light Lexus GX460 2014 Owner's Manual

375
GX 460 _O M_ OM6 0K 80 U_ (U)
5Interior features
5-1. Using the air conditioning system and defogger
Front automatic air conditioning system ................376
Rear air conditioning system ......................................... 386
Heated steering wheel/seat heaters/seat ventilators........ 389
5-2. Using the interior lights Interior lights list..........................392• Personal/interior lights main switch .............................393
• Personal/interior lights.......394 5-3. Using the storage features
List of storage features ............ 395• Glove box ............................... 396
• Console box........................... 396
• Coin holder ............................398
• Cup holders/bottle holders/ door pockets..........................398
• Auxiliary boxes .................... 400
Luggage compartment features........................................ 402
5-4. Using the other interior features
Other interior features ............409 • Cool box ..................................409
• Sun visors ................................... 411
• Vanity mirror ............................. 411
• Conversation mirror.............412
• Clock ..........................................412
• Power outlets .......................... 413
• Armrest ......................................417
• Coat hooks ...............................417
• Assist grips............................... 418
• Compass .................................. 419
Garage door opener................ 423
Safety Connect ........................... 428
GX460_OM_OM60K80U_(U).book Page 375 Wednesday, July 3, 2013 11:40 AM

389
GX 460 _O M_ OM6 0K 80 U_ (U)5-1. Using the air conditioning system and defogger
5
Interior features
Heated steering wheel∗/seat heaters∗/seat
ventilators
∗
Turns the heated steering wheel on/off
The indicator light comes on when the
heated steering wheel is operating.
∗: If equipped
Heated steering wheel and seat heaters heat the side grips of the steering
wheel and seats. Seat ventilators maintain good airflow by blowing air from
the seats.
CAUTION
●Care should be taken to prevent injury if anyone in the following categories comes in
contact with the steering wheel and seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically challenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold remedies, etc.)
●Observe the following precautions to prevent the minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat heater.
• Do not use seat heater more than necessary.
NOTICE
●Do not put heavy objects that have an uneven surface on the seat and do not stick
sharp objects (needles, nails, etc.) into the seat.
●To prevent battery discharge, do not use the functions when the engine is off.
Heated steering wheel (if equipped)
GX460_OM_OM60K80U_(U).book Page 389 Wednesday, July 3, 2013 11:40 AM

3905-1. Using the air conditioning system and defogger
GX 460 _O M_ OM6 0K 80 U_ (U)
●The heated steering wheel can be used when the engine switch is in IGNITION ON
mode.
●The heated steering wheel will automatically turn off after about 30 minutes.
●If the indicator light flashes, press the switch to turn the heated steering wheel off and
then press the switch again. If the indicator light still flashes, a malfunction may be
occurring. Turn the heated steering wheel off and have the vehicle inspected by your
Lexus dealer.
■Front seat
Turns the seat heater on
The indicator light comes on.
The higher the number of dots, the
warmer the seat becomes.
■Rear seat For left second seat
For right second seat
High heating temperature
Low heating temperature
To turn on the seat heater, press “HI”
or “LO”.
The indicator light on “HI” or “LO”
switch indicates that the seat heater
is on.
Off
To turn off, press “OFF”.
The seat heaters can be used when the engine switch is in IGNITION ON mode.
Seat heaters (if equipped)
1
2
3
4
5
GX460_OM_OM60K80U_(U).book Page 390 Wednesday, July 3, 2013 11:40 AM

GX 460 _O M_ OM6 0K 80 U_ (U)
3915-1. Using the air conditioning system and defogger
5
Interior features
Heats the seat
The indicator light comes on.
The higher the number of dots, the
warmer the airflow becomes.
Blows air from the seat
The indicator light comes on.
The higher the number of dots, the
stronger the airflow becomes.
The seat heaters and ventilators can be used when the engine switch is in IGNITION
ON mode.
Seat heaters and ventilators (if equipped)
1
2
GX460_OM_OM60K80U_(U).book Page 391 Wednesday, July 3, 2013 11:40 AM

