GX460_OM_OM60J63U_(U)
Rear window wiper
P. 246
Rear turn signal lights P. 196
Stop/tail lights P. 223
License plate lights P. 223
Back door P. 57
Roof luggage carrier P. 363
Side doors P. 52
Rear window defogger Glass hatch P. 417
P. 62
Tire
●Rotation
● Replacement
● Inflation pressure
● Information
P. 636
P. 726
P. 768
P. 774
Fuel filler door P. 113
Rear side marker lights P. 223
: If equipped

597
4-1. Maintenance and care
4
Maintenance and care
GX460_OM_OM60J63U_(U)
■Automatic car washes
●Fold the mirrors back before washing the vehicle. Start washing from the front
of the vehicle. Make sure to extend the mirrors before driving.
●Brushes used in automatic car washes may scratch the vehicle surface and
harm your vehicle’s paint.
■High pressure car washes
●Do not allow the nozzles of the car wash to come within close proximity of the
windows and the air suspension unit.
●Before using the car wash, check that the fuel filler door on your vehicle is
closed properly.
■Aluminum wheels
●Remove any dirt immediately by using a neutral detergent. Do not use hard
brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners.
Use the same mild detergent and wax as used on the paint.
●Do not use detergent on the wheels when they are hot, for example after driving
for long distance in the hot weather.
●Wash detergent from the wheels immediately after use.
■Bumpers and side moldings
Do not scrub with abrasive cleaners.

645
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
.
■Tire inflation pressure check interval
You should check tire inflation pressure every 2 weeks, or at least once a month.
Do not forget to check the spare.
■Effects of incorrect tire inflation pressure
Driving with incorrect tire inflation pressure may result in the following:
●Reduced fuel efficiency
●Reduced driving comfort and tire life
●Reduced safety
●Damage to the drive train
If a tire needs frequent refilling, have it checked by your Lexus dealer.
■Instructions for checking tire inflation pressure
When checking tire inflation pressure, observe the following:
●Check only when the tires are cold.
If your vehicle has been parked for at least 3 hours and has not been driven for
more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure
reading.
●Always use a tire pressure gauge.
The appearance of the tire can be misleadi ng. In addition, tire inflation pressures
that are even just a few pounds off can degrade ride and handling.
●Do not bleed or reduce tire inflation pressure after driving. It is normal for the
tire inflation pressure to be higher after driving.
●Never exceed the vehicle capacity weight.
Passengers and luggage weight should be placed so that the vehicle is bal-
anced.

5
When trouble arises
703
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
CAUTION
■Maintenance of the tires
Each tire, including the spare (if provided), should be checked monthly when cold
and inflated to the inflation pressure re commended by the vehicle manufacturer on
the vehicle placard or tire inflation pressure label (tire and load information label).
(If your vehicle has tires of a different size than the size indicated on the vehicle
placard or tire inflation pressure label [tire and load information label], you should
determine the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicl e has been equipped with a tire pressure
monitoring system (TPMS-tire pressure warning system) that illuminates a low tire
pressure telltale (tire pressure warning light) when one or more of your tires is sig-
nificantly under-inflated. Accordingly, when the low tire pressure telltale (tire pres-
sure warning light) illuminates, you should stop and check your tires as soon as
possible, and inflate them to the proper pressure. Driving on a significantly under-
inflated tire causes the tire to overheat an d can lead to tire failure. Under-inflation
also reduces fuel efficiency and tire tread life, and may affect the vehicle’s handling
and stopping ability.
Please note that the TPMS (tire pressure warning system) is not a substitute for
proper tire maintenance, and it is the driver’s responsibility to maintain correct tire
pressure, even if under-inflation has not reached the level to trigger illumination of
the TPMS low tire pressure telltale (tire pressure warning light).

