GX460_QG_OM60K88U_(U)
Keys ............................................................................................................................................................ 12
LDA (Lane Departure Alert).......................................................................................................... 27
Lexus Enform with Safety Connect (for U.S.A., if equipped)............................................89
List of Warning/Indicator Lights ................................................................................................... 97
Moon Roof ............................................................................................................................................. 94
Multi-information Display ................................................................................................................. 18
Multi-terrain Monitor......................................................................................................................... 32
Multi-terrain Select.............................................................................................................................30
Navigation System
Register home ................................................................................................................................. 47
Destination input
 Search by address ................................................................................ 49
Destination input
 Search points of interest by name................................................... 51
Destination input
 Search points of interest by category........................................... 52
Destination input
 Search points of interest by phone number...............................53
Voice Command System ............................................................................................................82
Portable Audio Device Ports ..........................................................................................................86
Power Windows ................................................................................................................................... 93
Rear Air Conditioning System
Control panel ................................................................................................................................. 80
Using the automatic mode........................................................................................................80
Control screen (front controller) ............................................................................................. 81
Rear Seat Entertainment System ...................................................................................................74
Rear Window Wiper and Washer ................................................................................................ 43

5
GX460_QG_OM60K88U_(U)
OverviewInstrument Panel
See P. 7
Inside lock buttons
P. 92
Door lock switches P. 92
Power window switches
P. 93
Window lock switch P. 93
Driving position memory
buttons
*
Hood lock release lever*
See P. 8
Parking brake pedal
*
Pre-collision braking off switch*
Center differential lock/unlock switch P. 33
Automatic High Beam
Fog light switch
*
P. 39
Windshield wipers
and washer switch
Rear window wiper
and washer switch
P. 40
P. 43
Engine (ignition) switch P. 16
Headlight switch P. 37
Turn signal lever P. 20

12
GX460_QG_OM60K88U_(U)
Keys
■Electronic key
Smart access system with push-button start
(P. 13, 16)
Wireless remote control (P. 1 2 )
■Mechanical key
To take out the mechanical key, slide the
release lever and take the key out.
After using the mechanical key, store it in
the electronic key. Carry the mechanical
key together with the electronic key.
If the electronic key battery is depleted
or the entry function does not operate
properly, you will need the mechanical
key.
■Wireless remote control
Locks the doors
Unlocks the doors
Opens the windows and moon roof*
Opens the glass hatch (press and hold)
Sounds the alarm (if equipped)
*: This setting must be customized at your
Lexus dealer.1
2
3
4
5

43
GX460_QG_OM60K88U_(U)
Rear Window Wiper and Washer
Ty p e A
Off
Intermittent operation
Normal operation
Washer/wiper dual operation
Washer/wiper dual operation
Ty p e B
Off
Intermittent operation
Normal operation
Washer/wiper dual operation
Washer/wiper dual operation
1
2
3
4
5
1
2
3
4
5

93
GX460_QG_OM60K88U_(U)
■Rear door child-protector lock
The door cannot be opened from inside the
vehicle when the lock is set.
Unlock
Lock
These locks can be set to prevent chil-
dren from opening the rear doors.
Push down on each rear door switch to
lock both rear doors.
Powe r Wi n d ows
■Po w e r w i n d o w s w i t c h e s
Closing
One-touch closing*
Opening
One-touch opening*
*: To stop the window partway, operate the
switch in the opposite direction.
■Window lock switch
Press the switch down to lock the passen-
ger window switches.
The indicator will come on.
Use this switch to prevent children from
accidentally opening or closing a pas-
senger window.
The passenger windows can still be
opened and closed using the power win-
dow switches on the driver’s side even if
the lock switch is on.
1
2
1
2
3
4
Indicator

95
GX460_QG_OM60K88U_(U)
Fuel Tank Cap
■Before refueling the vehicle
●Close all the doors and windows, and turn the engine switch off.
●Confirm the type of fuel.
■Opening the fuel tank cap
Press the opener to open the fuel filler
door.
Turn the fuel tank cap slowly to open,
and hang the fuel tank cap on the back
of the fuel filler door.1
2

100
What to do if ...
GX460_QG_OM60K88U_(U)
If the electronic key does not operate properly
■Unlocking and locking the doors
Use the mechanical key (P.1 2 ) i n o r d e r t o
perform the following operations (driver’s
door only):
Locks all the doors
Closes the windows and moon roof*
(turn and hold)
Unlocks the doors
Turning the key rearward unlocks the
driver’s door. Turning the key once
again unlocks the other doors.
Opens the windows and moon roof*
(turn and hold)
*: These settings must be customized at
your Lexus dealer.
■Starting the engine
Ensure that the shift lever is in P and
depress the brake pedal.
Touch the Lexus emblem side of the
electronic key to the engine switch.
If any of the doors is opened or
closed while the key is being touched
to the switch, an alarm will sound to
indicate that the start function cannot
detect the electronic key.
Press the engine switch within 10 sec-
onds of the buzzer sounding, keeping
the brake pedal depressed.
In the event that the engine switch still cannot be operated, contact your Lexus dealer.
1
2
3
4
1
2
3
If the electronic key battery becomes depleted, replace it with a new battery. For instruc-
tions on replacing the battery, refer to the Owner’s Manual. If you need further assistance,
contact your Lexus dealer.
