key Lexus GX460 2013 Specifications /

2
GX460_QG_U (OM60J68U)
Hands-free System For Cellular Phone (Without Navigation System)Bluetooth® phone pairing ......................................................................................................... 64
Calling by number .............................................................................................................. ...........65
Calling by name................................................................................................................ ..............65
Calling by speed dial .......................................................................................................... ..........66
Phonebook transfer ............................................................................................................. ......... 67
Changing the registered name ............................................................................................... 68
Registering a speed dial .............................................................................................................. 69
Headlights ..................................................................................................................... ..........................33
Intuitive Parking Assist ....................................................................................................... ................ 26
Keys............................................................................................................................................................. 10
LDA (Lane Departure Alert) ..................................................................................................... .....25
Lexus Enform with Safety Connect ............................................................................................. 83
List of Warning/Indicator Lights ............................................................................................... .... 89
Moon Roof ...................................................................................................................... ........................ 87
Multi-information Display (Accessory Meters) ....... ................................................................ 17
Multi-information Display (Optitron Meters) ........ ................................................................... 16
Multi-terrain Monitor .......................................................................................................... ............... 29
Multi-terrain Select ........................................................................................................... .................. 27
Navigation System
Register home .................................................................................................................. ...............40
Destination input
 Search by address ................................................................................. 41
Destination input
 Search points of interest by name..................................................43
Destination input
 Search points of interest by category...........................................44
Destination input
 Search points of interest by telephone number ....................... 45
Portable Audio Device Port..................................................................................................... ....... 80
Power Windows .................................................................................................................. ................. 86
Rear Air Conditioning System (With Navigation System) Front controller (touch screen) ......................... .......................................................................63
Rear Air Conditioning System (Without Navigation System) Using the automatic mode....................................................................................................... .. 75
Rear Seat Entertainment System................................................................................................. ..56
Rear Window Wiper and Washer .................................................................................................39
Safety Connect ................................................................................................................. ..................... 81
Smart Access System with Push-button Start........ .....................................................................11
Theft Deterrent System ......................................................................................................... ............. 12
Turn Signal Lever .............................................................................................................. ..................... 18
Voice Command System Basic operation ................................................................................................................................76
Command list ................................................................................................................... ............... 77
Wide View Front & Side Monitor ................................................................................................. 26
Windshield Wipers and Washers .................................................................................................. 37
Depending on specifications, the vehicle shown in the illustration may
differ from your vehicle in terms of color and equipment.

10
GX460_QG_U (OM60J68U)
Keys
■Electronic key
Smart access system with push-button start
( P. 11, 14)
■Mechanical key
Carry the mechanical key together with the
electronic key. If the electronic key battery
is depleted or the entry function does not
operate properly, you will need the
mechanical key.
To take out the mechan ical key, slide the
release lever and take the key out.
■ Wireless remote control
Locks all the doors
Unlocks all the doors
Pressing the button unlocks the driver’s
door. Pressing the bu tton again within 3
seconds unlocks the other doors.
Opens the windows and moon roof
(press and hold)*
Opens the glass hatch (press and hold)
The glass hatch can be opened only
when the back door is closed.
Sounds the alarm (press and hold)
*: This setting must be customized at your Lexus dealer.

11
GX460_QG_U (OM60J68U)
Smart Access System with Push-button Start
■Entering the vehicle
Grip the driver’s door handle to unlock the
door. Grip the passenger’s door handle to
unlock all the doors.
Make sure to touch the sensor on the
back of the handle.
The doors cannot be unlocked for 3 sec-
onds after the doors are locked.
■Exiting the vehicle
Touch the lock sensor (the indentation on
the upper or lower part of the door handle)
to lock the doors.
■Unlocking and locking the back door
Locks the all doors
Unlocks the all doors
The doors cannot be unlocked for 3 sec-
onds after the doors are locked.
The following operations can be performed simp ly by carrying the electronic key on your
person, for example in your pocket.
For details on starting the engine, see page 14.