780
6-1. Specifications
GX460_OM_OM60J63U_(U)
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation
pressureTire pressure when the vehicle has been parked for
three hours or more, or has not been driven more
than 1 mile or 1.5 km under that condition
Maximum inflation pres-
sureThe maximum cold inflated pressure to which a tire
may be inflated, shown on the sidewall of the tire
Recommended inflation
pressureCold tire inflation pressure recommended by a man-
ufacturer
Accessory weight
The combined weight (in excess of those standard
items which may be replaced) of automatic trans-
mission, power steering, power brakes, power win-
dows, power seats, radio and heater, to the extent
that these items are available as factory-installed
equipment (whether installed or not)
Curb weight
The weight of a motor vehicle with standard equip-
ment, including the maximum capacity of fuel, oil
and coolant, and if so equipped, air conditioning and
additional weight optional engine
Maximum loaded
vehicle weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

836
Alphabetical index
GX460_OM_OM60J63U_(U)
TRAC.........................................................340
Traction control .....................................340
Trailer towing.......................................... 375
Transmission shift switches ................ 193
Trip information display....................... 216
Trip meter ................................................. 199
Turn signal lightsReplacing light bulbs............ 676, 677
Switch ........................................................196
Wattage.................................................. 769
Vanity lights Vanity lights ..........................................545
Wattage.................................................. 769
Vanity mirrors ............................................545
Vehicle identification number ......... 759
Vehicle load limits ................................369
Ventilators ............................................... 557
VSC (Vehicle Stability Control).....339
Warning buzzers Brake system .........................................710
Open door ...............................697, 709
Open glass hatch reminder ...........710
Seat belt reminder............................. 697
Third power seat................................... 76 Warning lights
Anti-lock brake system (ABS) ................................................... 695
Brake system ....................................... 693
Charging system ............................... 694
Kinetic dynamic suspension system.................................................. 696
Low fuel level....................................... 697
Malfunction indicator lamp .......... 694
Master warning light........................ 698
Open door ........................................... 697
PCS .......................................................... 695
Seat belt reminder light .................. 697
Slip indicator light.............................. 695
SRS airbags .......................................... 695
Tire pressure warning light .......... 698
Warning messages Automatic transmission fluid temperature...................................... 706
Automatic transmission system.................................................. 706
Brake system ......................................... 710
Dynamic radar cruise control system........................................ 708, 712
Engine oil maintenance...................... 711
Engine oil pressure........................... 705
Intuitive parking assist ......................707
Low washer level .................................. 711
Open door ........................................... 709
Open glass hatch................................ 710
Open moon roof................................. 710
Pre-collision system................707, 712
V
W

840
What to do if...
GX460_OM_OM60J63U_(U)
■Warning lights
P. 6 9 8
or
P. 6 9 3P. 6 9 6
P. 6 9 5
or
P. 6 9 5P. 6 9 8
P. 6 9 5P. 6 9 6
P. 6 9 7P. 6 9 6
P. 6 9 5P. 6 9 6
P. 6 9 7P. 6 9 6
P. 6 9 4P. 6 9 6
P. 6 9 6
or
P. 6 9 4P. 6 9 6
P. 6 9 7P. 6 9 6
P. 6 9 7
Brake system warning lightTire pressure warning light
Kinetic dynami c suspension
system warning light
ABS warning light“PCS” warning light
Master warning light
Slip indicator light“AFS OFF” indicator light
Low fuel level warning lightAutomatic High Beam
indicator light
SRS warning light“LDA” indicator light
Open door warning lightCruise control indicator
light
Charging system warning
lightRadar cruise control
indicator light
Malfunction indicator lampMulti-terrain Select
indicator light
Low speed four-wheel drive
indicator light
Driver’s seat belt reminder
lightCenter differential lock
indicator light
Front passenger’s seat belt
reminder light

844
GX460_OM_OM60J63U_(U)
GAS STATION INFORMATION
Auxiliary catch leverP. 6 1 7Fuel filler doorP. 1 1 3
Hood lock release lever P. 6 1 7Fuel filler door leverP. 1 1 3Tire inflation pressure P. 76 8
Fuel tank capacity
(Reference)23.0 gal. (87 L, 19.1 Imp.gal.)
Fuel typePremium unleaded gasoline only P. 115, 760
Cold tire inflation
pressureP. 76 8
Engine oil capacity
(Drain and refill —
reference)qt. (L, Imp.qt.)
With filter 8.2 (7.8, 6.9)
Without filter 7.8 (7.4, 6.5)
Engine oil type
“Toyota Genuine Motor Oil” or equivalent
Oil grade: ILSAC multigrade engine oil P. 761
Recommended oil viscosity: SAE 0W-20
