1. INFORMATION DISPLAY
1. RECEIVING DOPPLER WEATHER INFORMATION
1Press the “INFO/APPS” button.
2Select “Weather” .
3Check that the “Weather” screen is dis-
played.Doppler weather radar information can
be received via the HD radio or by the
LEXUS App Suite application on a
Bluetooth
® phone. For details about the
LEXUS App Suite application: →P.350
DISPLAYING DOPPLER
WEATHER INFORMATION
No.Function
Select to display the weather of the
current location. ( →P.297)
Select to display the weather of a de-
sired location in the recently
checked locations list.
Select to display the weather of a de-
sired location in the national cities
list.
Select to display the weather of a de-
sired location in the other local cities
list.
Select to display Doppler weather
radar information over the map.
GX_Navi_OM60L77U_(U).book Page 296 Monday, June 2, 2014 10:49 AM

297
1. INFORMATION DISPLAY
6
INFORMATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
1Display the “Weather” screen.
(→ P.296)
2Select “Current Weather” .
3Select the desired tab to be displayed.
X When the “Current” tab is selected
X When the “3 Day” tab is selected
zWhen a specific day is selected, weather
information for that day will be displayed.
X When the “6/12 Hour” tab is selectedDISPLAYING THE WEATHER
OF THE CURRENT LOCATION
INFORMATION
●
If weather is set to the home screen, the
weather screen of the current location
will be displayed.
GX_Navi_OM60L77U_(U).book Page 297 Monday, June 2, 2014 10:49 AM

298
1. INFORMATION DISPLAY
GX460_Navi_OM60L77U_(U)14.06.02 10:48
2. DATA SERVICES SETTINGS
1Press the “SETUP” button.
2Select “Data Services Settings” .
3Select the desired item to be set.
zSelect a checkbox on the right to set.
SETTING DOWNLOAD
METHODS
Data service information, which is com-
prised of traffic information and weather
information, can be received via the HD
radio and by the LEXUS App Suite ap-
plication on a Bluetooth
® phone. The
receiving method can be set to both or
only via the HD radio. For details about
the LEXUS App Suite application:
→ P.350
No.Function
Select to receive data service infor-
mation via both the HD radio and the
LEXUS App Suite application on a
Bluetooth
® phone. When both
methods are available, the HD radio
will be selected.
Select to receive data only via the
HD radio.
GX_Navi_OM60L77U_(U).book Page 298 Monday, June 2, 2014 10:49 AM

7
299
1
2
3
4
5
6
7
8
GX460_Navi_OM60L77U_(U)14.05.27 10:31
1. QUICK REFERENCE ........................... 300
2. SOME BASICS ......................................... 301
REGISTERING/CONNECTING A Bluetooth® PHONE.......................................... 302
USING THE PHONE SWITCH/ MICROPHONE ................................................. 302
VOICE COMMAND SYSTEM...................... 303
ABOUT THE CONTACTS IN THE CONTACT LIST ................................................. 304
WHEN SELLING OR DISPOSING OF THE VEHICLE ............................................. 304
3. CALLING ON THE Bluetooth®
PHONE.................................................... 305
BY FAVORITES LIST ........................................... 306
BY CALL HISTORY ............................................. 306
BY CONTACTS LIST .......................................... 307
BY DIAL PAD ............................................................ 310
BY OFF HOOK SWITCH ................................... 310
4. RECEIVING ON THE Bluetooth®
PHONE...................................................... 311
INCOMING CALLS ............................................... 311
5. TALKING ON THE Bluetooth®
PHONE..................................................... 312
INCOMING CALL WAITING ......................... 314
6. Bluetooth® PHONE MESSAGE
FUNCTION............................................. 315
RECEIVING A MESSAGE ................................. 316
CHECKING MESSAGES ................................... 317
REPLYING TO A MESSAGE
(QUICK REPLY)................................................... 318
CALLING THE MESSAGE SENDER ......... 320
1. PHONE/MESSAGE SETTINGS ....... 322
PHONE/MESSAGE SETTINGS SCREEN ................................................................. 322
“Sound Settings” SCREEN ................................. 323
“Contact/Call History Settings” SCREEN ................................................................. 324
“Messaging Settings” SCREEN ........................ 335
“Phone Display Settings” SCREEN .................. 337
1. TROUBLESHOOTING ........................ 338
1
PHONE OPERATION
(HANDS-FREE SYSTEM
FOR CELLULAR PHONES)
2SETUP
3WHAT TO DO IF...
PHONE
GX_Navi_OM60L77U_(U).book Page 299 Monday, June 2, 2014 10:49 AM