392
GX 460 _O M_ OM6 0K 80 U_ (U)5-2. Using the interior lights
Interior lights list
Personal/interior lights (
→P. 3 9 4 )
Inside door handle lights
Shift lever light
Engine switch light Scuff lights
Footwell lights
Door courtesy lights
Running board lights1
2
3
4
5
6
7
8
GX460_OM_OM60K80U_(U).book Page 392 Wednesday, July 3, 2013 11:40 AM

GX 460 _O M_ OM6 0K 80 U_ (U)
3935-2. Using the interior lights
5
Interior features
Off
The personal/Interior lights and interior light can be individually turned on or
off.
Door position
The personal/interior lights come on wh en a door is opened. They turn off
when the doors are closed.
On
The personal/interior lights cannot be individually turned off.
Personal/interior lights main switch
1
2
3
GX460_OM_OM60K80U_(U).book Page 393 Wednesday, July 3, 2013 11:40 AM

394
GX 460 _O M_ OM6 0K 80 U_ (U)5-2. Using the interior lights
■Illuminated entry system
The lights automatically turn on/off according
to engine switch mode, the presence of the
electronic key, whether the doors are locked/unlocked, and whether the doors are
open/closed.
■To prevent battery discharge
If the following lights remain on when the engine switch is turned off the lights will go off
automatically after 20 minutes:
●Personal/interior light
●Inside door handle lights
●Footwell lights
●Running board lights
■Customization
Settings (e.g. adjust the time elapsed before the interior lights automatically turn off) can
be changed. (Customizable features →P. 5 8 3 )
Personal/interior lights
XFrontXRear
Turns the lights on/off Turns the lights on/off
NOTICE
To prevent battery discharge, do not leave the lights on longer than necessary when the
engine is not running.
GX460_OM_OM60K80U_(U).book Page 394 Wednesday, July 3, 2013 11:40 AM

395
GX 460 _O M_ OM6 0K 80 U_ (U)5-3. Using the storage features
5
Interior features
List of storage features
Cup holders (
→P. 3 9 8 )
Auxiliary boxes (→ P. 4 0 0 )
Bottle holders/door pockets (→ P. 3 9 9 ) Glove box (
→P. 396)
Console box (if equipped) (→ P. 396)
Coin holder (if equipped) (→ P. 3 9 8 )
CAUTION
■Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the
following when cabin temperature becomes high:
●Glasses may be deformed by heat or cracked if they come into contact with other
stored items.
●Lighters or spray cans may explode. If they come into contact with other stored items,
the lighter may catch fire or the spray can may release gas, causing a fire hazard.
■When driving or when the storage compartments are not in use
Keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur due to an
occupant being struck by an open lid or the items stored inside.
1
2
3
4
5
6
GX460_OM_OM60K80U_(U).book Page 395 Wednesday, July 3, 2013 11:40 AM

396
GX 460 _O M_ OM6 0K 80 U_ (U)5-3. Using the storage features
Unlock with the mechanical key
Lock with the mechanical key
Open (push the button)
The glove box light turns on when the tail lights are on.
Your vehicle is equipped with either a console box or cool box.
For vehicles with the cool box, refer to P. 409.
Lift the lid while pulling up the lower
lever to release the lock.
Glove box
1
2
3
Console box (if equipped)
GX460_OM_OM60K80U_(U).book Page 396 Wednesday, July 3, 2013 11:40 AM

GX 460 _O M_ OM6 0K 80 U_ (U)
3975-3. Using the storage features
5
Interior features
●The console box light turns on when the tail lights are on.
●When using the console box lid as an armrest,
slide the console box lid forward or backward
as needed. Slide the lid while pulling up the
upper lever to release the lock.
●The tray in the console box slides forward/
backward.
●To remove the tray, lift up.
NOTICE
Do not insert items exceeding the height of the tray. Doing so may prevent opening and
closing of the lid.
GX460_OM_OM60K80U_(U).book Page 397 Wednesday, July 3, 2013 11:40 AM
