2012 9:10 AM