300
GX460_Navi_OM60L77U_(U)14.06.02 11:29
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES)
1. QUICK REFERENCE
The phone top screen can be used to make a phone call. To display the hands-free op-
eration screen, press the
button, or the switch on the steering wheel.
Several functions are available to operate on each screen that is displayed by selecting
the 4 tabs.
FunctionPage
Phone operation
Registering/connecting Bluetooth® device40
Calling on the Bluetooth® phone305
Receiving on the Bluetooth® phone311
Talking on the Bluetooth® phone312
Message functionUsing the Bluetooth® phone message function315
Setting up a phonePhone settings322
Bluetooth® settings45
07-1.fm Page 300 Monday, June 2, 2014 11:30 AM

302
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES)
GX460_Navi_OM60L77U_(U)14.06.02 11:29
XSteering switch
Volume control switch
z Press the “+” side to increase the volume.
z Press the “-” side to decrease the volume.
Off hook switch
On hook switch
REGISTERING/
CONNECTING A Bluetooth®
PHONE
To use the hands-free system for cellular
phones, it is necessary to register a cel-
lular phone with the system. ( →P.40)
Bluetooth® PHONE
CONDITION DISPLAY
The condition of the Bluetooth
® phone
appears on the upper right side of the
screen. ( →P.14)
USING THE PHONE SWITCH/
MICROPHONE
By pressing the phone switch, a call can
be received or ended without taking
your hands off the steering wheel.
07-1.fm Page 302 Monday, June 2, 2014 11:30 AM

305
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES)
GX460_Navi_OM60L77U_(U)14.06.02 11:29
7
PHONE
3. CALLING ON THE Bluetooth® PHONE
1Press the button.
2Select the desired tab to call from.
zThe phone top screen can be displayed by
pressing the
switch on the steering
wheel.
After a Bluetooth® phone has been reg-
istered, a call can be made using the
hands-free system. There are several
methods by which a call can be made, as
described below.
How to make a call listPage
By favorites list306
By call history306
By contacts list*307
By dial pad*310
By e-mail/SMS/MMS320
By POI call83
By off hook switch310
By LEXUS App Suite*363
By voice command system286
*: The operation cannot be performed while driving.
07-1.fm Page 305 Monday, June 2, 2014 11:30 AM

306
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES)
GX460_Navi_OM60L77U_(U)14.06.02 11:29
1Display the phone top screen.
(→ P.305)
2Select the “Favorites” tab and select the
desired contact.
3Select the desired number.
4Check that the “Call” screen is dis-
played.
1Display the phone top screen.
( → P.305)
2Select the “Call History” tab and select
or the desired contact.
z The icons of call type are displayed.
: Missed call
: Incoming call
: Outgoing call
BY FAVORITES LIST
Calls can be made using registered con-
tacts which can be selected from a con-
tact list. ( →P.332)
BY CALL HISTORY
Up to 30 of the latest call history items
(missed, incoming and outgoing) can be
selected from the “Call History” tab.
07-1.fm Page 306 Monday, June 2, 2014 11:30 AM

307
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES)
7
PHONE
GX460_Navi_OM60L77U_(U)14.06.02 11:29
XWhen is selected
3Check that the “Call” screen is dis-
played.
X When the desired contact is selected
3Select the desired number.
4Check that the “Call” screen is dis-
played.
1Display the phone top screen.
(→ P.305)
2Select the “Contacts” tab and select the
desired contact.
3Select the desired number.
4Check that the “Call” screen is dis-
played.
INFORMATION
●
When making a call to the same number
continuously, only the most recent call is
listed in call history.
●When a phone number registered in the
contact list is received, the name is dis-
played.
●Number-withheld calls are also memo-
rized in the system.
●International phone calls may not be
made depending on the type of cellular
phone you have.
●The list should group together consecu-
tive entries with the same phone number
and same call type. For example, two calls
from John’s mobile would be displayed as
follows: John (2)
●By pressing the switch on the steering
wheel, a call to the latest history item can
be made.
BY CONTACTS LIST
Calls can be made by using contact data
which is transferred from a registered
cellular phone. ( →P.308)
Up to 2500 contacts (maximum of 4
phone numbers and e-mail addresses
per contact) can be registered in the
contact list.
07-1.fm Page 307 Monday, June 2, 2014 11:30 AM

310
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES)
GX460_Navi_OM60L77U_(U)14.06.02 11:29
1Display the phone top screen.
(→ P.305)
2Select the “Dial Pad” tab and enter the
phone number.
3Select or press the switch on
the steering wheel.
4Check that the “Call” screen is dis-
played.
1Press the switch on the steering
wheel to display the phone top screen.
2Press the switch on the steering
wheel to display the “Call History”
screen.
3Press the switch on the steering
wheel to call the latest history item.
4Check that the “Call” screen is dis-
played.
BY DIAL PAD
INFORMATION
●
Depending on the type of Bluetooth®
phone being connected, it may be neces-
sary to perform additional steps on the
phone.
BY OFF HOOK SWITCH
Calls can be made using the latest call
history item.
07-1.fm Page 310 Monday, June 2, 2014 11:30 AM
