clock Lexus GX460 2014 Owner's Manual

TABLE OF CONTENTS4
GX 460 _O M_ OM6 0K 80 U_ (U)
5-1. Using the air conditioning system and defogger
Front automatic air conditioning system ................ 376
Rear air conditioning system .......................................... 386
Heated steering wheel/seat heaters/seat ventilators ........389
5-2. Using the interior lights Interior lights list ......................... 392• Personal/interior lights main switch ............................. 393
• Personal/interior lights ...... 394
5-3. Using the storage features List of storage features ............ 395
• Glove box ............................... 396
• Console box .......................... 396
• Coin holder ............................398
• Cup holders/bottle holders/door pockets..........................398
• Auxiliary boxes .....................400
Luggage compartment features ....................................... 402 5-4. Using the other interior
features
Other interior features ............ 409 • Cool box.................................. 409
• Sun visors ................................... 411
• Vanity mirror ............................. 411
• Conversation mirror ............ 412
• Clock .......................................... 412
• Power outlets ...........................413
• Armrest...................................... 417
• Coat hooks............................... 417
• Assist grips ...............................418
• Compass ...................................419
Garage door opener ............... 423
Safety Connect........................... 428
5Interior features
GX460_OM_OM60K80U_(U).book Page 4 Wednesday, July 3, 2013 11:40 AM

375
GX 460 _O M_ OM6 0K 80 U_ (U)
5Interior features
5-1. Using the air conditioning system and defogger
Front automatic air conditioning system ................376
Rear air conditioning system ......................................... 386
Heated steering wheel/seat heaters/seat ventilators........ 389
5-2. Using the interior lights Interior lights list..........................392• Personal/interior lights main switch .............................393
• Personal/interior lights.......394 5-3. Using the storage features
List of storage features ............ 395• Glove box ............................... 396
• Console box........................... 396
• Coin holder ............................398
• Cup holders/bottle holders/ door pockets..........................398
• Auxiliary boxes .................... 400
Luggage compartment features........................................ 402
5-4. Using the other interior features
Other interior features ............409 • Cool box ..................................409
• Sun visors ................................... 411
• Vanity mirror ............................. 411
• Conversation mirror.............412
• Clock ..........................................412
• Power outlets .......................... 413
• Armrest ......................................417
• Coat hooks ...............................417
• Assist grips............................... 418
• Compass .................................. 419
Garage door opener................ 423
Safety Connect ........................... 428
GX460_OM_OM60K80U_(U).book Page 375 Wednesday, July 3, 2013 11:40 AM

402
GX 460 _O M_ OM6 0K 80 U_ (U)5-3. Using the storage features
Luggage compartment features
Raise the hook to use.
The cargo hooks are provided for
securing loose items.
When using the deck hooks, the third
seat must be fold down. (
→P. 1 2 3 )
Open the cover.
Turn the knob clockwise.
Open the cover.
Secure the warning reflector.
The warning reflector itself is not
included as an original equipment.
Cargo hooks
Warning reflector holder
1
1
2
2
GX460_OM_OM60K80U_(U).book Page 402 Wednesday, July 3, 2013 11:40 AM

412
GX 460 _O M_ OM6 0K 80 U_ (U)5-4. Using the other interior features
The conversation mirror can provide the driver and the front passenger with a
view of the rear seat area without the need to turn around.
Press in the button.
To use the overhead console when the conversation mirror is open, further extend the lid.
(
→ P. 400)
XVehicles with a navigation system
Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
XVehicles without a navigation system
Adjusts the hours
Adjusts the minutes
■The clock is displayed when
The engine switch is in IGNITION ON mode.
■When disconnecting and reconnecting battery terminals
The clock data will be reset.
Conversation mirror
Clock
1
2
GX460_OM_OM60K80U_(U).book Page 412 Wednesday, July 3, 2013 11:40 AM

