4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
6SUB BATT30 ATo w i n g
7IG220 AInjector, ignition, meter
8HORN10 AHorn
9EFI25 AEFI ECU, A/F heater relay, fuel pump
relay, EFI NO.2
10A/F20 AA/F SSR
11FUEL OPN 10 AFuel lid opener
12S/HTR RR20 ARear seat heater
13FOLD SEAT LH30 AFolding seat (left)
14FOLD SEAT RH30 AFolding seat (right)
15TOW I N G TA I L30 ATo w i n g
16A/C COMP10 AAir conditioning system
17STRG HTR 10 ASteering heater
18CDS FAN20 ACondenser fan
19STOP10 A
Stop lights, high mount stop light, stop
light switch, VSC ECU, towing, Smart
access system with push button start
20AIR SUS NO.27. 5 AAIR SUS ECU
21H-LP RH-HI15 AHeadlight high beam (right)
22H-LP LH-HI15 AHeadlight high beam (left)
FuseAmpereCircuit

660
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
23HTR50 AAir conditioning system
24WIP WSH RR30 ARear window wipers and washer
25H-LP CLN30 AHeadlight cleaner
26ST30 ASTARTER MTR
27H-LP HI25 ADIM relay, headlights, daytime run-
ning light system
28ALT-S7. 5 AALT
29TURN & HAZ15 A
Front turn signal light, rear turn signal
light, side turn signal light, meter turn
signal light
30D/L NO.125 ADoor lock motor, glass hatch opener
31ETCS10 AEFI ECU
32FUEL PMP15 AFPC
33TOW I N G30 ATo w i n g
34ALT140 A
Air conditioning system, AIR SUS,
headlight cleaner, towing, folding seat,
STOP, rear window defogger, MIR
HTR, CDS FAN, RR FOG, DEICER,
MG-CLT, RR SEAT HTR, STRG HTR,
J/B, INV, RR WIP, RR WSH
35P/ I - B80 AInjector, ignition, meter, EFI, A/F
heater, horn
FuseAmpereCircuit

661
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
36RAD NO.115 AAudio system, navigation system, rear
seat entertainment system
37AM27. 5 AStarter system
38RAD NO.210 ANavigation system
39MAYDAY7. 5 AMAYDAY
40AMP30 AAudio system
41ABS NO.150 AABS, VSC
42ABS NO.230 AABS, VSC
43AIR PMP50 AAir pump
44SECURITY10 ASECURITY
45SMART7. 5 ASmart access system with push button
start
46STRG LOCK20 ASteering lock system
47TOW I N G B R K30 ATo w i n g
48WIP RR15 ARear window wiper
49DOME10 A
Interior lights, personal lights, vanity
lights, door courtesy lights, footwell
lights, outer foot lights, overhead
module
FuseAmpereCircuit

663
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)Under the instrument panel
FuseAmpereCircuit
1P/O U T L E T15 APo w e r o u t l e t
2ACC7. 5 A
Outside rear view mirror motor,
BODY ECU, air conditioning system,
audio system, navigation system,
parking assist system, back up relay,
DSS#2 ECU, AT indicator, EFI ECU,
shift lock ECU, DCM, MAYDAY
ECU
3BKUP LP10 A
Back-up lights, audio system, multi
information display, DSS#2 ECU,
parking assist sensor
4TOW I N G B K L P10 ATo w i n g
5AV S20 AAir suspension system
6KDSS10 AKDSS ECU

666
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
30IGN10 A
EFI ECU, C/OPN RLY, VSC ECU, air
bag ECU, smart entry & start system,
steering lock ECU, CAN gateway
ECU
31GAUGE7. 5 AMeter
32PA N E L7. 5 A
Switch illumination, glove box light,
cup holder lights, auxiliary box light,
navigation system, audio system, air
conditioning system, outside rear view
mirror switch, folding seat switch,
multi-information display, P/SEAT
IND, SHIFT, COOL BOX
33TA I L10 A
Front position lights, tail lights, license
plate lights, EFI ECU, rear fog lights,
towing, front fog lights
FuseAmpereCircuit

When trouble arises5
683
GX460_OM_OM60J63U_(U)
5-1. Essential informationEmergency flashers............... 684
If your vehicle needs to be towed ............................ 685
If you think something is wrong ....................................... 691
Fuel pump shut off system.... 692 5-2. Steps to take in an
emergency
If a warning light turns on or a warning buzzer
sounds..................................... 693
If a warning message is displayed................................ 705
If you have a flat tire................ 726
If the engine will not start ..... 740
If the shift lever cannot be shifted from P ........................ 742
If you lose your keys ............... 743
If the electronic key does not operate properly........... 744
If the vehicle battery is discharged ............................. 746
If your vehicle overheats ...... 749
If the vehicle becomes stuck........................................ 752
If your vehicle has to be stopped in an
emergency ............................ 754

5
When trouble arises
685
5-1. Essential information
GX460_OM_OM60J63U_(U)
If your vehicle needs to be towed
Before towingThe following may indicate a problem with your transmission. Contact
your Lexus dealer before towing.
● The engine is running but the vehicle will not move.
● The vehicle makes an abnormal sound.
If towing is necessary, we recommend having your vehicle towed by your
Lexus dealer or a commercial towing se rvice, using a lift-type truck or a flat
bed truck.
Use a safety chain system for all towi ng, and abide by all state/provincial
and local laws.
The wheels and axle on the ground must be in good condition.
If they are damaged, use a to wing dolly or flat bed truck.

686
5-1. Essential information
GX460_OM_OM60J63U_(U)
Emergency towingIf a tow truck is not available in an emergency, your vehicle may be tem-
porarily towed using a cable or chain secured to the emergency towing
hooks. This should only attempted on hard surfaced roads for short dis-
tances at low speeds.
A driver must be in the vehicle to s teer and operate the brakes. The vehi-
cle’s wheels, drive train, axles, steering and brakes must be in good condi-
tion.
Towing hook

5
When trouble arises
687
5-1. Essential information
GX460_OM_OM60J63U_(U)
Towing with a sling-type truckDo not tow with a sling type truck
to prevent body damage.
Towing with a wheel lift-type truckFrom front Use a towing dolly under the rear
wheels.
From rear Use a towing dolly under the front
wheels.

5
When trouble arises
689
5-1. Essential information
GX460_OM_OM60J63U_(U)
■Before emergency towingThe “ENGINE START STOP” switch must be in the ACCESSORY mode
(engine off) or IGNITION ON mode (engine running).
Put the four-wheel drive control switch in H4. (The center differential is
unlocked.)
Put the vehicle height in the N mode and press height control switch to
turn off the rear height control air suspension.
Shift the shift lever in N.
Release the parking brake.
CAUTION
■Caution while towing
●Use extreme caution when towing the vehicle.
Avoid sudden starts or erratic driving maneuvers which place excessive stress on
the emergency towing eyelets and the cables or chains. Always be cautious of the
surroundings and other vehicles while towing.
●Do not turn the “ENGINE START STOP” switch off.
Doing so will lock the steering wheel and prevent operation, possibly causing an
accident and result ing in death or serious injury.
●If the engine is not running, the power assi st for the brakes and steering will not
function, making steering and braking more difficult.
STEP1
STEP2
STEP3
STEP4
STEP5
