5227-2. Steps to take in an emergency
GX 460 _O M_ OM6 0K 80 U_ (U)
■Warning message in radar cruise mode (if equipped)
In the following situations, the warning message may not be displayed even if vehicle-to-
vehicle distance decreases:
●When your vehicle and the vehicle ahead are traveling at the same speed or the vehicle
ahead is traveling more quickly than your vehicle
●When the vehicle ahead is traveling at a very low speed
●Immediately after cruise control speed is set
●At the instant the accelerator pedal is depressed
■The LDA (Lane Departure Alert) lane departure warning function (if equipped)
In the following situations, the warning message will not be displayed even if a lane line is
crossed.
●When the vehicle speed deviates from the operating range of the LDA system func-
tions
●When the lane lines cannot be recognized
■Conditions that the tire pressure warning system may not function properly
→P. 4 6 8
■Warning buzzer
In some cases, the buzzer may not be heard due to being in a noisy location or audio
sound.
GX460_OM_OM60K80U_(U).book Page 522 Wednesday, July 3, 2013 11:40 AM

5237-2. Steps to take in an emergency
GX 460 _O M_ OM6 0K 80 U_ (U)
7
When trouble arises
Interior buzzerExteriorbuzzerWa r n i n g m e s s a g eDetails/Actions
Once 3 times The electronic key was carried out-
side the vehicle and a door other
than the driver’s door was opened
and closed while the engine switch
was in a mode other than off.
→
Bring the electronic key back
into the vehicle.
The driver’s door was opened and
closed while the electronic key was
not in the vehicle, the shift lever was
in P and the engine switch was not
turned off.
→ Turn the engine switch off.
Bring the electronic key back
into the vehicle.
OnceCon-
tinuous
An attempt was made to exit the
vehicle with the electronic key and
lock the doors without first turning
the engine switch off.
→Turn the engine switch off and
lock the doors again.
Once
• An attempt was made to start the
engine without the electronic key
being present, or the electronic
key was not functioning normally.
• An attempt was made to drive when the regular key was not
inside the vehicle.
→ Confirm that the electronic key
is inside the vehicle.
(Flashes)
(Displayed alternately)
(Flashes)
(Flashes)
GX460_OM_OM60K80U_(U).book Page 523 Wednesday, July 3, 2013 11:40 AM

5247-2. Steps to take in an emergency
GX 460 _O M_ OM6 0K 80 U_ (U)
Con-
tinuous
The driver’s door was opened when
the shift lever was not in P and the
engine switch was not turned off.
→Shift the shift lever to P.
Con-
tinuousCon-
tinuous
The driver’s door was opened and
closed while the electronic key was
not in the vehicle, the shift lever was
not in P and the engine switch was
not turned off.
→Shift the shift lever to P.
→ Bring the electronic key back
into the vehicle.
OnceContin-
uous
• An attempt was made to lock
either front door by opening a
door and putting the inside lock
button into the lock position, then
closing the door with the elec-
tronic key still inside the vehicle.
• An attempt was made to lock the doors using the smart access sys-
tem with push-button start while
the electronic key was still inside
the vehicle.
→ Retrieve the electronic key
from the vehicle and lock the
doors again.
Once
• When the doors were unlocked
with the mechanical key and then
the engine switch was pressed,
the electronic key could not be
detected in the vehicle.
• The electronic key could not be detected in the vehicle even after
the engine switch was pressed
two consecutive times.
→ Touch the electronic key to the
engine switch while depressing
the brake pedal.
Interior
buzzerExteriorbuzzerWa r n i n g m e s s a g eDetails/Actions
(Flashes)
(Displayed alternately)
(Flashes)
(Flashes)
(Flashes)
GX460_OM_OM60K80U_(U).book Page 524 Wednesday, July 3, 2013 11:40 AM