454
GX 460 _O M_ OM6 0K 80 U_ (U)6-3. Do-it-yourself maintenance
■Adding engine oil
If the oil level is below or near the
low level mark, add engine oil of the
same type as already in the engine.
Make sure to check the oil type and prepare the items needed before adding
oil.
Remove the oil filler cap by turning it counterclockwise.
Add engine oil slowly, checking the dipstick.
Install the oil filler cap by turning it clockwise.
■Engine oil consumption
A certain amount of engine oil will be consumed while driving. In the following situations,
oil consumption may increase, and engine oil may need to be refilled in between oil
maintenance intervals.
●When the engine is new, for example direct ly after purchasing the vehicle or after
replacing the engine
●If low quality oil or oil of an inappropriate viscosity is used
●When driving at high engine speeds or with a heavy load, when towing, or when driving
while accelerating or decelerating frequently
●When leaving the engine idling for a long time, or when driving frequently through
heavy traffic
Engine oil selection→ P. 5 5 6
Oil quantity (Low → Full)1.6 qt. (1.5 L, 1.3 Imp.qt.)
ItemsClean funnel
1
2
3
GX460_OM_OM60K80U_(U).book Page 454 Wednesday, July 3, 2013 11:40 AM

GX 460 _O M_ OM6 0K 80 U_ (U)
4596-3. Do-it-yourself maintenance
6
Maintenance and care
■Fluid level
The fluid level should be within the appropriate range.Full (when cold)
Add fluid (when cold)
Full (when hot)
Add fluid (when hot)
Hot: The vehicles has been driven around 50 mph (80 km/h) for 20 min- utes, or slightly longer in frigid temperatures.
(Fluid temperature, 140 °F - 175 °F [60 °C - 80 °C]).
Cold: The engine has not been run for about 5 hours. (Room temperature, 50 °F - 85 °F [10 °C - 30 °C]).
■Checking the fluid level
Make sure to check the fluid type and prepare the necessary items.
Clean all dirt off the reservoir.
Remove the cap by turning it counterclockwise.
Wipe the dipstick clean.
Reinstall the cap and remove it again.
Check the fluid level.
Power steering fluid
1
2
3
4
Fluid typeAutomatic transmission fluid DEXRON® II or III
ItemsRag or paper, clean funnel (only for adding fluid)
1
2
3
4
5
GX460_OM_OM60K80U_(U).book Page 459 Wednesday, July 3, 2013 11:40 AM

488
GX 460 _O M_ OM6 0K 80 U_ (U)6-3. Do-it-yourself maintenance
■Headlight high beams
Turn the cover counterclockwise.
Turn the bulb base counterclock-
wise.
Unplug the connector while pull-
ing the lock release.
Replacing light bulbs
1
2
3
GX460_OM_OM60K80U_(U).book Page 488 Wednesday, July 3, 2013 11:40 AM

490
GX 460 _O M_ OM6 0K 80 U_ (U)6-3. Do-it-yourself maintenance
■Front turn signal lights
Turn the bulb base counterclock-
wise.
Remove the light bulb.
When installing, reverse the steps listed.
1
2
3
GX460_OM_OM60K80U_(U).book Page 490 Wednesday, July 3, 2013 11:40 AM

492
GX 460 _O M_ OM6 0K 80 U_ (U)6-3. Do-it-yourself maintenance
Unplug the connector while
pushing the lock release.
Turn the bulb bases counter-
clockwise.
Rear turn signal light
Rear side marker light
Remove the light bulb. Rear turn signal light
Rear side marker light
When installing, reverse the steps listed.2
3
1
2
4
1
2
5
GX460_OM_OM60K80U_(U).book Page 492 Wednesday, July 3, 2013 11:40 AM

GX 460 _O M_ OM6 0K 80 U_ (U)
4936-3. Do-it-yourself maintenance
6
Maintenance and care
■Back-up lightsRemove the bolts and pull down
the under cover.
Turn the bulb base counterclock-
wise.
Remove the light bulb.
When installing, reverse the steps listed.
1
2
3
4
GX460_OM_OM60K80U_(U).book Page 493 Wednesday, July 3, 2013 11:40 AM
