Garage door opener
The garage door opener (HomeLink® Universal Transceiver) is manufactured
under license from HomeLink®.
The HomeLink
® compatible transceiver in your vehicle has 3 buttons which can
be programmed to operate 3 different devices. Refer to the programming
method below appropriate for the device.
Indicator light
Buttons
■Before programming HomeLink®
●During programming, it is possible that garage doors, gates, or other devices
may operate. For this reason, make sure that people and objects are clear of
the garage door or other devices to pr event injury or other potential harm.
●It is recommended that a new battery be placed in the remote control trans-
mitter for more accurate programming.
●Garage door openers manufactured after 1995 may be equipped with rolling
code protection . If this is the case, you will need a stepladder or other sturdy,
safe device to reach the “Learn” or “S mart” button on the garage door opener
motor.
The garage door opener can be programmed to operate garage doors, gates,
entry doors, door locks, home lighting systems, security systems, and other
devices.
Programming the HomeLink®
1
2

GX460_OM_OM60L72U_(U)
4295-4. Using the other interior features
5
Interior features
Te s t t h e H o m e L i n k® operation by
pressing the newly programmed
button and observing the indica-
tor light:
●If the indicator light is solid/
continuous, programming has
been completed and your
device should activate when
the HomeLink
® button is
pressed and released.
●If the indicator light blinks rapidly for 2 seconds and then turns into a
solid/continuous light, proceed with the following instructions for
programming a rolling code system.
Programming a rolling code system
Locate the “Learn” or “Smart”
button on the garage door
opener motor in the garage.
This button can usually be found
where the hanging antenna wire is
attached to the unit. The name and
color of the button may vary by man-
ufacturer. Please refer to the opera-
tor’s manual supplied with the garage
door opener motor for details.
Press and release the “Learn” or
“Smart” button.
Pe r f o r m w i t h i n 3 0 s e c o n d s
after performing .
3
4
4
5
6
5

430
GX460_OM_OM60L72U_(U)5-4. Using the other interior features
Press and hold the programmed
HomeLink® button (located
inside the vehicle) for 2 seconds
and release it. Repeat this
sequence (press/hold/release)
up to 3 times to complete pro-
gramming.
If the garage door opener motor
activates when the HomeLink® but-
ton is pressed, the garage door
opener motor recognizes the
HomeLink
® signal.
Repeat the steps above to program another device for any of the remaining
HomeLink® buttons.
■Reprogramming a single HomeLink® button
When the following procedure is performed, buttons which already have
devices registered to them can be overwritten: With one hand, press and hold the desired HomeLink
® button.
When the HomeLink
® indicator starts flashing , continue to hold the
HomeLink® button and perform “Programming HomeLink®” from (it
takes 20 seconds for the HomeLink® indicator to start flashing).
Press and hold the 2 outside buttons for
10 seconds until the indicator light
flashes.
If you sell your vehicle, be sure to erase
the programs stored in the HomeLink®
memory.
6
Erasing the entire HomeLink® memory (all three programs)
7
1
2
1

GX460_OM_OM60L72U_(U)
4315-4. Using the other interior features
5
Interior features
■Programs stored in the HomeLink® memory
●The registered codes are not erased even if the 12-volt battery cable is disconnected.
●If learning failed when registering a different code to a HomeLink® button that already
has a code registered to it, the already registered code is not erased.
■Certification for the garage door opener
For vehicles sold in the U.S.A., Ha waii, Guam, Saipan and Puerto Rico
For vehicles sold in Canada
■When support is necessary
Visit on the web at www.homelink.com
or call 1-800-355-3515.
CAUTION
■When programming a garage door or other remote control device
The garage door or other device may operat e, so ensure people and objects are out of
danger to prevent potential harm.
■Conforming to federal safety standards
Do not use the HomeLink® compatible transceiver with any garage door opener or
device that lacks safety stop and reverse fe atures as required by federal safety stan-
dards.
This includes any garage door that canno t detect an interfering object. A door or
device without these features increases the risk of death or serious injury.
■When operating or programming HomeLink®
Never allow a child to operate or play with the HomeLink® buttons.

622Alphabetical index
GX460_OM_OM60L72U_(U)
Fuel ............................................................. 564Capacity ................................................ 564
Fuel gauge ................................................ 79
Fuel pump shut off system.............. 510
Information ............................................ 572
Refueling...................................................214
Type ............................................... 214, 564
Warning light ........................................ 513
Fuel consumption information ........... 88
Fuel filler door .......................................... 214 Refueling...................................................214
Fuel gauge ...................................................79
Fuel pump shut off system.................. 510
Fuses .......................................................... 485
Garage door opener ...........................427
Gauges .........................................................79
Glass hatch .............................................. 106
Glove box ................................................400
Hands-free system (for cellular phone)
*
Head restraints ........................................136
Headlights .................................................196 Light switch ............................................ 196
Replacing light bulbs ........................492
Wattage ................................................... 571
Headlights cleaner.................................213
Heaters Automatic air conditioning system .................................... 380, 390
Seat heaters ..........................................394
Outside rear view mirrors ............ 385 Height control ......................................... 331
Hill-start assist control ....................... 346
Hood ......................................................... 454
Hooks
Cargo hooks .......................... 406, 407
Coat hooks ............................................. 421
Retaining hooks (floor mat)..............24
Horn............................................................. 139
I/M test ..................................................... 450
Identification Engine ..................................................... 564
Vehicle ....................................................563
Ignition switch (engine switch) .........185
Ignition switch light .............................. 396
Illuminated entry system ................... 398
Immobilizer system ................................ 68
Indicators ..................................................... 74
Initialization Moon roof .............................................. 150
Power windows.................................... 147
Inside rear view mirror...........................141
Instrument panel light control ............ 80
Interior lights .......................................... 396 Switch ...................................................... 397
Wattage ................................................... 571
Jack Vehicle-equipped jack ................... 534
Jack handle ..............................................537
Jam protection function Moon roof .............................................. 150
Power windows.................................... 147
G
H
I
J
