■Radio
Tuning to preset stations/channels
Using HD Radio
TM Te c h n o l o g y ( f o r
U.S.A., if equipped)
Scanning for receivable stations
Press: Selects a preset station
Press and hold: Seeks for a station
Adjusting the frequency
■Entering station presets
Tune in the desired station.
Select “(add new)”.
Select “Yes” on the confirmation screen.
Select “OK” after setting the new preset station.
Radio mode has a mix preset function, which can store up to 36 stations (6 stations per
page x 6 pages) from any of the AM, FM or SAT bands.
1
2
3
4
5
1
2
3
4

72
GX460_QG_OM60K88U_(U)
■CD player
■
Playing an audio CD
Random playback
Repeat playback
Playback/pause
CD eject
Selecting a track
Disc slot
■Playing a CD with MP3/WMA/AAC files
Displaying a folder list
Random playback
Repeat playback
Playback/pause
CD eject
Selecting a file/fast forward/rewind
Selecting a file
Disc slot
1
2
3
4
5
6
1
2
3
4
5
6
7
8

73
GX460_QG_OM60K88U_(U)
■Operating an iPod
■
Playing an iPod audio
Selecting a play mode
Random playback
Repeat playback
Playback/pause
Selecting a track/fast forward/rewind
■Playing an iPod video
Image display (full screen)
Playback/pause
Selecting a file
1
2
3
4
5
1
2
3

74
GX460_QG_OM60K88U_(U)
Rear Seat Entertainment System (if equipped)
Front audio/visual system
Displays
Rear seat entertainment system controller
Headphone volume control dials and headphone jacks
HDMI port
A/V input port
For details, refer to the Navigation System Owner’s Manual.
The rear seat entertainment system is designed for the rear passengers to enjoy audio
and DVD video separately from the front audio/visual system.
1
2
3
4
5
6

75
GX460_QG_OM60K88U_(U)
■Basic operation
Turns display off
Selects the display to be operated
L: left side display
R: right side display
Power on or off
Turning on the audio source selection
screen
Selecting an icon
Inputting the selected icon
■AM/FM/SAT
Select radio mode on the source screen to
display the control screen.
Selecting a preset station/channel
Press: Tuning the station/channel
Press and hold: Seeking a station/
channel
Press: Tuning the station/channel
Press and hold: Seeking a station/
channel
1
2
3
4
5
6
1
2
3

76
GX460_QG_OM60K88U_(U)
■DISC/USB/iPod/BT-A
Select desired mode on the source screen
to display the control screen.
Selecting a folder/an album
Play/pause
Fa st for wa rd or rewin d
Press: Selecting a track/file
Press and hold: Fast forward or rewind
1
2
3
4

77
GX460_QG_OM60K88U_(U)
■DVD video
Press “DISC” or select disc mode to display DVD video.
Selecting an icon
Turning on the DVD mode
Inputting the selected icon
Playing/pausing a disc
Fast forwarding a disc during playback
and forward slowly during pause.
Stopping a screen
Tu r n i n g o n t h e m e n u
Turning on the option screen
Turning on the title selection screen
Press to select a chapter
Press and hold to fast forward or
rewind a chapter
Rewinding a disc
■Headphone jacks
To listen to the rear audio, use headphones.
To use the headphones, connect them
to the jack.
To adjust the volume.
1
2
3
4
5
6
7
8
9
10
11
1
2

78
GX460_QG_OM60K88U_(U)
Front Air Conditioning System
■Control panel
■Control screen
Without a navigation system With a navigation system

79
GX460_QG_OM60K88U_(U)
■Adjusting the temperature setting
Press to increase the temperature and to decrease the temperature.
■Adjusting the fan speed setting
Press to increase the fan speed and to decrease the fan speed.
■Changing the air flow mode
Select an air outlet switch.
■Option control screen
Touch on the climate screen to display the option control screen. The functions
can be switched on and off.
Select to set cooling and dehumidifica-
tion function on/off
Adjust the temperature for driver and
passenger seats separately (“DUAL”
mode)/driver, passenger and rear seats
separately (“3-ZONE” mode)
Prevent ice from building up on the
windshield and wiper blades (if
equipped)
Remove pollen from the air
■Using the automatic mode
Press the “AUTO” button to turn on the air flow and adjust the temperature setting.
■Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)/driver, passenger and rear seats separately (“3-ZONE”
mode)
To turn on the “DUAL”/“3-ZONE” mode, perform any of the following procedures:
●Press the “DUAL”/“3-ZONE” button.
●Select “DUAL”/“3-ZONE” on the option control screen.
●Adjust the passenger’s side temperature setting.
1
2
3
4

80
GX460_QG_OM60K88U_(U)
Rear Air Conditioning System (if equipped)
■Control panel
■
Adjusting the temperature setting
Press “” on the “TEMP” button to increase the temperature and “” to decrease the
temperature.
■Adjusting the fan speed setting
Press “” on to increase the fan speed and “” to decrease the fan speed.
■Changing the air flow mode
Press .
The air flow mode switch each time the button is pressed.
■Using the automatic mode
Press the “AUTO” button to turn on the air flow and adjust the temperature setting.
