Lexus GX460 2014 VOICE COMMAND SYSTEM OPERATION / LEXUS 2014 GX460 OWNERS MANUAL (OM60K80U)

601
GX460_OM_OM60K80U_(U)
9
For owners
Headlight aim instructions for Canadian owners
(in French)
Boulon de réglage A
Boulon de réglage B
Assurez-vous que le réservoir de carburant du véhicule est plein et que la
partie de carrosserie située autour des phares n’est pas déformée.
Garez le véhicule sur un sol parfaitement horizontal.
Asseyez-vous sur le siège du conducteur.
Faites rebondir le véhicule à plusieurs reprises.
The following is a French explanation of headlight aim instructions from the
headlight aim section in this manual.
Boulons de réglage vertical
1
2
Avant de vérifier la portée des phares
1
2
3
4

602
GX460_OM_OM60K80U_(U)
Tournez le boulon A vers la droite ou vers la gauche à l’aide d’un tournevis
cruciforme.
Retenez le sens de rotation et le nombre de tours.
Tournez le boulon B du même nom-
bre de tours et dans le même sens
qu’à l’étape .
Si vous n’arrivez pas à régler vos phares
en suivant cette procédure, apportez le
véhicule chez votre concessionnaire
Lexus afin qu’il règle la portée des
phares.
Réglage de la portée des phares
1
Côté gaucheCôté droit
2
1

GX460_OM_OM60K80U_(U)
603
9
For owners

604
GX460_OM_OM60K80U_(U)

603
GX460_OM_OM60K80U_(U)
Index
What to do if... (Troubleshooting)................................604
Alphabetical index................................ 608

604What to do if... (Troubleshooting)
GX460_OM_OM60K80U_(U)
What to do if... (Troubleshooting)
●If you lose your mechanical keys, new genuine mechanical keys can be made
by your Lexus dealer. ( P. 8 9 )
●If you lose your electronic keys, the risk of vehicle theft increases significantly.
Contact your Lexus dealer immediately. ( P. 8 9 )
●Is the electronic key battery weak or depleted? ( P. 4 7 9 )
●Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. ( P. 1 8 2 )
●Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on your
person.
●The function may not operate properly du e to the condition of the radio wave.
( P. 1 1 0 )
●Is the child-protector lock set?
The rear door cannot be opened from in side the vehicle when the lock is set.
Open the rear door from outside and then unlock the child-protector lock.
( P. 9 5 )
If you have a problem, check the following before contacting your Lexus
dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

605What to do if... (Troubleshooting)
GX460_OM_OM60K80U_(U)
●Did you press the engine switch while firmly depressing the brake pedal?
(P. 1 8 1 )
●Is the shift lever in P? ( P. 181)
●Is the electronic key anywhere detectable inside the vehicle? ( P. 1 0 8 )
●Is the steering wheel unlocked? ( P. 1 8 4 )
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. (P. 5 4 4 )
●Is the battery discharged? ( P. 5 4 5 )
●Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in IGNITION ON mode ( P. 5 4 2 )
If you think something is wrong
The engine does not start
The shift lever cannot be shifted from P even if you depress the brake
pedal

606What to do if... (Troubleshooting)
GX460_OM_OM60K80U_(U)
●It is locked automatically to prevent theft of the vehicle. ( P. 1 8 3 )
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be operated
if the window lock switch is pressed. ( P. 1 4 2 )
●The auto power off function will be oper ated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. ( P. 1 8 3 )
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts?
( P. 5 0 9 )
●The parking brake indicator is on
Is the parking brake released? ( P. 1 9 1 )
Depending on the situation, other type s of warning buzzer may also sound.
( P. 5 0 7 , 5 1 4 )
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 6 8 )
To stop the alarm, turn the engine switch to IGNITION ON mode or start the
engine. The steering wheel cannot be turned after the engine is stopped
The windows do not open or close by operating the power window
switches
The engine switch is turned off automatically
A warning buzzer sounds during driving
An alarm is activated and the horn sounds

607What to do if... (Troubleshooting)
GX460_OM_OM60K80U_(U)
●Is the electronic key left inside the vehicle or the moon roof opened?
Check the message on the multi-information display. (P. 5 1 4 )
●When a warning light turns on or a warning message is displayed, refer to
P. 5 0 7 , 5 1 4 .
●Stop the vehicle in a safe place and replace the flat tire with the spare tire.
( P. 5 2 7 )
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow.
(P. 551)
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

608Alphabetical index
GX460_OM_OM60K80U_(U)
Alphabetical index
A/C .................................................376, 386Air conditioning filter........................ 477
ABS (Anti-lock Brake System).........341 Function ................................................... 341
Active Traction Control .................... 342 Warning light ...................................... 507
Air conditioning filter ...........................477
Air conditioning system ..........376, 386 Air conditioning filter........................ 477
Airbags ........................................................ 34 Airbag operating conditions ........... 42
Airbag precautions for your child........................................ 37
Airbag warning light ........................ 507
Correct driving posture .................... 26
Curtain shield airbag operating conditions........................ 42
Curtain shield airbag precautions ........................................... 37
General airbag precautions............ 37
Locations of airbags ............................ 34
Modification and disposal of airbags ..............................41
Side airbag operating conditions .............................................. 42
Side airbag precautions..................... 37
Side and curtain shield airbags operating conditions........................ 42
Side and curtain shield airbags precautions ........................................... 37
SRS airbags.............................................. 34
SRS warning light.............................. 507
Alarm ............................................................ 68 Alarm...........................................................68
Warning buzzer ................................ 507
Anchor brackets ...................................... 58 Antennas (smart access system
with push-button start) .................... 108
Anti-lock brake system (ABS) ....................................................... 341 Function .................................................... 341
Warning light ....................................... 507
Armrest ...................................................... 417
Assist grip .................................................. 418
Audio input
*
Audio system*
Automatic headlight leveling system ..................................... 194
Automatic High Beam ......................... 195
Automatic light control system ........ 194
Automatic transmission.......................186 If the shift lever cannot be shifted from P ................................... 542
S mode..................................................... 188
AUX port
*
Auxiliary boxes ..................................... 400
AVS ............................................................. 331
Back door ....................................................99
Back-up lights Replacing light bulbs .........................491
Wattage .................................................563
Battery ...................................................... 460 Battery checking ................................460
If the vehicle battery is discharged.........................................545
Preparing and checking before winter .................................... 366
Warning light ....................................... 507
Bluetooth
®*
A
B