12
GX460_QG_U (OM60J68U)
■Opening the glass hatch
Press the button to open the glass hatch.
The glass hatch will pop up.
The glass hatch can be opened only
when the back door is closed.
Theft Deterrent System
■Immobilizer system
Without navigation system
The indicator light flashes after the
“ENGINE START STOP” switch has been
turned OFF to indicate that the system is
operating.
The indicator light stops flashing after the
“ENGINE START STOP” switch has been
turned to ACCESSORY or IGNITION
ON mode to indicate that the system has
been canceled.
With navigatio n system
For details on what to do when the electronic key does not operate properly, see page 92.

14
GX460_QG_U (OM60J68U)
Engine (Ignition) Switch
■Starting the engine
Check that the parking brake is set.
Check that the shift lever is set in P.
Firmly depress the brake pedal.
The “ENGINE START STOP” switch
indicator will turn green. If the indica-
tor does not turn green, the engine
cannot be started.
Press the “ENGINE START STOP”
switch. The engine will crank until it starts or
for up to 25 seconds, whichever is
less.
Continue depressing the brake pedal
until the engine is completely started.
The engine can be started from any
“ENGINE START STOP” switch
mode.
■Stopping the engine
Stop the vehicle.
Shift the shift lever to P.
Set the parking brake.
Press the “ENGINE START STOP” switch.
Release the brake pedal and check that the indicator on the “ENGINE START STOP”
switch is off.
Performing the following operations when carrying the electronic key on your person
starts the engine or changes “ENGINE START STOP” switch modes.

64
GX460_QG_U (OM60J68U)
Hands-free System For Cellular Phone
(Without Navigation System)
■Bluetooth® phone pairing
Compatible Bluetooth®-equipped phones can be connected to the vehicle, enabling
hands-free operation. Please refer to the cellu lar phone manufacturer’s user guide for pair-
ing procedures, or go to“www.lexus.com/bluetooth” for more phone information.
To use a Bluetooth
® phone, it is necessary
to first register it in the system.
Press or .
Press and say “Pair phone”.
Press and say a name*.
*: This name will be used to identifyyour phone in the case that more than
one phone has been registered to the
system.
Press and say “Confirm” to display
the passkey.
Enter the passkey shown on the display
into the phone.
Refer to the cellular phone user’s manual
for cellular phone operation.
Once the voice guidance for registration
completion is finished, press .STEP1
: Pressing this switch turns the voice command system on. Say a command after the beep.

85
GX460_QG_U (OM60J68U)
Door Locks
■Door lock switches
Locks all the doors
Unlocks all the doors
■Inside lock button
Locks the door
Unlocks the door
The front doors can be opened by pull-
ing the inside handles even if the lock
buttons are in the lock position.
The vehicle can be locked and unlocked using the entry function, wireless remote con-
trol, key or door lock switch.
For details the entry function or wireless remote control ( P.10, 11)

92
What to do if ...
GX460_QG_U (OM60J68U)
If the electronic key does not operate properly
■Unlocking and locking the doors
Use the mechanical key ( P.10) in order to
perform the following operations (driver’s
door only):
Locks all the doors
Closes the windows and moon roof (turn
and hold)*
Unlocks the door
Turning the key rearward unlocks the
driver’s door. Turning the key once again
unlocks the other doors.
Opens the windows and moon roof (turn
and hold)*
*: This setting must be customized at your Lexus dealer.
■Starting the engine
Ensure that the shift lever is in P and
depress the brake pedal.
Touch the Lexus emblem side of the
electronic key to the “ENGINE START
STOP” switch.
If any of the doors is opened or
closed while the key is being touched
to the switch, an alarm will sound to
indicate that the start function cannot
detect the electronic key.
Press the “ENGINE START STOP”
switch within 10 se conds of the buzzer
sounding, keeping the brake pedal
depressed.
In the event that the “ENGINE START STOP” switch still cannot be operated, contact your
Lexus dealer.
If the electronic key battery becomes depleted , replace it with a new battery. For instruc-
tions on replacing the battery, refer to the Ow ner’s Manual. If you need further assistance,
contact your Lexus dealer.
