heater Lexus GX460 2013 Specifications /

557
3-7. Other interior features
3
Interior features
GX460_OM_OM60J63U_(U)
Seat heaters and ventilators
The seat heaters and ventilators heat the seats and maintain good airflow
by blowing air from the seats.
■ Front seat heaters/ventilators
Turns the seat heater on
The indicator light comes on.
The higher the number of dots,
the warmer the seat becomes.
Blows air from the seat
The indicator light comes on.
The higher the number of dots,
the stronger the airflow
becomes.

558
3-7. Other interior features
GX460_OM_OM60J63U_(U)
■The seat heaters/ventilators can be used when
The “ENGINE START STOP” switch is in IGNITION ON mode.
■When not in use
Turn the dial until the indicator light turns off.
■Outer second seat heaters (if equipped)
For left second seat
For right second seat
High heating temperature
Low heating temperature
To turn on the seat heater, press
“HI” or “LO”.
The indicator light on “HI” or
“LO” switch indicates that the
seat heater is on.
Off
To turn off, press “OFF”.

559
3-7. Other interior features
3
Interior features
GX460_OM_OM60J63U_(U)
CAUTION
■Burns
●Use caution when seating the following persons in a seat with the seat heater on
to avoid the possibility of burns:
• Babies, small children, the elderly, the sick and the physically challenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs,
cold remedies, etc.)
●Do not cover the seat with anything when using the seat heater.
Using the seat heater with a blanket or cushion increases the temperature of the
seat and may lead to overheating.
●Do not use the seat heater more than necessary. Doing so may cause minor
burns or overheating.
NOTICE
■To prevent damage to the se at heaters and ventilators
Do not put heavy objects that have an unev en surface on the seat and do not stick
sharp objects (needles, nail s, etc.) into the seat.
■To prevent battery discharge
Turn the seat heaters and ventilators off when the engine is not running.

603
4-1. Maintenance and care
4
Maintenance and care
GX460_OM_OM60J63U_(U)
NOTICE
■Cleaning detergents
●Do not use the following types of detergent, as they may discolor the vehicle inte-
rior or cause streaks or damage to painted surfaces.
• Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, or bleach.
• Seats: Acidic solutions, such as thinner, benzene, or alcohol.
●Do not use polish wax or polish cleaner. The instrument panel’s or other interior
part’s painted surface may be damaged.
■Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of leather
surfaces:
●Remove any dust or dirt from leather surfaces immediately.
●Do not expose the vehicle to direct sunlight for extended pe riods of time. Park
the vehicle in the shade, especially during summer.
●Do not place items made of vinyl, plastic, or containing wax on the upholstery, as
they may stick to the leather surface if th e vehicle interior heats up significantly.
■Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes into
contact with electrical components such as the audio system above or under the
floor of the vehicle. Water may also cause the body to rust.
■Cleaning the inside of the rear window
●Do not use glass cleaner to clean the re ar window, as this may cause damage to
the rear window defogger heater wires or antenna. Use a cloth dampened with
lukewarm water to gently wipe the window clean. Wipe the window in strokes
running parallel to the heater wires or antenna.
●Be careful not to scratch or damage the heater wires or antenna.

659
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
6SUB BATT30 ATo w i n g
7IG220 AInjector, ignition, meter
8HORN10 AHorn
9EFI25 AEFI ECU, A/F heater relay, fuel pump
relay, EFI NO.2
10A/F20 AA/F SSR
11FUEL OPN 10 AFuel lid opener
12S/HTR RR20 ARear seat heater
13FOLD SEAT LH30 AFolding seat (left)
14FOLD SEAT RH30 AFolding seat (right)
15TOW I N G TA I L30 ATo w i n g
16A/C COMP10 AAir conditioning system
17STRG HTR 10 ASteering heater
18CDS FAN20 ACondenser fan
19STOP10 A
Stop lights, high mount stop light, stop
light switch, VSC ECU, towing, Smart
access system with push button start
20AIR SUS NO.27. 5 AAIR SUS ECU
21H-LP RH-HI15 AHeadlight high beam (right)
22H-LP LH-HI15 AHeadlight high beam (left)
FuseAmpereCircuit

