1
GX460_QG_OM60K88U_(U)
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manuals so you will have a better
understanding of your vehicle’s capabilities and limitations.
Audio System (with multimedia system)*
Audio control screen.................................................................................................................... 69
Remote control (steering wheel switches).......................................................................... 69
Basic operation ............................................................................................................................... 70
Radio .....................................................................................................................................................71
CD player.......................................................................................................................................... 72
Operating an iPod ......................................................................................................................... 73
Audio System (with navigation system)
*
Audio control screen....................................................................................................................59
Remote control (steering wheel switches)..........................................................................59
Basic operation ...............................................................................................................................60
Radio .....................................................................................................................................................61
DVD player ........................................................................................................................................61
Operating an iPod .........................................................................................................................63
Automatic High Beam ......................................................................................................................39
BSM (Blind Spot Monitor)...............................................................................................................35
Crawl Control.......................................................................................................................................34
Cruise Control ...................................................................................................................................... 21
Door Locks ............................................................................................................................................ 92
Dynamic Radar Cruise Control ....................................................................................................23
Eco Driving Indicator Light .............................................................................................................. 19
Engine (Ignition) Switch..................................................................................................................... 16
Floor mat installation .............................................................................................................................11
Four-wheel Drive System ................................................................................................................. 33
Front Air Conditioning System
Control panel ........................................................................................................................................... 78Control screen ................................................................................................................................ 78
Using the automatic mode......................................................................................................... 79
Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)/driver, passenger and rear seats separately
(“3-ZONE” mode)........................................................................................................................ 79
Fuel Tank Cap .......................................................................................................................................95
*: These features may be operated by Voice Command (See P. 82)

3
GX460_QG_OM60K88U_(U)
Keys ............................................................................................................................................................ 12
LDA (Lane Departure Alert).......................................................................................................... 27
Lexus Enform with Safety Connect (for U.S.A., if equipped)............................................89
List of Warning/Indicator Lights ................................................................................................... 97
Moon Roof ............................................................................................................................................. 94
Multi-information Display ................................................................................................................. 18
Multi-terrain Monitor......................................................................................................................... 32
Multi-terrain Select.............................................................................................................................30
Navigation System
Register home ................................................................................................................................. 47
Destination input
 Search by address ................................................................................ 49
Destination input
 Search points of interest by name................................................... 51
Destination input
 Search points of interest by category........................................... 52
Destination input
 Search points of interest by phone number...............................53
Voice Command System ............................................................................................................82
Portable Audio Device Ports ..........................................................................................................86
Power Windows ................................................................................................................................... 93
Rear Air Conditioning System
Control panel ................................................................................................................................. 80
Using the automatic mode........................................................................................................80
Control screen (front controller) ............................................................................................. 81
Rear Seat Entertainment System ...................................................................................................74
Rear Window Wiper and Washer ................................................................................................ 43

6
GX460_QG_OM60K88U_(U)
Emergency flasher switch*
Audio system P. 59, 69
Glove box*
Touch screen P. 44, 64
See P. 9
: If equipped
*: Refer to “OWNER’S MANUAL”.
Air conditioning system P. 78
Navigation System
P. 47

8
GX460_QG_OM60K88U_(U)
Audio remote control switches P. 59, 69
Telephone switches
P. 58, 68
Menu switch P. 18
“ENTER” switch
P. 18
Wide view front & side monitor switch
Multi-terrain Monitor switch

P. 29
P. 32
Horn*1
Talk switch P. 82
Cruise control switch P. 21, 23
“LDA” switch P. 27
Vehicle-to-vehicle distance button P. 23
: If equipped
*1: Refer to “OWNER’S MANUAL”.
*2: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL” or
“MULTIMEDIA OWNER’S MANUAL”.
Tilt and telescopic steering
control switch
*1