578
GX 460 _O M_ OM6 0K 80 U_ (U)8-2. Customization
Customizable features
■Changing by using the menu switch and the “ENTER” switch
When customizing vehicle features, ensure that the vehicle is parked in a safe
place with the shift lever in
P and the parking brake set.
Press and hold the menu switch to display customization mode. ( →P. 8 1 )
Press the “ENTER” switch upwards or downwards to select the item to be
customized.
Press the “ENTER” switch to confirm.
Press the “ENTER” switch upwards or downwards to select the desired set-
ting for the item being customized.
Press the “ENTER” switch to confirm.
When customization is completed, press the menu switch to clear the cus-
tomization screen.
■Changing by using the multimedia system or navigation system
Press the “SETUP” button on the multimedia system or navigation system.
Select “Vehicle” on the “Setup” screen and select “Vehicle Customization”.
Various setting can be changed. Refer to the list of settings that can be
changed for details.
Your vehicle includes a variety of electronic features that can be personalized
to suit your preferences. The settings of these features can be changed by
using the steering wheel switches, the mu ltimedia system or navigation sys-
tem or at your Lexus dealer.
It is also possible to customize certai n vehicle features yourself using the
menu switch and the “ENTER” switch.
Customizing vehicle features
1
2
3
1
2
GX460_OM_OM60K80U_(U).book Page 578 Wednesday, July 3, 2013 11:40 AM

GX 460 _O M_ OM6 0K 80 U_ (U)
5798-2. Customization
8
Vehicle specifications
Some function settings are changed simultaneously with other functions being
customized. Contact your Lexus dealer for further details.
Settings that can be changed using the menu switch and the “ENTER” switch
Settings that can be changed using the multimedia system or navigation sys-
tem
Settings that can be changed by your Lexus dealer
Definition of symbols: O = Available, – =Not available
■Multi-information display ( →P. 8 0 )
*: The default setting varies according to countries.
■Door lock ( →P. 92, 99, 543)
Customizable features
1
2
3
FunctionDefault settingCustomized
setting
Language*EnglishFrenchOOOSpanish
Units*miles (MPG US)km (km/L)O—Okm (L/100km)
Eco Driving Indicator LightOnOffO—O
123
FunctionDefault settingCustomized
setting
Unlocking using a
mechanical key
Driver’s door
unlocked in one
step, all doors
unlocked in two
stepsAll doors
unlocked in one
step——O
Speed linked door locking
functionOffOn—OO
Shift position linked door
locking functionOnOff—OO
Shift position linked door
unlocking functionOnOff—OO
Driver’s door linked door
unlocking functionOffOn—OO
123
GX460_OM_OM60K80U_(U).book Page 579 Wednesday, July 3, 2013 11:40 AM

GX 460 _O M_ OM6 0K 80 U_ (U)
5878-2. Customization
8
Vehicle specifications
■Intuitive parking assist* (→P. 2 3 4 )
*: If equipped
■In the following situations, customize mode will automatically be turned off.
●A warning message appears after the customize mode screen is displayed.
●The engine switch is turned to OFF.
●The vehicle begins to move while the customize mode screen is displayed.
FunctionDefault settingCustomized
setting
Buzzer volumeLevel 5Level 1 to 5—OO
Display settingAll sensors displayedDisplay off—OO
Detection distance of the
front center sensorFarNear—OO
Detection distance of the
rear center sensorFarNear—OO
123
CAUTION
■During customization
As the engine needs to be running during customization, ensure that the vehicle is
parked in a place with adequate ventilation. In a closed area such as a garage, exhaust
gases including harmful carbon monoxide (CO) may collect and enter the vehicle. This
may lead to death or a serious health hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that the engine is running while customizing fea-
tures.
GX460_OM_OM60K80U_(U).book Page 587 Wednesday, July 3, 2013 11:40 AM

607What to do if... (Troubleshooting)
GX 460 _O M_ OM6 0K 80 U_ (U)
●Is the electronic key left inside the vehicle or the moon roof opened?
Check the message on the multi-information display. ( →P. 5 1 4 )
●When a warning light turns on or a warning message is displayed, refer to
P. 5 0 7 , 5 1 4 .
●Stop the vehicle in a safe place and replace the flat tire with the spare tire.
(→ P. 5 2 7 )
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow.
(→ P. 5 5 1 )
A warning buzzer sounds wh
en leaving the vehicle
A warning light turns on or a warning message is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck
GX460_OM_OM60K80U_(U).book Page 607 Wednesday, July 3, 2013 11:40 AM

