service indicator Lexus GX460 2014 VOICE COMMAND SYSTEM OPERATION / LEXUS 2014 GX460 OWNERS MANUAL (OM60K80U)

428
GX460_OM_OM60K80U_(U)5-4. Using the other interior features
Safety Connect
Microphone
LED light indicators
“SOS” button
: If equipped
Safety Connect is a subscription-based telematics service that uses Global
Positioning System (GPS) data and embe
dded cellular technology to provide
safety and security features to subscribers. Safety Connect is supported by
Lexus’ designated response center, wh ich operates 24 hours per day, 7 days
per week.
Safety Connect service is available by su bscription on select, telematics hard-
ware-equipped vehicles.
By using the Safety Connect service, yo u are agreeing to be bound by the
Telematics Subscription Service Agreement and its Terms and Conditions, as
in effect and amended from time to time, a current copy of which is available
at Lexus.com. All use of the Safety Connect service is subject to such then-
applicable Terms and Conditions.
System components
1
2
3

430
GX460_OM_OM60K80U_(U)5-4. Using the other interior features
When the engine switch is turned to IGNITION ON mode, the red indicator
light comes on for 2 seconds then turns
off. Afterward, the green indicator light
comes on, indicating that the service is active.
The following indicator light patterns indicate specific system usage conditions:
●Green indicator light on = Active service
●Green indicator light flashing = Safety Connect call in process
●Red indicator light (except at vehicle start-up) = System malfunction (contact
your Lexus dealer)
●No indicator light (off) = Safety Connect service not active
■Automatic Collis ion Notification
In case of either airbag deployment or severe rear-end collision, the system is
designed to automatically call the response center. The responding agent
receives the vehicle’s location and attempts to speak with the vehicle occu-
pants to assess the level of emergency. If the occupants are unable to commu-
nicate, the agent automatically treats the call as an emergency, contacts the
nearest emergency services provider to describe the situation, and requests
that assistance be se nt to the location.
Safety Connect LED light Indicators
Safety Connect services

446
GX460_OM_OM60K80U_(U)6-2. Maintenance
Emission inspection and
maintenance (I/M) programs
The OBD system determines that a problem exists somewhere in the emission
control system. Your vehicle may not pa ss the I/M test and may need to be
repaired. Contact your Lexus dealer to service the vehicle.
●When the battery is disconnected or discharged
Readiness codes that are set during ordinary driving are erased.
Also, depending on your driving habits, the readiness codes may not be com-
pletely set.
●When the fuel tank cap is loose
The malfunction indicator lamp comes on indicating a temporary malfunction
and your vehicle may not pass the I/M test.
The error code in the OBD system will not be cleared unless the vehicle is driven
40 or more times.
Contact your Lexus dealer to prepare the vehicle for re-testing.
Some states have vehicle emission inspection programs which include OBD
(On Board Diagnostics) checks. The OBD system monitors the operation of
the emission control system.
If the malfunction indicator lamp comes on
Your vehicle may not pass the I/M test in the following situations:
When the malfunction indicator lamp s till remains on after several driv-
ing trips
If your vehicle does not pass the I/M test

GX460_OM_OM60K80U_(U)
5658-1. Specifications
8
Vehicle specifications
■Recommendation of the use of gasoline containing detergent additives
●Lexus recommends the use of gasoline that contains detergent additives to avoid the
build-up of engine deposits.
●All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or
keep clean intake systems, per EPA’s lowest additives concentration program.
●Lexus strongly recommends the use of Top Ti er Detergent Gasoline. For more informa-
tion on Top Tier Detergent Gasoline and a list of marketers, please go to the official
website www.toptiergas.com.
■Recommendation of the use of cleaner burning gasoline
Cleaner burning gasoline, including reformul ated gasoline that contains oxygenates
such as ethanol or MTBE (Methyl Tertiary Butyl Ether) is available in many areas.
Lexus recommends the use of cleaner bu rning gasoline and appropriately blended
reformulated gasoline. These types of gaso line provide excellent vehicle performance,
reduce vehicle emissions and improve air quality.
■Non-recommendation of the use of blended gasoline
●If you use gasohol in your Lexus, be sure that it has an octane rating no lower than 87.
●Lexus does not recommend the use of gasoline containing methanol.
■Non-recommendation of the use of gasoline containing MMT
Some gasoline contains an octane enhancing additive called MMT (Methylcy clopenta-
dienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gasolin e that contains MMT. If fuel containing
MMT is used, your emission control system may be adversely affected.
The malfunction indicator lamp on the instru ment cluster may come on. If this happens,
contact your Lexus dealer for service.
●Use only gasoline containing a maximum of
10% ethanol.
DO NOT use any flex-fuel or gasoline that
could contain more than 10% ethanol, includ-
ing from any pump labeled E15, E30, E50,
E85 (which are only some examples of fuel
containing more than 10% ethanol).DO NOT use gasoline con-
taining more than 10% eth-
anol.
(15% ethanol)
(50% ethanol)
(85% ethanol)

616Alphabetical index
GX460_OM_OM60K80U_(U)
Seat heaters ............................................ 390
Seat ventilators ........................................391
Seat position memory.......................... 128
Seats...................................................... 115, 117Adjustment .......................................115, 117
Adjustment precautions .......... 116, 127
Child seats/child restraint system installation..............................56
Cleaning ................................................. 437
Driving position memory ................ 128
Head restraint ........................................132
Properly sitting in the seat ................ 26
Seat position memory....................... 128
Ventilators .............................................. 391
Sensor Automatic headlight system .......... 194
Inside rear view mirror ..................... 138
Intuitive parking assist-sensor ..................................... 234
Rain-sensing windshield wipers .................................................. 205
Service reminder indicators ................72
Shift lever Automatic transmission ................... 186
If the shift lever cannot be shifted from P ...................................542
Shift lock system.................................... 542
Shopping bag hooks ........................... 403
Side airbags ............................................... 34
Side mirrors ..............................................139 Adjusting and folding........................ 139
Blind Spot Monitor............................ 347
Side turn signal lights ........................... 190 Replacing light bulbs ......................... 491
Turn signal lever .................................. 190 Smart access system with
push-button start................................ 108 Antenna location................................. 108
Starting the engine ............................... 181
Snow tires ................................................ 368
Spare tire ..................................................527 Inflation pressure.................................. 471
Storage location .................................528
Spark plug ............................................... 558
Specifications......................................... 554
Speedometer ............................................. 77
Steering lock Column lock release .........................184
Steering wheel ........................................ 135 Adjustment..............................................135
Audio switches
*
Heated steering wheel ...................389
Steering wheel position memory.................................................128
Stop/tail lights Wattage .................................................563
Storage feature ..................................... 395
Stuck If the vehicle becomes stuck......... 551
Sun shade Roof ............................................................146
Sun visors.....................................................411
Switch “2nd START” button ..........................187
AVS switch ............................................. 331
BSM (Blind spot monitor) switch ................................................... 347
Center differential lock/ unlock switch.................................... 333
Crawl Control switch...................... 336
Cruise control switch .............. 214, 217
“DAC” switch ...................................... 339