17
GX460_QG_OM60K88U_(U)
■Changing engine switch modes
Modes can be changed by pressing the engine switch with brake pedal released. (The mode
changes each time the switch is pressed.)
Off*
The emergency flashers can be used.
ACCESSORY mode
Some electrical components such as
the audio system can be used.
The engine switch indicator turns
amber.
IGNITION ON mode
All electrical components can be used.
The engine switch indicator turns
amber.
*: If the shift lever is in a position other than
P when turning off the engine, the
engine switch will be turned to ACCES-
SORY mode, not to OFF.
1
2
3

44
GX460_QG_OM60K88U_(U)
Touch Screen (with navigation system)
■Basic operation
Press to display the hands-free operation screen.
Press to display the “Information” screen.
Press to display the “Setup” screen.
Press to display the home screen.
Press to display the air conditioning control screen.
Press to display the map screen.
Press to display the audio/visual screen.
This system is operated mainly by selecting the buttons on the screen. (Referred to as
screen buttons in this manual.)
For details, see the “Navigation System Owner’s Manual”.
1
2
3
4
5
6
7

45
GX460_QG_OM60K88U_(U)
■Home
Three-way split screen
Press the “HOME” button to display the
home screen.
The home screen can display multiple infor-
mation screens, such as the navigation sys-
tem screen, audio system screen and fuel
consumption screen, simultaneously. When
a screen is selected, the selected screen is
switched to a full-screen display.
Displays the condition of the
Bluetooth
® connection
Select to change the display items/area
and the home screen layout. Two-way split screen
■Screen scroll operation
Use the scroll feature to move the desired
point to the center of the screen for looking
at a point on the map that is different from
the current position.
Cursor mark
Distance from the current position to
the cursor mark.
Zooms in on the map
Zooms out on the map
Select to return to the current position.
Select to register as a memory point.
Select to set as a destination.
1
2
1
2
3
4
5
6
7

59
GX460_QG_OM60K88U_(U)
Audio System (with navigation system)
■Audio control screen
Follow the procedure below to display the audio control screen.
Press the “AUDIO” button.
■Remote control (steering wheel switches)
Some audio features can be controlled using the switches on the steering wheel.
Increases/decreases volume
Radio mode: Selects a radio station/
channel
Audio CD mode: Selects a track
MP3/WMA/AAC disc mode: Selects
a file
DVD mode: Selects a chapter
iPod mode: Selects a track/file
Press: Change audio modes
Press and hold: Mute/unmute or
pause/resume the current operation
1
1
2
3

60
GX460_QG_OM60K88U_(U)
■Basic operation
Sound settings
Audio sources
AM: AM radio
FM: FM radio
SAT: Satellite radio*
1
APPS (if equipped):
Internet radio broadcast
DISC: DVD player
iPod: iPod
USB: USB memory
Bluetooth*
2: Bluetooth® audio
AUX: Auxiliary audio device
Po w e r/ Vo l u m e
*
1: To listen to a satellite radio broadcast in the vehicle, a subscription to the XM Satellite
Radio service is necessary. (P. 9 1 )
*
2: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
1
2
3

61
GX460_QG_OM60K88U_(U)
■Radio
Tuning to preset stations/channels
Scanning for receivable stations
Using HD Radio
TM Te c h n o l o g y ( f o r
U.S.A., if equipped)
Cache radio operation buttons
Adjusting the frequency
Press: Selects a preset station
Press and hold: Seeks for a station
■Entering station presets
Tune in the desired station.
Select “add new”.
Select “Yes” on the confirmation screen.
Select “OK” after setting the new preset station.
Radio mode has a mix preset function, which can store up to 36 stations (6 stations per
page x 6 pages) from any of the AM, FM or SAT bands.
■DVD player
■
Playing an audio CD
Playback/pause
Repeat playback
Random playback
Disc eject
Selecting a track
Disc slot
1
2
3
4
5
6
1
2
3
4
1
2
3
4
5
6