660
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
23HTR50 AAir conditioning system
24WIP WSH RR30 ARear window wipers and washer
25H-LP CLN30 AHeadlight cleaner
26ST30 ASTARTER MTR
27H-LP HI25 ADIM relay, headlights, daytime run-
ning light system
28ALT-S7. 5 AALT
29TURN & HAZ15 A
Front turn signal light, rear turn signal
light, side turn signal light, meter turn
signal light
30D/L NO.125 ADoor lock motor, glass hatch opener
31ETCS10 AEFI ECU
32FUEL PMP15 AFPC
33TOW I N G30 ATo w i n g
34ALT140 A
Air conditioning system, AIR SUS,
headlight cleaner, towing, folding seat,
STOP, rear window defogger, MIR
HTR, CDS FAN, RR FOG, DEICER,
MG-CLT, RR SEAT HTR, STRG HTR,
J/B, INV, RR WIP, RR WSH
35P/ I - B80 AInjector, ignition, meter, EFI, A/F
heater, horn
FuseAmpereCircuit

662
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
50ECU-B10 A
BODY ECU, meter, heater, steering
sensor, wireless remote control, seat
position memory, tilt and telescopic
steering, multi display, Smart access
system with push button start, folding
seat, cool box, DSS#2 ECU, steering
switch, D-module switch, overhead
module
51WSH FR NO.27. 5 ADSS#1 ECU
52H-LP RH-LO15 AHeadlight low beam (right), headlight
leveling system
53H-LP LH-LO15 AHeadlight low beam (left), headlight
leveling system
54INJ10 ACoil, injector, ignition, noise filter
55EFI NO.210 A
O2 SSR, AFM, ACIS VSV, AI
COMB, KEY OFF PUMP, EYP VSV,
EGR VALVE, CANISTER VSV, AI
VSV RLY, AI PUMP HTR RLY
56WIP FR NO.27. 5 ADSS#1 ECU
57WSH RR15 ARear window washer
58SPARESpare fuse
59SPARESpare fuse
60SPARESpare fuse
FuseAmpereCircuit

665
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
19ECU-IG NO.210 A
Rear window defogger, outside rear
view mirror memory, seat heater/ven-
tilator switch, inverter relay, air condi-
tioning system, EC mirror, BODY
ECU, exhaust gas sensor, parking
assist sensor, navigation system,
DSS#2 ECU, meter switch, accessory
meter, folding seat ECU, O/H IG,
head light cleaner, rear air condition-
ing system, deicer, D-module, rain
sensor, air suspension, RR VLV ECU,
steering heater, LKA, P/SEAT IND
20S/HTR FR20 ASeat heater and ventilator
21P/ S E AT F R30 AFront power seat (right)
22DOOR P30 A
Front power window (passenger’s
side), outside rear view mirror mem-
ory
23DOOR10 APo w e r w i n d o w
24DOOR D25 AFront power window (driver’s side)
25DOOR RR25 ARear power window (right)
26S/ROOF25 AMoon roof
27WIP30 AWindshield wipers and washer
28WA S H E R20 AWindshield wipers and washer, rear
window wipers and washer
29COOLING10 ACool box
FuseAmpereCircuit

763
6-1. Specifications
6
Vehicle specifications
GX460_OM_OM60J63U_(U)
Cooling system
Ignition system
Capacity
(reference)
With rear
heater16.3 qt. (15.4 L, 13.6 Imp.qt.)
Without rear
heater14.5 qt. (13.7 L, 12.1 Imp.qt.)
Coolant type
Use either of the following:•“ToyotaSuper Long Life Coolant”
• A similar high-quality ethylene glycol-
based non-silicate, non-amine, non-nitrite,
and non-borate coolant with long-life
hybrid organic acid technology
Do not use plain water alone.
Spark plug
MakeDENSO SK20HR11
Gap0.043 in. (1.1 mm)
NOTICE
■Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

780
6-1. Specifications
GX460_OM_OM60J63U_(U)
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation
pressureTire pressure when the vehicle has been parked for
three hours or more, or has not been driven more
than 1 mile or 1.5 km under that condition
Maximum inflation pres-
sureThe maximum cold inflated pressure to which a tire
may be inflated, shown on the sidewall of the tire
Recommended inflation
pressureCold tire inflation pressure recommended by a man-
ufacturer
Accessory weight
The combined weight (in excess of those standard
items which may be replaced) of automatic trans-
mission, power steering, power brakes, power win-
dows, power seats, radio and heater, to the extent
that these items are available as factory-installed
equipment (whether installed or not)
Curb weight
The weight of a motor vehicle with standard equip-
ment, including the maximum capacity of fuel, oil
and coolant, and if so equipped, air conditioning and
additional weight optional engine
Maximum loaded
vehicle weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