610Alphabetical index
GX 460 _O M_ OM6 0K 80 U_ (U)
Crawl Control ....................................... 336
Cruise controlCruise control........................................214
Dynamic radar crui se control........ 217
Cup holders ............................................398
Curtain shield airbags ........................... 34
Current fuel consumption .....................81
Customizable features ....................... 578
DAC (Downhill Assist Control system)................................................... 339
Daytime running light system ............194
Defogger Front windshield ................................ 380
Outside rear view mirrors .............. 381
Rear window ......................................... 381
Differential............................................... 559
Dimension ............................................... 554
Display
Multi-information display ................. 80
Trip information ...................................... 81
Warning message .............................. 514
Do-it-yourself maintenance ............. 447
Doors............................................................ 92 Back door ............................................. 99
Door glasses ..........................................142
Door lock .................................................. 92
Open door warning light.............. 509
Outside rear view mirrors .............. 139
Rear door child-protector................95
Driver’s seat position memory ......... 128 Driving ........................................................150
AVS switch ............................................. 331
Break-in tips ........................................... 176
Correct posture .................................... 26
Procedures ............................................ 150
Winter drive tips ................................ 366
Dynamic radar cruise control ........... 217
Eco Driving Indicator ............................ 84
Electronic key ........................................... 88 Battery-saving function ..................... 110
If the electronic key does not operate properly ............................ 543
Replacing the battery ...................... 479
Emergency, in case of
If the electronic key does not operate properly ............................ 543
If the engine will not start ...............540
If the shift lever cannot be shifted from P ................................... 542
If the vehicle has
discharged battery ........................545
If the warning buzzer
sounds ................................................. 507
If the warning light turns on .......... 507
If you have a flat tire .......................... 527
If you lose your keys.........................604
If you think something is wrong.................................................. 505
If your vehicle becomes stuck....................................................... 551
If your vehicle needs to be towed .................................................. 500
If your vehicle overheats ................548
D
E
GX460_OM_OM60K80U_(U).book Page 610 Wednesday, July 3, 2013 11:40 AM

614Alphabetical index
GX 460 _O M_ OM6 0K 80 U_ (U)
Meter .............................................................77Indicators................................................... 72
Instrument panel light control .........78
Meters......................................................... 77
Multi-information display ................. 80
Warning lights ........................................ 72
Micro dust and pollen filter ............... 381
Mirrors Inside rear view mirror ......................137
Outside rear view mirror defoggers ............................................ 381
Outside rear view mirrors .............. 139
Vanity mirrors ......................................... 411
Moon roof..................................................145
Jam protection function ................... 143
Operation ............................................... 145
MP3 disc
*
Multi-information display ..................... 80
Switching the display............................ 81
Trip information ...................................... 81
Multi-terrain Monitor .........................303
Multi-terrain Select.............................. 298
Navigation system
*
Odometer ................................................... 77
Off-road precautions ......................... 369
Oil Engine oil ...............................................556
Front differential oil ...........................559
Rear differential oil ............................559
Transfer.................................................. 560
Opener Back door................................................. 99
Fuel filler door........................................210
Hood........................................................450
Outside rear view mirrors.................. 139 Adjusting and folding ........................139
Blind spot monitor ............................ 347
Outside rear view mirror
defoggers............................................ 381
Outside temperature display ............. 84
Overheating, Engine .......................... 548
Parking assist sensors
(intuitive parking assist)...................234
Parking assist monitor ........................ 253
Parking brake ........................................... 191 Operation................................................. 191
Parking brake engaged warning buzzer ............................... 507
Personal lights ....................................... 392 Switch ...................................................... 393
Wattage .................................................563
N
O
P
GX460_OM_OM60K80U_(U).book Page 614 Wednesday, July 3, 2013 11:40 AM
